- Page 1 Instruction Manual Pharma-X ESE02197-EN 2012-11 Original manual...
-
Page 3: Table Of Contents
Table of contents The information herein is correct at the time of issue but may be subject to change without prior notice 1. Description ..................... 1.1. Safety precautions ................1.2. Recycling information ................1.3. Application ..................1.4. Design ..................... 2. Installation and initial start-up .............. -
Page 4: Description
The Alfa Laval Pharma-X is a compact point-of-use cooler for Water For Injection (WFI) or Purified Water (PW) systems. The Pharma-X exchanger is intended for points of use where water is drawn intermittently over a period of minutes or, at the most, an hour. -
Page 5: Design
WFI. It is completely drainable on the product side. The Pharma-X is supplied either as a naked heat exchanger or as a module. The module is built as a plug-and-play module for easy installation. It is delivered complete with insulation, cladding, valves and a pitot tube arrangement for connection to the WFI main loop. - Page 6 All product wetted parts in the Pharma-X are electropolished and the tubes are seamless. No risk of cross-contamination There are no internal welds in the Pharma-X, eliminating the risk of cross contamination between the product and the service medium. Drainable The Pharma-X is fully drainable on the product side, with no dead legs.
-
Page 7: Installation And Initial Start-Up
- If the Pharma-X heat exchanger is installed at a low point, it can be used as a draining point of water system. - If the heat exchanger is to be installed in a close loop system, non-return valves and appropriate safety valves should be fitted on the service side after the cooling water valve. - Page 8 2 Installation and initial start-up Figure 4. Pharma-X naked unit Figure 5. Pharma-X complete module A = Product outlet B = Service medium inlet C = Service medium outlet D = Product inlet. 5301-0008 Double Single TT311 & TT3151 TT312 & TT3152...
-
Page 9: The Pitot Tube Arrangement
2 Installation and initial start-up 2.3 The pitot tube arrangement In stand by mode, hot water from the main loop enters via the pitot tube, Fig. 7, and flows continuously through the point-of-use cooler and back to the main loop. The pitot tube can be turned 180 degrees if needed. -
Page 10: Initial Start-Up Procedure
2 Installation and initial start-up 2.4 Initial start-up procedure When taking a heat exchanger into operation, slowly start to circulate the cold medium only. Make sure that the entire cold side of the heat exchanger is completely flooded before closing the vents. The hot medium should then be gradually introduced until all passages are filled with hot fluid. -
Page 11: Operation
A sufficient flow is maintained in the Pharma-X by means of the pitot tube in the main loop, as long as the flow rate in the main loop is maintained. -
Page 12: Maintenance
When the SIP operation is completed, condensate is removed from the lowest drain points of the system. Make sure the product side of the Pharma-X is drained properly. Close the user point and drain points of the Pharma-X. Allow the system to cool. -
Page 13: Technical Data
5.1 Introduction The Pharma-X heat exchanger is available in six standard models with a length of 1.0 alternatively 1.5 meters, which gives an effective total tube length of 2, 3, 4 or 6 meters depending on model. The heat exchangers are configured as single pass or double pass. -
Page 14: Spare Parts List
Material 316 L stainless steel, seamless tubes Surface finish Ra< 0.5 µm. Electropolished on all product wetted parts Welding according to EN 287 and ASME IX Pharma-X module Insulation: Armaflex Cladding: 304L electropolished Weight of module 22-46 kg Design pressure... - Page 16 © Alfa Laval Corporate AB This document and its contents is owned by Alfa Laval Corporate AB and protected by laws governing intellectual property and thereto related rights. It is the responsibility of the user of this document to comply with all applicable intellectual property laws. Without limiting any rights related to this document, no part of this document may be copied, reproduced or transmitted in any form or by any means (electronic, mechanical, photocopying, recording, or otherwise), or for any purpose, without the expressed permission of Alfa Laval Corporate AB.
