DLP-539: Detailed Level Procedures
Page 6 of 7
Table B – MDS Server Circuit Pack Slot Association (Odd Shelves)
Shelf Shelf
No. Conn.
1 (Odd) J101
J102
J103
J104
Note: The colors specified in this cable are true only if the transmission cable uses color code 4.
Pins MDS Slot
R,T CU 0
1,26 1
2,27
9,34 3
10,35
17,42 5
18,43
25,50 7
1,26
8,33 9
9,34
16,41 11
17,42
24,49 13
25,50
7,32 15
8,33
15,40 17
16,41
23,48 19
24,49
6,31 21
7,32
14,39 23
15,40
P191/P192 ED-7C723-35, G17
Connector Pins R,T
OUT 1,26
IN 1,26
OUT 2,27
IN 2,27
OUT 3,28
IN 3,28
OUT 4,29
IN 4,29
OUT 5,30
IN 5,30
OUT 6,31
IN 6,31
OUT 7,32
IN 7,32
OUT 8,33
IN 8,33
OUT 9,34
IN 9,34
OUT 10,35
IN 10,35
OUT 11,36
IN 11,36
OUT 12,37
IN 12,37
363-208-001
Issue 9, April 1998
DSX-1 Colors
(Note)
BL-W, W-BL
BL-W, W-BL
O-W, W-O
O-W, W-O
G-W, W-G
G-W, W-G
BR-W, W-BR
BR-W, W-BR
S-W, W-S
S-W, W-S
BL-R, R-BL
BL-R, R-BL
O-R, O-R
O-R, O-R
G-R, R-G
G-R, R-G
BR-R, BR-R
BR-R, BR-R
S-R, R-S
S-R, R-S
BL-BK, BK-BL
BL-BK, BK-BL
O-BK, BK-O
O-BK, BK-O
