H-10103
MOBILE FLOOR MIRROR
TOOLS NEEDED
Phillips
Allen Wrench
Screwdriver
(Included)
Mirror x 1
1. Attach crossbar to T-legs using lock washers
and bolts. Tighten using allen wrench. (See Figure 1)
NOTE: Bolts come pre-installed in crossbar.
Figure 1
Crossbar
PAGE 1 OF 6
1-800-295-5510
uline.com
Two Person Assembly
Recommended
T-Leg x 2
ASSEMBLY
T-Leg
Lock
Washer
Bolt
PARTS
Crossbar x 1
2. Insert casters into bottom of T-legs. (See Figure 2)
Figure 2
Para Español, vea páginas 3-4.
Pour le français, consulter les pages 5-6.
Lock Washer x 2
Bolt x 2
Caster
Caster x 4
Knob x 2
0522 IH-10103

Advertisement

loading

Related Manuals for U-Line H-10103

Summary of Contents for U-Line H-10103

  • Page 1 Para Español, vea páginas 3-4. Pour le français, consulter les pages 5-6. H-10103 1-800-295-5510 uline.com MOBILE FLOOR MIRROR TOOLS NEEDED Two Person Assembly Phillips Allen Wrench Recommended Screwdriver (Included) PARTS Lock Washer x 2 Caster x 4 Crossbar x 1...
  • Page 2 ASSEMBLY CONTINUED 3. With second person, align holes in mirror and T-legs. Secure and tighten with knobs. (See Figure 3) NOTE: Knobs should remain tight. To adjust, tilt mirror and it will remain at desired angle. Figure 3 Knob 1-800-295-5510 uline.com PAGE 2 OF 6 0522 IH-10103...

  • Page 3: Herramientas Necesarias

    H-10103 800-295-5510 uline.mx ESPEJO RODANTE DE PIE HERRAMIENTAS NECESARIAS Se Recomienda Armar Desarmador Llave Allen Entre Dos Personas de Cruz (Incluida) PARTES 2 Rondanas de 4 Ruedas Seguridad 1 Barra Transversal 2 Perillas 1 Espejo 2 Patas en T 2 Pernos...
  • Page 4 CONTINUACIÓN DEL ENSAMBLE 3. Con ayuda de otra persona, alinee los orificios en el espejo y las patas en T. Asegure y apriete con las perillas. (Vea Diagrama 3) NOTA: Las perillas deben permanecer ajustadas. Para ajustarlas, incline el espejo y permanecerá...

  • Page 5: Outils Requis

    H-10103 1-800-295-5510 uline.ca MIROIR DE SOL MOBILE OUTILS REQUIS Montage à deux Tournevis Clé Allen personnes recommandé cruciforme (inclus) PIÈCES Rondelle de Roulette x 4 blocage x 2 Barre transversale x 1 Bouton x 2 Miroir x 1 Pied en T x 2...
  • Page 6 MONTAGE SUITE 3. À deux, alignez les trous du miroir sur les pieds en T. Fixez et serrez le tout avec les boutons. (Voir Figure 3) REMARQUE : Les boutons doivent être fermement vissés. Il suffit d'incliner le miroir pour l'ajuster à l'angle souhaité. Figure 3 Bouton 1-800-295-5510...
