Octava HDMXA71-V1.3 Installation Manual

Hide thumbs Also See for HDMXA71-V1.3:

Advertisement

Quick Links

Download this manual See also: Installation Manual
Enlarged version
Description
Model
Version
HDCP
HDMI Inputs
HDMI Display Outputs
Optical Toslink Digital Audio Output
5.1 / 7.1 Analog Audio Output
Aux 5.1 / 7.1 Analog Audio Input
RS-232
Single Link Range
Video Data Rate
Vertical Frequency Scan Rate
Dimension
DC adapter (included)
Rackmount capable
Remote control (IR)
For Questions and support:
Email:
info@octavainc.com
URL: www.octavainc.com
copyright© 2010 Octava Inc. All rights reserved.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LL.C
All trademarks are the sole property of their respective companies
Specifications
HDMXA71-V1.3
1.3
Yes
4
2
1
1 ( 8ch.)
1 ( 8ch.)
1
480P, 720I/P, 1080IP
6.75 Gbps
24 / 50 / 60 Hz
15.07 x 4.12 x 1.67 inch
(382.9 x 104.7 x 42.3 mm)
5VDC, 2.5A
1RU, Rack mounts included
Infrared, discrete code.
Rev. D
V1.3
Installation Guide

Advertisement

loading

Related Manuals for Octava HDMXA71-V1.3

Summary of Contents for Octava HDMXA71-V1.3

  • Page 1 For Questions and support: Email: info@octavainc.com URL: www.octavainc.com copyright© 2010 Octava Inc. All rights reserved. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LL.C All trademarks are the sole property of their respective companies...

  • Page 2: Table Of Contents

    1 RU Rackmount : Table of contents The Octava 4x2 HDMI Matrix Switch analog 7.1can be installed in a 1 RU rack by simply installing the rack mounts included. 1. Application Diagram 2. Installation 3. Smart Scan 4. Configuring Smart Scan 5.

  • Page 3: Application Diagram

    3) Connect audio cables (optional) 4) Connect the DC power adapter Smart Scan Octava’s HDMI switch with Smart Scan saves you the hassle of fumbling with multiple remote controls. Simply power on the HDMI source you want to view and the HDMI switch will automatically switch to the...

  • Page 4: Configuring Smart Scan

    Configuring Smart Scan Changing EDID mode: The Smart Scan is disabled before shipment. It is recommended It is recommended to keep the EDID in the factory default MODE1. to leave Smart Scan disabled in most applications. If necessary, you may set to different EDID mode by following these instructions.

  • Page 5: Features

    EDID Configuration: Features:  Version 1.3 The Matrix can be configured to 3 EDID settings.  Full 6.75 Gbps, 1080P It is recommended to keep the EDID in the default factory mode 1.  4 HDMI inputs, 2 HDMI outputs Mode Video Audio...
  • Page 6 Infrared Manual Front View Input Switch Controls Detector Select Input ASCII Function Selection <STX>211<ETX> Select OUT A to Input port 1 <STX>212<ETX> Select OUT A to Input port 2 <STX>213<ETX> Select OUT A to Input port 3 <STX>214<ETX> Select OUT A to Input port 4 Aux Audio Source LED Aux Audio...
  • Page 7 RS232 Controls: The Octava HDMI Distribution Amp can be easily integrated with 3 Back Side Function Party control systems via RS232 control. The following shows the Connectors control protocol: HDMI Inputs Connect to video sources Baud rate=9600 HDMI Outputs A...

  • Page 8: Remote Control Guide

    Display B decrements to Turns ON HDMI switch. next available Input Put HDMI switch to Standby mode. Select Audio 7.1 Other Not used Octava’s Remote control uses discrete code so can be easily integrated with most Universal Remote Controls such as Logitech’s Harmony.
