COMPONENT LAYOUT - FLOOR MOUNTED UNITS
Figure 25.1 - Exploded View
Figure 25.2 - Component Layout
Control
Panel
Blower
Motor
Freeze Stat
(Optional)
Face &
Bypass
Damper
Actuator
(Optional)
Field
Installed
Piping
Outside Air/Return Air
Face & Bypass
Filters
Blowers
Electrical Box with Power
Damper Actuator
Damper
Connection, Disconnect Switch and
(Optional)
(Optional)
3-Speed Fan Switch
14-500.5
25
