C8051T60x-DK
RESET
P1
C8051T600 EDB
J8
F300
P2
Figure 1. Hardware Setup (Emulation Daughter Board Shown)

4. Software Setup

The included CD-ROM contains the Silicon Laboratories Integrated Development Environment (IDE), Keil software
8051 tools and additional documentation. Insert the CD-ROM into your PC's CD-ROM drive. An installer will
automatically launch, allowing you to install the IDE software or read documentation by clicking buttons on the
Installation Panel. If the installer does not automatically start when you insert the CD-ROM, run autorun.exe found
in the root directory of the CD-ROM. Refer to the ReleaseNotes.txt file on the CD-ROM for the latest information
regarding the CD contents.

5. Silicon Laboratories Integrated Development Environment

The Silicon Laboratories IDE integrates a source-code editor, source-level debugger and in-system Flash
programmer. The use of third-party compilers and assemblers is also supported. This development kit includes an
evaluation version of the Keil Software A51 macro assembler, BL51 linker and C51 'C' compiler. These tools can
be used from within the Silicon Laboratories IDE.
5.1. System Requirements
The Silicon Laboratories IDE requirements:
Pentium-class host PC running Windows 2000 or Windows XP.
One available USB port.
64 MB RAM and 40 MB free HD space recommended.
5.2. Assembler and Linker
A full-version Keil A51 macro assembler and BL51 banking linker are included with the development kit and are
installed during IDE installation. The complete assembler and linker reference manual can be found under the Help
menu in the IDE or in the "SiLabs\MCU\hlp" directory (A51.pdf).
2
J7
R13
D7
J10
D2
J3
J2
SILICON LABS
www.silabs.com
P3
D4
PWR
J1
DEBUG
D1
SW1
P0.6
P0.3
Rev. 0.1
AC Adapter

USB Cable
