ST STM32Cube Quick Start Manual page 40

1 Generate data set
Serial
Data log
Capture data and create specific datasets
Generating contextual data using HSDATALOG in Utilities folder
❑ The equipment behaviors can be analyzed, creating a lot of different dataset based on vibrometer or accelerometer data, focused
on "Normal" & "Anomaly" working condition to monitor and detect. The same approach can be used to classify different "Working
Conditions" creating specific dataset to built a N-Class Classification machine learning model.
❑ To prepare these datasets, you can use HSDatalog firmware, that can be loaded directly via BLE Sensor App, by FUOTA,
available in Utilities/HS_Datalog/Proteus_HS_Datalog_FUOTA_reference.bin
❑ Before start take care that on STEVAL-PROTEUS the blue LED is blinking. If it doesn't, please, press the "RESET" button.
❑ On PC, launch "Utilities/HS_Datalog/cli_example/USB_DataLog_Run.bat" or any other batch file inside
".\PROTEUS_batch_file_examples"
❑ An automatic folder will be created, collecting all the *.DAT files configured to use for the library generation.
Press «RETURN» button
The blue LED turns off and the green LED starts blinking
The acquisition will continue for all the
configured time or up to «ESC» button pressed
40
