SCHUBERTH E2 Manual page 75

C. THE HELMET
Fitting
1. Remove the visor from the helmet.
2. Use the notch to help position one side of the
anti-fog lens on one of the eccentric holding
pins. Make sure that the silicone seal is facing
the visor.
3. Carefully bend the visor just enough that
the notch is guided onto the other eccentric
holding pin on the opposite side of the anti-fog
lens. To do this, you will need to bend the end
of the anti-fog lens into a slight S-shape.
4. Checking the correct application of the
anti-fog lens, by trying to slide a piece of
paper between the visor and the anti-
fog lens. In case it gets between the
two, please adjusting the pins in order to
increase the strain of the anti-fog lens.,
5. Ensure that the anti-fog lens sits snugly
on the visor. If this is not the case, the
tension on the anti-fog lens can be increased
or decreased, as necessary, by turning the
eccentric holding pin.
