Specifications

Function Range
AC Current 60.00 AAC
50/60 Hz
600.0 AAC
True RMS
AC Voltage 6.000 VAC
True RMS
60.00 VAC
600.0 VAC
DC Voltage 600.0 mVDC
6.000 VDC
60.00 VDC
600.0 VDC
Resistance
600.0Ω
6.000kΩ
60.00kΩ
600.0kΩ
6.000MΩ
60.00MΩ
Capacitance 40.00nF
400.0nF
4.000µF
40.00µF
400.0µF
4000µF
Frequency 10Hz to 10kHz
Sensitivity: 15Vrms
Duty Cycle 0.5% to 99.0%
Pulse width: 100μs to 100ms, Frequency: 10Hz to 10kHz
Temperature -4 to - 1400°F
Type K
-20 to 760°C
Specification does not include probe accuracy
www.ponpe.com
Accuracy
Resolution
(% of reading + digits)
0.01A ±(2.8% + 8 digits)
0.1A ±(3.0% + 8 digits)
0.001V
±(1.8% + 8 digits)
0.01V
0.1V
0.1mV
0.001V
±(1.5% + 2 digits)
0.01V
0.1V
±(1.0% + 4 digits)
0.1Ω
0.001kΩ
±(1.5% + 2 digits)
0.01kΩ
0.1kΩ
±(2.5% + 3 digits)
0.001MΩ
±(3.5% + 5 digits)
0.01MΩ
0.01nF ±(4.0% + 20 digits)
0.1nF
0.001µF ±(3.0% + 5 digits)
0.01µF
0.1µF ±(4.0% + 10 digits)
1µF ±(5.0% + 10 digits)
0.01Hz to 0.01khz ±(1.5% + 2 digits)
0.1% ±(1.2% + 2 digits)
0.1° <800°; 1° >800°
±3% reading + 9°F/5°C
0.1° <400°; 1° >400°
11 MA620 V2.1 07/08
