SPECIFICATIONS

Model Name
Technical
Role of usage
Background picture
update
HDMI compliance
HDCP compliance
Video bandwidth
Output Video Support
Video support(USB)
Input Video Support
Video Format Support
Audio support
Control
Embedded video mixer
Input TMDS signal
Recording Mode
Recording Video
Format
ESD protection
Input
Output
HDMI connector
RS-232 connector
RJ-45 connector
Software compatibility
(not complete list)
(Video Capture
Function)
OS Support (Video
Capture Function)
Mechanical
Housing
Dimension Model
s Package
[L x W x H] Carton
Weight Model
Package
Power supply
Power consumption
Multi-View Seamless Presentation Matrix Switcher
Primary HDMI: Mix line in and HDMI in audio
RS-232/ Ethernet/ IR/ Front panel
YUY2 (USB3.0), MJPG (USB2.0/3.0)
Human body model — ±15kV [air-gap discharge] & ±8kV [contact
discharge]
4x HDMI + 2x Stereo RCA + 1x RS-232 + 1x RJ-45(Ethernet) + 1x
3x HDMI + 2x Stereo RCA + 1x USB + 1x 3.5mm
OBS Studio (Windows, Linux), AMCap (Windows), Potplayer
(Windows)¸ VLC (OS X, Linux), XSplit Boardcast (Windows), Skype
(Windows, OS X), Zoom (Windows), Hangout (Windows),
Windows 7 /8.1 /10, Mac and Linux OS
390 x 214 x 44mm[15.3" x 8.4" x 1.7" ]
519 x 263 x 75 mm [1'7" x 10.4" x 3"]
542 x 411 x 300 mm [1'8" x 1'3" x 11.8"]
MVPS-UHD42VC
Yes
HDMI 2.0a
HDCP 2.2 / 1.4
HDMI 600MHz [18Gbps]
Up to 4K2K@60 (4:4:4 8bits)
Up to 1080p60
Up to 4K2K@60 (4:4:4 8bits)
HDMI 2.0
Secondary HDMI: Bypass
Yes
1.2 Volts [peak to peak]
Software Compression
3.5mm (IR)
Type A [19-pin female]
DE-9 [9-pin D-sub female]
WE/SS 8P8C
TeamViewer (Windows)
Metal enclosure
1760g[3.8 lbs]
2703g[5.9 lbs]
12V DC
32 Watts [max]
