Summary of Contents for Lehner Lifttechnik Omega
- Page 2 User manual Platform lift "Omega” Version: September 2022 Lehner Lifttechnik GmbH Salling 8 4724 Neukirchen am Walde Austria Tel: +43 7278 3514 15 E-mail: office@lehnerlifttechnik.at Web: www.lehner-lifttechnik.at Take a look at the user video of our platform stairlifts...
-
Page 3: Table Of Contents
Radio controlled call stations at the stops ......................12 Operation of the platform ..............................14 Call the platform ................................14 Driving on the platform ............................. 14 Driving with the platform ............................15 Leaving the platform ..............................15 Troubleshooting ..................................16 Omega | User Manual Version 09/2022... - Page 4 Installation and commissioning ............................26 11.1 Fixing the rail system ..............................26 11.2 Dismantling and disposal............................26 Declaration of Conformity ..............................27 Duties of the platform lift operator ............................28 Requirements for the maintenance company .........................29 Assembly and maintenance records ..........................30 Omega | User Manual Version 09/2022...
-
Page 5: Introduction
INTRODUCTION We would like to congratulate you on your purchase of a platform lift from Lehner Lifttechnik GmbH and welcome you to our large circle of satisfied customers. For more than 30 years, our lifts have been known as reliable means of transport, which are characterised by individual adaptation to structural conditions. -
Page 6: Attention - Safety First
Failure to observe this sign will result in immediate increased danger and may cause personal injury or damage to property. All pictures, photos and drawings used in this manual are symbolic only and may Image differ from reality. Photo Omega | User Manual Version 09/2022 Page 2... -
Page 7: Platform Lift Operator
2.5 Qualified workers Installation, maintenance, repairs and checks must be carried out by qualified persons, preferably by companies authorised by Lehner Lifttechnik. 2.6 Decommissioning When the unit is taken out of service for cleaning, maintenance or repair work, it must be protected against unintentional movement. -
Page 8: Intended Use
Do not disable any safety device by making mechanical or electrical changes to the • installation. Without the written consent of Lehner Lifttechnik, all types of adjustments and/or modifications to the system are prohibited The platform lift may only be used by one person at a time. Accompanying persons •... -
Page 9: Use Of The Platform Lift
In the user video of our platform stairlifts we show you the correct use of your lift. Omega | User Manual Version 09/2022 Page 5... -
Page 10: Technical Equipment
3 TECHNICAL EQUIPMENT The Omega platform lift was developed for transporting wheelchair users. It is driven by a revolving traction cable that is connected to the motor at the end of the rail. The lift is permanently powered. The standard version is supplied with an automatically folding platform and rails made of coated steel. -
Page 11: Platform
3.2 Platform Display Unblocking of barriers Lateral contact bars Lower carriage with limit switches Linkage platform - sidewall Safety bottom Access ramp Upper carriage Omega | User Manual Version 09/2022 Page 7... -
Page 12: Overview Of The Drive
3.3 Overview of the drive Top emergency Main switch limit switch Control board Frequency converter Motor Handwheel for manual operation Omega | User Manual Version 09/2022 Page 8... -
Page 13: Technical Specifications
Volume < 60 dB (A) Certificates TÜV according to EN 81-41 In some situations it is necessary to make a special adjustment to the platform lift, which may change the above specifications. Omega | User Manual Version 09/2022 Page 9... -
Page 14: Safety Devices
4 SAFETY DEVICES The Omega platform lift is equipped with the following safety devices: Platform barriers and access ramps The barriers and access ramps, which must be closed (horizontally) or folded down during the journey, prevent the vehicle from falling in the longitudinal direction. These always open automatically at the stops if the travel command is held down. -
Page 15: Operating Elements
The handset is only used to drive the open platform and to open and close the barriers in the landings. Alternatively, or additionally, controls can also be mounted on the top of the platform side wall. Omega | User Manual Version 09/2022 Page 11... -
Page 16: Radio Controlled Call Stations At The Stops
Only when closed can the platform be sent down. OPEN the platform This command only works when the platform OMEGA is in the landing. CLOSE the platform This command also works when the platform is outside the landing. Key switch Omega | User Manual Version 09/2022 Page 12... - Page 17 Green flashing Radio transmitter has been successfully registered with the receiver Orange flashing Radio connection interrupted Red flashing The battery of the radio transmitter is weak and should be replaced. Omega | User Manual Version 09/2022 Page 13...
