７．Other Cautions for Operation
7-1) Some of internal components of cylinder is made of iron. Protect them from direct splash of water etc.
If such a situation can't be avoided, contact SMC separately.
7-2) Before piping, perform flashing inside the piping to prevent intrusion of dust and cutting chip inside
the cylinder.
7-3) Do not give any damage including flaw and gouge on external face of cylinder tube. These damage
may be followed by the damage of soft wiper, packing and wearing and finally operating failure may
be caused.
８．Made to Order
The made to order of the rodless cylinder is available depending on operating environment and
conditions. The following shows relation between a certain operating environment or conditions and
applicable type of made to order.
Suffix
－Ｘ１１６
Air hydraulic
(Note)
－Ｘ１６０
High speed
(Note)
With hard chrome
plating on external face
－Ｘ３２２
of cylinder tube
CY1B6 interchangeable
－Ｘ１４６８
specification
With floating joint
－ＸＣ５７
(Note) These spec. are available only in both-side piping type (CY3R) with the port in axial direction
of cylinder.
Spec. Operative environment and conditions
Intermediate stop accuracy higher than
one obtained by pneumatic circuit is
required.
Operation at speed higher than
standard spec. is required.
(Speed without load: 1500mm/s)
Wear of external wearing needs to be
reduced (to improve durability of the
wearing).
For
mounting dimensions as CY1B6.
The time to connect cylinder with
guide on other axis (load side) needs
to be reduced.
request to have the
14
Applicable
cylinder tube I.D.
φ２５～φ４０
φ２０～φ４０
φ１５～φ４０
same
φ６
φ１５～φ４０
A
