Industrial sensor evaluation kit for condition monitoring based on 2.4 GHz STM32WB5MMG module
The STEVAL-PROTEUS1 is an evaluation tool designed for temperature and vibration monitoring, based on a 2.4 GHz multiprotocol wireless SoC to address
machine or facility condition monitoring for industrial applications. All components are mounted exclusively on the top side of the PCB to ensure an easy mounting on
other equipment.
Key Features
• Kit content: the STEVAL-PROTEUS main board, LiPo battery 3.7 V, 480 mAh, plastic case and screws
• STEVAL-PROTEUS: STM32WB5MMG - ultra-low-power module, dual core 32-bit Arm Cortex-M4 MCU 64 MHz, Cortex-M0+
32 MHz for real-time radio layer, with 1 Mbyte of flash memory, 256kbyte SRAM, and 2.4GHz RF supporting Bluetooth® Low
Energy 5, 802.15.4, Zigbee 3.0, and Thread
• IIS3DWB - ultra-wide bandwidth up to 6 kHz, low noise, 3-axis digital accelerometer
• ISM330DHCX - iNEMO inertial module with machine learning core and finite state machine with digital output
• IIS2DLPC - high-performance ultra-low-power 3-axis digital accelerometer
• STTS22H - low-voltage, ultra-low-power, 0.5°C accuracy I²C/SMBus 3.0 temperature sensor
• Memory & Secure: 2Gb QSPI NOR flash memory for data storage, STSAFE-A110 - secure element
• Power: STBC02 - Li-Ion linear battery charger with LDO, ST1PS02 - step-down converter with digital voltage selection
• HMI: 3 push-buttons (Reset, User, Power-on with battery), 4 LEDs (three user LEDs, one STBC02 LED status)
• Flexible power supply options - LiPo battery, USB power, and primary battery
• Connectors: SWD connector for debugging and programming capability, 34-pin expansion connector compliant with STMOD+
https://www.st.com/en/evaluation-tools/steval-proteus1.html
Latest info available at:
STEVAL – PROTEUS1
Hardware Overview
Contains:
FCC ID: YCP-STM32WB5M001
IC: 8976A-STM32WB5M01
J3
