Assembly Instructions & User's Manual
Member's Mark
Item Number: 980241176
Model Number:TPGAZ2030
Customer Assistance (spare/replacement parts):1-800-847-7508
or Email: servicet@taipengchina.com
DISCLAIMER: Supplier is fully responsible for the entire content of the assembly
manual, including all Sam's Club suggested edits or revisions.
THIS ASSEMB LY MANUA L CONTAINS IMPORTANT SAFET Y INFORMATION.
PLEASE READ AND KEE P FOR FUTURE REFERENCE.
for
[12'x16'ALAMEDA HARDTOP
TM
GAZEBO]
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Member's Mark ALAMEDA TPGAZ2030
Summary of Contents for Member's Mark ALAMEDA TPGAZ2030
- Page 1 Assembly Instructions & User’s Manual Member’s Mark [12'x16'ALAMEDA HARDTOP GAZEBO] Item Number: 980241176 Model Number:TPGAZ2030 Customer Assistance (spare/replacement parts):1-800-847-7508 or Email: servicet@taipengchina.com DISCLAIMER: Supplier is fully responsible for the entire content of the assembly manual, including all Sam’s Club suggested edits or revisions. THIS ASSEMB LY MANUA L CONTAINS IMPORTANT SAFET Y INFORMATION.
-
Page 2: Table Of Contents
Table of Contents Quality Statement ..................3 Important Safety Information ................3 Before Assembly ....................3 Care & Use.....................3 Product Information..................3 Components....................4 Hardware......................6 Tools.......................6 Step 1 – Step 3....................7 Warning....................18 Danger....................18 Care & Use and Storage Instructions.............18 Warranty Information..................19 Need Assistance? Visit us at: samsclub.com/membersmarkhelp... -
Page 3: Quality Statement
Quality Statement Important Safety Information Please read all instructions carefully before assembling this gazebo. For your safety, assembly by two or more adults is strongly recommended. Hardware may loosen overtime. Periodically check that all connections are tight. NOTICE: To prevent injury and property damage from unexpected tipping of furniture, we highly recommend installation of the anti-tip kit included with this product. -
Page 4: Components
Components Upper Central Connector Connector Lower Central Corner Connector Connector Long Top Bar Post Top Bar Connector Base Short Top Bar Roof Support Left Lintel -Left Top 25.20" / 640mm Roof Support Right Lintel -Right Top 25.20" / 640mm Roof Support Short Lintel -Left Middle 49.41"... - Page 5 Components Roof Support Roof Panel -Right Bottom - Left 71.45" / 1815mm Top Panel Roof Panel Cover -Right Top Panel Roof Panel Cover -Right Lintel Cover Roof Panel -Right Mosquito Net Roof Panel -Middle Hook Edge Cover -Left Edge Cover -Right Edge Cover Roof Panel...
-
Page 6: Hardware
Hardware Bolt\Flat Washer M6*15 Bolt /Plastic Washer M6*25 Bolt /Plastic Washer M6*35 Bolt\Flat Washer\ M6*55 Bolt M6*15 Spacer Hanger Stake Tools Wrench (Included) Hammer(Not Included) Allen Wrench (Included) Qty: Part No:EE Qty: Part No:JJ Safety goggles Hardhat Gloves (Not Included) (Not Included) (Not Included) Stepladder... -
Page 7: Step 1 - Step 3
Step 1 (AA) (FF) (HH) Bolt (M6X15) Hanger Bolt\Flat Washer （ M6*15） Qty: 138 Qty: 16 Qty: 56 (EE) (KK) Wrench Allen Wrench Qty: 1 Qty: 1 Fig 1 1-a. Connect the Base (L) and the Post (J) with Bolt\Flat Washer M6*15(AA). seeFig.1 Need Assistance? Visit us at: samsclub.com/membersmarkhelp... - Page 8 ×12PCS ×16PCS Fig 2 1-b. Insert the Hanger (HH) into the track of Right Lintel (E2). Insert the Connector (F) into Left Lintel (E1)/Right Lintel (E2), at the same time connect it to Left Lintel (E1)/Right Lintel (E2) by the Connector (H) with Bolt\Flat Washer(AA).
- Page 9 E1/E2 E1/E2 Fig 4 Fig 3 Fig 5 1-c. Attach the Lintel (E2/E1) to Post (J) with Bolt\Flat Washer M6*15(AA). See Fig.3. tach the Lintel (E2/E1) to Post (J) with Bolt M6*15 (FF) .See Fig.4. Attach the Support Bar (G1/G2) to Lintel (E1/E2) and Post (J) with Bolt\Flat Washer M6*15 (AA).See Fig.5.
