- Page 1 User Manual PowerFlex 25-COMM-P PROFIBUS DPV1 Adapter...
-
Page 2: Getting Started
Provides a clean ground for the communication bus cable shields. CS1 or CS2 should be connected to a clean ground or PE ground on the drive. PROFIBUS DB9 PROFIBUS connector for the PROFIBUS Female connector network cable. Rockwell Automation Publication 520COM-UM004A-EN-E - November 2013... - Page 3 These parameters reside on the adapter. • Host parameters are used to configure the drive, including the datalink configuration for the datalinks used by the adapter. These parameters reside on the drive. Rockwell Automation Publication 520COM-UM004A-EN-E - November 2013...
- Page 4 You can obtain a free copy by downloading it or requesting a DVD. Both options are available at http://ab.rockwellautomation.com/Programmable-Controllers/Connected-Components-Workbench-Software. Controller configuration software RSLogix 5000 (version 20 or greater) or Logix Designer (version 21 or greater) A computer connection to the PROFIBUS DPV1 network Rockwell Automation Publication 520COM-UM004A-EN-E - November 2013...
-
Page 5: Specifications
Temperature -10...50 °C (14...149 °F) Operating -40...85 °C (-40...185 °F) Storage Relative Humidity -5...95% noncondensing See the PowerFlex 520-Series Adjustable Frequency AC Drive User Manual, Regulatory Compliance publication 520-UM001 for regulatory compliance information. Rockwell Automation Publication 520COM-UM004A-EN-E - November 2013... -
Page 6: Adapter Parameters
0 = Ltl Endian Displays the byte alignment for the network data as selected 1 = Big Endian with the Byte Swap switch 8 (see Node Address Switch Settings Type: Read Only on page 15). Rockwell Automation Publication 520COM-UM004A-EN-E - November 2013... - Page 7 When commissioning the drive, verify that your system responds correctly to various situations (for example, a disconnected drive). Rockwell Automation Publication 520COM-UM004A-EN-E - November 2013...
- Page 8 • Device parameter 11 [Comm Flt Action] is set to 4 “Send Flt Type: Read/Write Cfg” and the I/O Communication is disrupted. Reset Required: • Device parameter 12 [Idle Flt Action] is set to 4 “Send Flt Cfg” and the controller is in Program Mode. Rockwell Automation Publication 520COM-UM004A-EN-E - November 2013...
- Page 9 3 = Drive 3 Actv Drive 1 Actv Digit 2 4 = Drive 4 Actv Drive 2 Actv Digit 3 Type: Read Only Drive 3 Actv Digit 4 Drive 4 Actv Digit 5 Rockwell Automation Publication 520COM-UM004A-EN-E - November 2013...
- Page 10 (2) A Not Stop condition (logic bit 0 = 0) must first be present before a 1 = Jog condition will jog the drive. A transition to a “0” will stop the drive. (3) To perform this command, the value must switch from “0” to “1.” Rockwell Automation Publication 520COM-UM004A-EN-E - November 2013...
- Page 11 1 = Controlled by Active Com Parameters 0 = Not Locked 1 = Locked Digital Input 1 Status – Digital Input 2 Status – Digital Input 3 Status – Digital Input 4 Status – Rockwell Automation Publication 520COM-UM004A-EN-E - November 2013...
- Page 12 1 = Sync Hold Sync Ramp 0 = Not Sync Ramp 1 = Ramp Sync Traverse 0 = Traverse Off 1 = Traverse On Traverse Decel 0 = Not Traverse Decel 1 = Traverse Decel Rockwell Automation Publication 520COM-UM004A-EN-E - November 2013...
