Assembly Instructions & User's Manual
For
Member's Mark
Halstead 7pc Dining set
Item Number: xxxxxxxx
Model Number: GC-11213-7PC
Customer Assistance
: 1-800-691-2824
(spare/replacement parts)
or Email: customerservice@coronadocasuals.com
THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1 |
P a g e
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Member's Mark GC-11213-7PC
Summary of Contents for Member's Mark GC-11213-7PC
- Page 1 Assembly Instructions & User’s Manual Member’s Mark Halstead 7pc Dining set Item Number: xxxxxxxx Model Number: GC-11213-7PC Customer Assistance : 1-800-691-2824 (spare/replacement parts) or Email: customerservice@coronadocasuals.com THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
-
Page 2: Table Of Contents
Table of Contents Quality Statement ............................. 3 Important Safety Information ........................ 3 Before Assembly ............................3 Care & Use ..............................3 Package Contents ............................ 4 Product Information ..........................4 Components .............................. 5 Hardware ..............................5 Tools ................................5 Step 1 ................................. 6 Step 2............................7 Step 3............................8 Furniture Cover..........................9... -
Page 3: Quality Statement
Quality Statement Important Safety Information • Please read all instructions carefully before assembling this product. • Where applicable, and for your safety, assembly by an adult is strongly recommended. • Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. -
Page 4: Package Contents
Package Contents Component Description Quantity Component Description Quantity Table top Allen/Hex Bolt M6x25mm Table legs 1 M6 Washer Table legs 2 Allen Wrench Product Information Product Dimensions： Dining Chair: 27.5” x 28.25” x 41.25” (69.85cm x 71.75cm x 104.77cm) Dining table: φ60” x 29” (φ152cm x 73.66cm) Product Weight Capacity Dining Chair: Supports up to 300 lbs. -
Page 5: Components
Components Table top Table leg 1 Table leg 2 Qty: 1pc Qty: 1pc Qty: 1pc Hardware Allen/Hex Bolt M6 Washer M6x25mm Qty: 8pcs Qty: 8pcs Tools M6 Allen Wrench Qty: 1pc Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... -
Page 6: Step 1
Step 1 M6 Allen Wrench Allen/Hex Bolt M6 Washer M6x25mm Qty: 1pc Qty: 4pcs Qty: 4pcs Carefully place table top (A) upside down a soft, flat and non-abrasive surface. Attach the table leg 1(B) to table top (A) with bolts(D) and Washer(E) by using M6 Allen Wrench(F). -
Page 7: Step 2
Step 2 M6 Allen Wrench Allen/Hex Bolt M6 Washer M6x25mm Qty: 1pc Qty: 4pcs Qty: 4pcs Attach the table leg 2(C) to table top (A) with bolts(D) and Washer(E) by using M6 Allen Wrench(F). Tighten all the bolts with M6 Allen Wrench(F). Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... -
Page 8: Step 3
Step 3 Carefully turn the coffee table over. The dining table is ready for your enjoyment. If the chair and table is uneven, you can adjust the feet to make it even. Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... -
Page 9: Furniture Cover
Furniture Cover Component Description Quantity Component Description Quantity Dining chair Dining table Seat Cushion Furniture cover for dining For maximum protection, use Heavy Duty Furniture Cover (J). Fasten adjustable cord lock to secure the cover from wind and snug fit. Need Assistance? Visit us at: samsclub.com/membersmarkhelp P a g e... -
Page 10: Warranty Information
Warranty Information This product component has a 5 year guarantee against defects in material and/or workmanship. If you have any questions regarding the warranty or spare / replacement parts, please call our toll-free number customerservice@coronadocasuals.com 1-800-691-2824 or email us at NOTE: Please consider recycling all applicable packaging material.
