Specifications

General Specifications
Display
Status indicators
Microphone
Measurement Units
Measurement ranges
Frequency range
Frequency weighting
Time Response
Calibration
Datalogger Sampling Rate
Memory Card
Display update rate
Data Output
AC Output
Applicable Standards
Operating Temperature
Operating Humidity
Auto Power OFF
Power Supply
Power Consumption
Weight
Dimensions
Note: Specifications tested at 23°C ± 5°C and under an environmental RF Field Strength lower
than 3 V/M and a frequency lower than 30 MHz
Copyright © 2011 Extech Instruments Corporation (a FLIR company)
All rights reserved including the right of reproduction in whole or in part in any form
52 x 38mm (2 x 1.5") Backlit LCD
Out-of-range (----) and low battery
12.7mm (0.5") electret condenser microphone
Decibels
Automatic and Manual (30 to 80, 50 to 100, and 80 to 130dB)
31.5Hz to 8KHz
Selectable 'A' or 'C'
Fast (125ms) and Slow (1sec) selectable
Calibration potentiometer for use with external (optional) calibrator
AUTO: 1, 2, 5, 10, 30, 60, 120, 300, 600, 1800, 3600
seconds. Note that a one (1) second sampling rate can
cause some data loss on slower computers.
MANUAL: Set the sampling rate to '0'
SD Card type (1GB to 16GB size)
Approx. 1 second.
RS-232 / USB PC computer interface
0.5V AC rms full scale, 600ohm output impedance
IEC61672-1: 2002 Class 2; ANSI S1.4:1983 Type 2,
0 to 50°C (32 to 122°F)
85% R.H. max.
After 10 minutes of inactivity (can be disabled)
Six (6) 1.5 VDC batteries (optional 9V AC adaptor)
Normal operation (backlight and datalogger OFF): approx. 12mAdc
With backlight OFF and datalogging ON: approx. 51mAdc
With backlight ON add approx. 30mAdc
428g (0.94 lbs.) including batteries
Main instrument: 250 x 73 x 47.5mm (9.8 x 2.9 x 1.9")
Microphone: 12.7mm (0.5") outer diameter
