- Page 1 Assembly Instructions W18N4063W Please read this manual carefully before beginning assembly of this product.Keep this manual for future reference.
- Page 4 Cam bolt Cam lock Bolt Screw Wooden dowel Handle Handle Magnetic plate Ø6x35mm Ø15x10mm Ø4x18mm Ø3x12mm Ø6x30mm x 25 x 25 x 12 x 26 Screw Plastic wedge Screw Shelf support pi Anchor Screw Magnetic catch L-iron Ø4x12mm Ø3x14mm Ø5x25mm Ø6x30mm Ø4x35mm x 10...
- Page 5 · Attach panels(9) to panels(1,2) with screws(R) correctly. · Gently screw cam bolts(A) into panels(1,2). · Stick parts(W) on panels(1,2) as shown. ３...
- Page 6 · Attach left slider arm(S) to panel(9) on panel(1) with screws(D) correctly. · Attach right slider arm(T) to panel(9) on panel(2) with screws(D) correctly.
- Page 7 Finished edge · Attach part(J) to panel(5) with screws(I). · Insert dowels(C) into panel(7). · Attach panels(5,7) to panel(2). · Insert and secure cam locks(B) to panels(5,7) to lock it.
- Page 8 · Insert dowel(C) into panel(7). · Attach panel(1) to panels(5,7). · Insert and secure cam locks(B) to panels(5,7) to lock it.
- Page 9 · Attach parts(Q) to panels(10,11) with screws(D). · Gently screw cam bolts(A) into panels(8,10,11).
- Page 10 · Insert dowels(C) into panels(10,11), then attach panels(10,11) to panel(8). · Attach panels(8,10,11) to panels(1,2,7). · Insert and secure cam locks(B) to panels(1,2,7) to lock it.
- Page 11 ·Carefully insert panel(4) into the slot of panels(1,2,7).
- Page 12 · Gently screw cam bolts(A) into panel(3). · Attach L-iron(K) to panel(3) with screw(L).
- Page 13 · Insert dowels(C) into panels(1,2,10,11). · Attach panel(3) to panels(1,2,10,11). · Insert and secure cam locks(B) to panels(1,2) to lock it.
- Page 14 · Secure parts(M) with Screws(I).
- Page 15 · Attach panels(15,16) to panel(12) with screws(R). · Carefully insert panel(13) into the slot of panels(12,15,16).
- Page 16 · Screw cam bolts(A) into panel(14). · Attach handle(G) to panel(14) with bolts(E). · Attach panel(14) to panels(13,15,16). · Insert and secure cam locks(B) to panels(15,16) to lock it.
- Page 17 · Attach right slider bracket(U) to panel(16) with screws(D) correctly. · Attach left slider bracket(V) to panel(15) with screws(D) correctly.
- Page 18 Cabinet Slide arms Drawer Slide brackets Finished edge · Slide the drawer into the cabinet as shown in the diagram. · Insert the shelf supports(N) at the desired level and place the adjustable shelf(6) onto the shelf supports.
- Page 19 · Attach parts(H) to panels(17,18) with screws(D). · Attach parts(F) to panels(17,18) with bolts(E).
- Page 20 · Attach panels(17,18) to panels(10,11) with screws(D).
- Page 21 Note: We recommend it to be fixed to the wall to prevent the furniture from tipping over. Wall anchor and hardware are included in the package. Please make sure hardware is suitable for your walls before installation, as different wall materials may require different types of anchors.