-
Page 18: Operation Of The Platform
6 OPERATION OF THE PLATFORM The Omega platform lift is safe and easy to use. The operation is designed for a user with walking difficulties. Before moving the platform, make sure that nobody is endangered by the movement of the platform. If a dangerous situation arises while the platform is moving, stop the... -
Page 19: Driving With The Platform
To prevent unauthorised use of the lift, you should always remove the key in the call stations after using the lift. Omega | User Manual Version 09/2022 Page 15... -
Page 20: Troubleshooting
7 TROUBLESHOOTING General For safety reasons, your Omega platform lift is fitted with a number of electrical and mechanical interlocks and touch sensitive edges. If any of these devices are not in order or any component or sequence is not working correctly, the unit will not operate. In the event of a breakdown, you can independently check your system for faults with the support of the points listed below or contact the service personnel. -
Page 21: Error Table
A barrier does not open The platform does not reach Have the switch reset by the the stop completely. service company. Check whether the contact bar/safety bottom is activated. Omega | User Manual Version 09/2022 Page 17... -
Page 22: Status Messages On The Display
SI: S27, A-S11U IN LOWER Displayed when the barriers are Drive command upwards by means STATION already fully open in lower stop. of handset control. SI: S28, A-S11U Omega | User Manual Version 09/2022 Page 18... - Page 23 BARRIER The stop is not set correctly. Use the emergency hand wheel to UNBLOCK move the platform out of the SI: S14,15,16 landing, then contact your service company. Omega | User Manual Version 09/2022 Page 19...
-
Page 24: Liberation Of A Passenger
At the stop, the barrier on the side where the platform is normally exited can be opened manually and the wheelchair user can now exit the platform. Lever for opening the engine brake Handwheel for manual operation Omega | User Manual Version 09/2022 Page 20... -
Page 25: Platform Is Not Located Near The Landing Stop
The wheelchair user can now be lifted off the platform. This must always be done in the upward direction on the stairs. It is essential to press the lever marked RED; this ensures that the barrier on the uphill side is unlocked. Omega | User Manual Version 09/2022 Page 21... -
Page 26: Control And Maintenance
The floor should be wiped with a damp dust rag. Avoid wetness, especially with the operating elements (no splashing water). ▪ Further maintenance work may only be carried out by authorised partner companies. ▪ Omega | User Manual Version 09/2022 Page 22... -
Page 27: Maintenance / Inspection
Main switch (ON/OFF) on the side of the platform sidewall ▪ Emergency stop on the platform ▪ Up and down on the call stations ▪ Up and down operation on the platform handset ▪ Call stations key switch ▪ Omega | User Manual Version 09/2022 Page 23... -
Page 28: Mechanics Of The Platform Barriers, The Ramps And The Platform Motor
Check mechanical switches for function (test faulty switching) ▪ Check all fastening and actuating elements of the forced switches for secure hold. ▪ Omega | User Manual Version 09/2022 Page 24... -
Page 29: Gearbox And Drive Motor
10.3.2 Spare parts Only original spare parts from Lehner Lifttechnik may be used, as this is the only way to guarantee safety and functionality. If other products are used, the declaration of conformity loses its validity. Omega | User Manual... -
Page 30: Installation And Commissioning
If you have any problems or questions, contact your Lehner Lifttechnik partner or customer service. Installation work on the entire system may only be carried out by the manufacturer or its authorised partner companies. -
Page 31: Declaration Of Conformity
The technical documentation is managed by: Lehner Lifttechnik GmbH Salling 8, 4724 Neukirchen am Walde, Austria This declaration becomes invalid if the machine is modified or altered or if the provisions of the "Omega- F - User Manual" are not observed. Lehner Christian Neukirchen... -
Page 32: Duties Of The Platform Lift Operator
Irregularities during operation or emergency situations must be reported immediately to the maintenance company. In addition, the maintenance company must be informed of all changes to the building and the system that could affect operation. Omega | User Manual Version 09/2022 Page 28... -
Page 33: Requirements For The Maintenance Company
The maintenance company must have appropriate and sufficient insurance cover. ▪ The maintenance company must record every intervention that occurred due to a fault. ▪ Omega | User Manual Version 09/2022 Page 29... -
Page 34: Assembly And Maintenance Records
15 ASSEMBLY AND MAINTENANCE RECORDS Assembled by: __________________________________________________________ Date: __________________________________________________________________ This is the maintenance record sheet for your platform lift. This form is filled out by your maintenance company during a service. Date Details Name Omega | User Manual Version 09/2022 Page 30... - Page 35 Date Details Name Omega | User Manual Version 09/2022 Page 31...
