ST STM32Cube Quick Start Manual page 11

5
Lock the top case to the bottom
one with the last four screws
included in the kit.
4
Plug the battery connector on J3
3
ut the cover on the battery and
P
close it using two screws.
2
Put the Li-Po battery in the top
case, insert the battery cable into
the dedicated hole.
1
Fix the main board to the case
bottom with the four screws
included in the kit.
STEVAL-PROTEUS1
Power ON
Push and hold S2 until the yellow LED turns on
(HW Featrure)
Yellow
LED
Use a needle to
access the buttons
behind the holes on
Power OFF
the sides of the case.
Push and hold S2 until the Yellow LED turns off
(SW feature)
Unboxing
S2
J3
J3
11
