Power - Racelogic Performance Box Touch V1 User Manual

Product Code
PBT-V1
RLACS184
USB2-007241
RLACS313
RLACS277
RLACS290
RLACS284
RLACS281

Power

The supplied USB cable (USB2-007241) plugs into the
Cigar Plug USB Adapter (RLACS184) and the vehicle's 12 V cigar power socket to power the Performance Box Touch.
You can also have the Performance Box Touch powered by the battery (which is available from
Racelogic – RLACS290). You can find more information on the battery below.
When booting up, the Performance Box Touch will display a splash screen and automatically look for satellites and
media.
https://en.racelogic.support//Product_Info/VBOX_Data_Loggers/Performance_Box_Touch/Performance_Box_Touch_V1/
User_Guide_%E2%80%93_Performance_Box_Touch_V1/01_Getting_Started_%E2%80%93_Performance_Box_Touch_V1
Quantity
1
1
2
1
1
1
1
1
Power socket on the right-hand side of the unit. Use the supplied
Description
Performance Box Touch Unit
Cigar Plug USB Adapter
USB 2.0 A to Right Angle Micro B
data and Charging Cable, 1.5 m
8 GB SD Ultima Pro UHS-1 Memory
Card
Swivel Neck Richter Suction Mount
Performance Box Touch Battery
GPS/GLONASS Low Profile
Antenna, 2 m
Plastic Carry Case
4
