Choosing Operation Mode Vrm; Choosing Operation Mode Iscsi Storage - Bosch DIVAR IP all-in-one 6000 Installation Manual

DIVAR IP all-in-one 6000
2.
3.
4.
Notice!
i
For further details, refer to the respective DIVAR IP all-in-one web-based training and to the
BVMS documentation.
You can find the training under:
8.4.2

Choosing operation mode VRM

To operate the DIVAR IP all-in-one system as a pure video recording system:
1.
2.
3.
Notice!
i
For further details, refer to the VRM documentation.
8.4.3

Choosing operation mode iSCSI storage

To operate the DIVAR IP all-in-one system as an iSCSI storage expansion:
1.
2.
3.
4.
Notice!
i
For further details, refer to the BVMS or Configuration Manager documentation.
Bosch Security Systems B.V.
Read and accept the license agreement, then click Install to continue.
The installation starts and the installation dialog box shows the installation progress. Do
not turn off the system and do not remove the storage media during the installation
process.
After all software packages have been installed successfully, the system restarts. After
restart, you are directed to the BVMS desktop.
On the BVMS desktop, click the desired application to configure your system.
On the DIVAR IP - System setup page, select the operation mode VRM and the desired
VRM version that you want to install, then click Next.
The VRM license agreement is displayed.
Read and accept the license agreement, then click Install to continue.
The installation starts and the installation dialog box shows the installation progress. Do
not turn off the system and do not remove the storage media during the installation
process.
After all software packages have been installed successfully, the system restarts. After
restart, you are directed to the Windows sign-in screen.
On the DIVAR IP - System setup page, select the operation mode iSCSI storage and the
desired iSCSI storage version that you want to install, then click Next.
The installation dialog box is displayed.
In the installation dialog box, click Install to continue.
The installation starts and the installation dialog box shows the installation progress. Do
not turn off the system and do not remove the storage media during the installation
process.
After all software packages have been installed successfully, the system restarts. After
restart, you are directed to the Windows sign-in screen.
Add the system as an iSCSI storage expansion to an external BVMS or VRM server using
BVMS Configuration Client or Configuration Manager.
www.boschsecurity.com/xc/en/support/training/
Installation manual
System setup | en
2022-10 | V02 | F.01U.407.903
37
