- Page 1 Assembly Instructions W17N4061W Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.
-
Page 4: Table Of Contents
Cam bolt Screw Screw Cam lock Wooden dowel Ø3x12mm Ø3x14mm Ø6x35mm Ø15x10mm Ø6x30mm x 18 x 18 x 12 x 18 Shelf support pin Screw Hinge Magnetic catch Plastic wedge Ø5x25mm Ø4x35mm Bolt Anchor Screw Magnetic plate Handle Ø4x18mm Ø7.5x40mm Ø4.5x50mm Philips screwdriverr Tools Required... - Page 5 x 12 · Gently screw cam bolts(A) into panels(1,2,3). · Attach magnetic catch(H) to panel(3) with screws(E). Ø3x14mm ３...
- Page 6 Finished edges · Insert dowel(C) into panel(7). · Attach panels(4,7) to panel(2). · Insert and secure cam locks(B) to panels(4,7) to lock it.
- Page 7 · Insert dowel(C) into panel(7). · Attach panel(1) to panels(4,7). · Insert and secure cam locks(B) to panels(4,7) to lock it.
-
Page 8: A X
· Attach parts(G) to panels(9,10) with screws(D). · Gently screw cam bolts(A) into panels(9,10). Ø3x12mm... - Page 9 · Attach panels(9,10) to panels(1,2). · Insert and secure cam locks(B) to panels(1,2) to lock it.
- Page 10 · Insert dowels(C) into panels(1,2,9,10). · Attach panel(8) to panels(1,2,9,10) with screws(I).
- Page 11 ·Carefully insert panel(5) into the slot of panels(1,2,8).
- Page 12 · Insert dowels(C) into panels(1,2,4,9,10). · Attach panel(3) to panels(1,2,4,9,10). · Insert and secure cam locks(B) to panels(1,2) to lock it.
- Page 13 · Secure parts(J) with screws(E).
-
Page 14: F X
Finished edge · Insert the shelf supports(F) at the desired level and place the adjustable shelf(6) onto the shelf supports. -
Page 15: L X
· Attach parts(K) to panels(11,12) with screws(D). · Attach parts(L) to panels(11,12) with bolts(M). - Page 16 · Attach panels(11,12) to panels(9,10) with screws(D).
-
Page 17: N X
Note: The parts N and O for hanging the cabinet work with wooden wall, solid wall.Please purchase the suitable parts to prevent the cabinet from falling down if you hang it on the other type of walls.