- Page 10 1-d. Attach the Right Lintel (E2) and Left Lintel(E1) to Post (J) with Bolt\Flat Washer M6*15(AA). Attach the Right Lintel (E2) and Le ft Lintel (E1) to Post (J) with Bolt M6*15 ( FF ). See Fig.6-7. 1-e. Attach the Left Suppor t Bar (G1) to Left Lintel (E1) and Post (J) with Bolt\Flat Washer M6*15(AA); attach theRight Support Bar (G2) to Right Lintel (E2) and Post(J) with Bolt\Flat WasherM6*15(AA).
- Page 11 Fig.12 Bolt\Flat Washer M6*15(AA) 2-a . Insert the Top Bar (C1) into Long Top Bar (C) and connect with See Fig.12 Fig.13 2-b. Attach Long Top Bar (C) to Lower Central Connector (B) with Bolt\Flat Washer M6*15(AA),attach Top Bar (C1) to Top Connector (K) with Bolt\Flat Washer\Nut (DD), using the same method to attach others. See Fig.13. Need Assistance? Visit us at: samsclub.com/membersmarkhelp...
- Page 12 E1/E3 Fig.14 c. Attach Short Top Bar (D) to Lower Central Connector (B) with Bolt\Flat Washer M6*15(AA), attach Short Top Bar (D) to Connector (H) with Bolt\Flat Washer M6*15(AA), using the same method to attach others. See Fig.14 Need Assistance? Visit us at: samsclub.com/membersmarkhelp...
- Page 13 Fig.15 Attach Upper Central Connector (A) to Lower Central Connector (B) with Bolt\Flat Washer M6*15 (AA).at the same time screw the Hook (T) to the Upper Central Connector (A) and twist to tighten .See Fig.15. Fig.16 2-e.Attach the Roof Supports-Left Top (N1) /Roof Supports-Right Top (N2) / Roof Supports- Left Middle (O1) / Roof Supports-Right Middle (O2) to the Long Top Bar (C) with Bolt/Flat Washer M6*15(AA）.
- Page 14 P2/O3 Fig.17 Bolt\Flat Attach Roof Panel-Left Bottom (P1) to Top Bar (C1)/Short Top Bar (D) with Washer M6*15 (AA). Attach Roof Panel-Right Bottom (P2) to Top Bar (C1)/Short Top Bar (D) Bolt\Flat WasherM6*15 with (AA). Attach Roof Panel-Middle (O3) to Short Top Bar (D) Bolt\Flat Washer M6*15 with (AA).
- Page 15 Illustration 1 Illustration 2 Plastic Washer O1/D/O2/O3 ee Fig.18 IMPORTANT: ● Make sure each screw installed on this step is attached to a spacer (GG). ● Wait at the end of the installation of the roof panels before tightening all screws. If you do not wait and tighten from the beginning, you will not be able to correctly install all the roof panels.
- Page 16 Fig.19 3-b.Connect Edge Cover-Left(U)/ Edge Cover- Right (U1) to Lintel (E1/E2) with Bolt\Flat Washer , Connect Edge Cover-Middle to Short Lintel (E3) with M6*15(AA) Bolt\Flat Washer M6*15(AA). See Fig.19. Plastic Washer Fig.20 Fig.21 c. Place Top Panel Cover (Q)/(Q1) on the top of Top Bar (C)/(C1) and then insert Top Panel Cover (Q) into the gap between Upper Central Connector (A) and Long Top Bar (C).
- Page 17 E1/E2/E3 Fig.22 Fig.23 3-d.Hang Mosquito Net (S) on the Hanger (HH). See Fig.22. 3-e.Adjust position of gazebo and anchor posts to the ground by inserting Stakes (II) into each hole in each Base Plate. See Fig.23. Your gazebo is now completely assembled. Need Assistance? Visit us at: samsclub.com/membersmarkhelp...
-
Page 18: Warning
WARNING KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS TENT FABRIC. This tent meets the flammability requirements of CPAI-84. The fabric may burn if left in continuous contact with any flame source. The application of any foreign substance to the tent fabric may render the flame-resistant properties ineffective. -
Page 19: Warranty Information
Warranty Information This product component has a 1 year guarantee against defects in material and/or workmanship. If you have any questions regarding the warranty or spare / replacement parts, please call our toll-free number 1-800-847-7508 or email us at servicet@taipengchina.com NOTE: Please consider recycling all applicable packaging material. - Page 20 MADE IN CHINA Need Assistance? Visit us at: samsclub.com/membersmarkhelp Need Assistance? Visit us at: samsclub.com/membersmarkhelp...
