Summary of Contents for Lehner Lifttechnik LIFTBOY 4
- Page 2 INTRODUCTION Thank you for deciding to buy the vertical lifting platform type Liftboy 4 (further only platform) for handicapped persons. It is a modern, technically advanced product, which meets current requirements of control and operational safety. Beside the vertical lifting platform our company produces and supplies inclined stair platforms, inclined chair lifts, and other types of vertical lifting platforms with a lifting height from 0,0m to 4m, which are projected and constructed according to the customer’s wish.
-
Page 3: Table Of Contents
8.2.2 Emergency movement of the platform and rescuing of persons .......... 8 Safety operational requirements ......................9 Guide for operation, maintenance and scrapping of batteries ............10 Operation and maintenance ........................ 10 Service life and operational conditions ..................... 10 Operational conditions .......................... 10 Liftboy 4 | User handbook... - Page 4 Packing, delivery, Storing, Warranty ......................11 Duties of device operator ..........................12 Attachments ............................... 13 12.1 Lubrication plan ............................13 12.2 Drawing of the complete platform ..................... 14 12.2.1 Liftboy 4 S ............................14 12.2.2 Liftboy 4 L ............................15 Liftboy 4 | User handbook...
-
Page 5: Definitions
The platform is passable in straight direction, and it allows the transport of persons between two height levels. The control of the platform movement is performed by pressing and holding of the button on the control panel. Liftboy 4 | User handbook page 1... -
Page 6: Technical Description
Lower frame of the platform Lower shear Upper shear Middle part Platform floor Lower safety frame Electrical accumulators Electrical switchboard of the platform (placed behind the removable cover) Electromechanical strut 10 Control panel on the platform Liftboy 4 | User handbook page 2... -
Page 7: Technical Parameters
Liftboy 4 S Width: 845 mm | Length: 1500 mm Liftboy 4 L Width: 862 mm | Length: 1410 mm Lifting height: Liftboy 4 S: 1000 mm Liftboy 4 L: 1400 mm Maximal lifting height: 1400 mm Minimum height of platform:... -
Page 8: Charging Of Batteries
6.2 Process of connecting the charger Charging the batteries is possible in two ways: Connecting the charger with the external port. The battery does not need to be removed from the platform. Liftboy 4 | User handbook page 4... - Page 9 When connecting the charger, always connect the charging connector to the battery pack or to the external charging connector first. Then connect the charger to the socket 1 x 230 V 50/60 Hz Green LED: end of charging, charged Orange LED: charging process Liftboy 4 | User handbook page 5...
-
Page 10: Control Of The Platform
Before the operating person can control the platform, please ensure that no person or obstacle is in the operating space. 7.2 Control panel on the platform Stop Green LED: ON Yellow LED: Lowering of battery capacity/overload Red LED: Discharged battery Movement direction: Movement direction: DOWN Liftboy 4 | User handbook page 6... -
Page 11: Operating Instruction
The platform moves while the button is pushed. When the button is released while the platform is moving, it stops, and it is only possible to continue the movement when a new choice Liftboy 4 | User handbook page 7... -
Page 12: Fold Up The Ramp Again
In this case, two situation models are described below. Attention: The evacuation of the transported person from the platform can be done by trained person only. Liftboy 4 | User handbook page 8... -
Page 13: Safety Operational Requirements
The device is designed for a whole load of 300 kg (with evenly split charge). Such a loading prompts no damage to the platform and all safety standards are met. Liftboy 4 | User handbook page 9... -
Page 14: Guide For Operation, Maintenance And Scrapping Of Batteries
CSN33 2000-5-51. The platform can also be placed outdoors and in areas that are not protected from rainfall. The operating load amounts to max. 10%, which means 6 min / h. Liftboy 4 | User handbook page 10... -
Page 15: Technical Documentation
The manufacturer offers a quality warranty for the duration of the mentioned period. After the warranty period, the maintenance of the platform is guaranteed against payment. Liftboy 4 | User handbook page 11... -
Page 16: Duties Of Device Operator
Please inform the manufacturer or a licensed service company about any problems or emergencies. Furthermore, also please inform them of any changes of the device, which could affect the safety of the platform. Liftboy 4 | User handbook page 12... -
Page 17: Attachments
If used occasionally – lubrication1 x per year during the inspection is sufficient. In case the platform is used several times a day – lubrication 2x to 4x per year is necessary. Recommended lubricating greases: Vaseline Interflon Fin Grease MP00 Liftboy 4 | User handbook page 13... -
Page 18: Drawing Of The Complete Platform
12.2 Drawing of the complete platform 12.2.1 Liftboy 4 S Liftboy 4 | User handbook page 14... -
Page 19: Liftboy 4 L
12.2.2 Liftboy 4 L Liftboy 4 | User handbook page 15...
