Installation; First Step - Automatic Systems TR491 Installation Manual

3.

INSTALLATION

3.1.

First step

4:2
B
Legend:
4:1 Front end section ( "A")
4:2 Rear end section ( "B")
4:3 Hood
•
The tripod turnstile has been packaged suitable for transport.
installation site with the assistance of a fork-lift, or manual hand truck and remove the packing
material.
•
Unlock and open the front doors (4:1) and (4:2). Keys are supplied as accessories in a separate
bag.
•
Open and remove the hood (4:3).
•
Check the state of the material.
occurred during transport.
replaced.
 Automatic Systems TR491-TR6-GB-a YD-JMW 20/01/00
Fig. 4
Though it has been carefully packed, damage may have
Any transportation damage should be repaired, or components
Installation TR491
4:3
A
Move the material to the
2-1106GB Rev.: C
4:1
p. 7/12
