Member's Mark Lancaster GC-8976-5PC Assembly Manual

Member's Mark Lancaster GC-8976-5PC Assembly Manual

5pc fire chat set
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
DANGER:
FIRE OR EXPLOSION HAZARA
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, leave the area immediately.
4. After leaving the area, call your gas supplier or fire depatment.
Failure to follow these instructions could result in fire or explosion, which could cause
property damage, personal injury, or death.
Do not store or use gasoline or other flammable liquids vapors and liquids, in the vicinity of
WARNING:
this or any other appliance.
An LP cylinder not connected for use shall not be stored in the vicinity of this or any
other appliance.
Installation and service must be performed by a qualified installer, service agency, or the gas supplier.
DANGER
This appliance can produce carbon monoxide which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space such as a camper,
tent, car or home.
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING: If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury, or loss of life.
Assembly Manual
Lancaster 5pc Fire Chat Set
Model Number: GC-8976-5PC
WARNING:
For Outdoor Use Only.
CARBON MONOXIDE HAZARD

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Lancaster GC-8976-5PC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Member's Mark Lancaster GC-8976-5PC

Summary of Contents for Member's Mark Lancaster GC-8976-5PC

  • Page 1 Assembly Manual Lancaster 5pc Fire Chat Set Model Number: GC-8976-5PC DANGER: FIRE OR EXPLOSION HAZARA If you smell gas: 1. Shut off gas to the appliance. 2. Extinguish any open flame. 3. If odor continues, leave the area immediately. 4. After leaving the area, call your gas supplier or fire depatment. Failure to follow these instructions could result in fire or explosion, which could cause property damage, personal injury, or death.

  • Page 2: Important Safety Information

    Important Safety Information Please read all instructions carefully before assembling this furniture. For your safety, assembly by two or more adults is strongly recommended. Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. Hardware may loosen overtime.
  • Page 3 Components A..Table top..1 B..Table base..1 C..Burner Cover..1 G..8kg Glass beads..1 Hardware Hex Head Bolt Washer Hex Wrench M6x20mm Qty: 4 Qty: 1 Qty: 4 Need Assistance? Call us at 1-888-691-2824 from 8am to 5pm CST Monday-Friday...
  • Page 4 Step 1 Hex Head Bolt Washer Hex Wrench M6x20mm Qty: 4 Qty: 1 Qty: 4 Carefully place the table top (A) upside down on a non-abrasive surface. Assemble the table base(B) to the table top(A) with bolts (D) and washer (E) by using Allen wrench (F).
  • Page 5 Step 2 Carefully Place the glass beads (G) around the burner. Step 3 Place Burner Cover onto the fire bowl. NOTE: Glass beads is not included. When the fire pit is not in use and has cooled COMPLETELY, cover it with the Burner Cover. DO NOT USE BURNER COVER ON A HOT FIRE PIT OR WHEN IN USE.
  • Page 6 Loading the propane Open the door Carefully place the cylinder into the tank rack. Tighten the bolt to hold the cylinder in place Need Assistance? Call us at 1-888-691-2824 from 8am to 5pm CST Monday-Friday...
  • Page 7 Safety Warning • Children and adults should be alerted to the hazards of high surface temperatures and should stay away to avoid burns or prevent clothing ignition. • Young children should be carefully supervised when they are in the area of the appliance. •...
  • Page 8 Safety Warning • When the appliance is connected to a fixed-gas system, the installation must conform with local codes, or in the absence of local codes with the National Fuel Gas Code, ANS Z223.1 /NFPA54; International Fuel Gas Code, Natural Gas and Propane Installation Code, CSA B149.1; CAUTION or Propane Storage and Handling Code, B149.2, as applicable.

  • Page 9: Loading The Battery

    Loading the battery Unscrew the battery box, insert the negative electrode side of the battery into the bottom of the battery box Note: Please follow the above instructions to replace the battery when needed. Gas connection Fig.7 Connect the pressure regulator (4#) to the cylinder by rotating the knob(5#) clockwise until it is fully secured.

  • Page 10: Leak Check

    Leak Check Do not use an open flame to check for leaks. Do not smoke during testing. Do not test indoors. WARNING A leak check must be performed whenever the gas cylinder is replaced. 1. Make sure the gas cntrol knob (2#) is on the “OFF” position. Open access doors. 2.
  • Page 11 SHUTTING DOWN THE GAS 1. Turn the gas control knob (2#) to “OFF” to shut down applianca. 2. Turn the gas cylinder valve (7#) off when the gas appliance will not be in use. WARNING Do not try to cool glass beads with cold water right after shutting down the gas apploance or they will get crack.
  • Page 12 Gas Cylinder Required 20lb QCC OPD Barbecue Tank Diameter: 12.125 in. / 308 mm Height: 17.625 in. / 447.8 mm TW (Tare Weight): 16.6 lbs WC ( Water Capacity): 47.6 lbs Other cylinders may be acceptable for use with the appliance provided they are compatible with the appliance retention means;...
