Page 2: Start Here
• A network card installed with the NetBEUI protocol All other users must refer to Installation and Reference for the Model PS104/ PS105/PS110 Printer Server on the PS100 Series Print Server Resource CD for complete hardware and software installation instructions. -
Page 3: Package Contents
Customer Support Call your reseller or NETGEAR Customer Support in your area if there are any wrong, missing, or damaged parts. Keep the carton, including the original packing materials. Use them to repack the print server if you need to return it for repair. - Page 4 PRINTER LEDs NETWORK LEDs Print Server 10/100 Mbps On=Link; Blinking=Rx Link/Act Alert PRINTER NETWORK PWR LED Front Panel of the Model PS104 Print Server PRINTER LEDs NETWORK LEDs Print Server 10 Mbps On=Link; Blinking=Rx Link/Act Alert PRINTER NETWORK PWR LED...
- Page 5 The following table describes the activity of the LEDs on the PS100 Series print servers. Label Color Activity PWR (power) Green PRINTER, PRINTER 1, or PRINTER 2 Link/Act Green Blinking Alert Amber NETWORK (On Model PS104 and Model PS105) Link/Rx Green Blinking Amber Blinking (collision) NETWORK (On Model PS110) Link Green 100M Green...
- Page 6 Rear Panel The rear panel of the Model PS104 Print Server and Model PS105 Print Server has one parallel PRINTER port, and the rear panel of the Model PS110 Print Server has two parallel ports for printers (PRINTER 1 and PRINTER 2). These printer ports accept either printers or other parallel devices such as a plotter.
-
Page 7: Typical Applications
Model PS105 Print Server PRINTER Limited to 3 m in length Model PS104 Print Server PRINTER Limited to 3 m in length Model PS104/PS105/PS110 Print Server Installation Guide NETWORK 12VDC 1.2A Normal/Uplink NETGEAR Model EN108 hub EN108 10 BASE-T HUB... -
Page 8: Install The Print Server
Install the Print Server You can place the print server on a desktop or any flat surface. To save work space, you can also mount the print server with Velcro strips on the side of a printer. Connect the Printer Cables Connect a cable (not provided) from the printer to the parallel PRINTER port on the print server. -
Page 9: Verify Power
• The green Pwr (power) LED on the front panel is on. • On the Model PS104 and Model PS105 print servers, the green Link/Rx LED on each connected network port is on. • On the Model PS110 Print Server, the Link LED on the connected network port is on. -
Page 10: Install And Set Up
6. Click on “Next” when the “NETGEAR Print Server Software Installation” window opens. 7. Click on “Next” to install the NETGEAR Print Server program in the Program Files folder. 8. Click on “Next” to title the program folder “FirstGear for Print Server”... - Page 11 “Refresh” button, which will initiate the PC browse again for a port. 4. Click on the printer port you want to use with the print server, and click on “Add.” 5. Click on “No” when asked if there is an Epson Stylus COLOR printer attached to the port, and continue on to step 6.
- Page 12 “Next.” If you have not installed the driver, do so now as prompted by the screen. 3. Click on the “PSxxxxxxx_P1 (or PSxxxxxx_P2) Netgear Print Server” that you selected in step 6 when the next “Add Printer Wizard”...
-
Page 13: Troubleshooting
Category 5 cables. With 10BASE-2 connections through the BNC port on the Model PS105, make sure the cable meets the specifications as outlined in Installation and Reference for the Model PS104/ PS105/PS110 Print Server on the PS100 Series Print Server Resource CD. -
Page 14: Technical Specifications
CSA certified (CSA 22.2 #950) TUV licensed (EN 60 950) T-Mark Warranty Information Print server Power adapter Model PS104/PS105/PS110 Print Server Installation Guide Four 10BASE-T network ports (RJ-45) Four 10BASE-T network ports (RJ-45) and one BNC port One 10/100BASE-T network port (RJ-45) - Page 15 Certificate of the Manufacturer/Importer It is hereby certified that the Model PS104, Model PS105, or Model PS110 print server has been suppressed in accordance with the conditions set out in the BMPT-AmtsblVfg 243/1991 and Vfg 46/1992.
- Page 16 EN 55 022 Statement This is to certify that the Model PS104, Model PS105, or Model PS110 print server is shielded against the generation of radio interference in accordance with the application of Council Directive 89/336/EEC, Article 4a. Conformity is declared by the application of EN 55 022 Class B (CISPR 22).
- Page 17 NETGEAR, Inc. A Bay Networks Company 4401 Great America Parkway Santa Clara, CA 95054 USA Phone: 888-NETGEAR http://www.NETGEARinc.com *M1-PS100NA-1* Model PS104/PS105/PS110 Print Server Installation Guide...
