DLP-616: Channel Unit Installation
Page 6 of 8
18. Did all alarms clear?
If YES, then STOP. YOU HAVE COMPLETED THIS PROCEDURE.
If NO, then continue with Step 19.
19. Clear alarms using TAP-104.
Table A – Possible DSX-1 Provisioning Combinations and CIT Commands for NBS (R4.4 and Later)
Provisioned Mode of Each DSX-1
Provisioning Feeding a V-DT in the NBS
Combination (Upper Shelf — Slots 1-6
Number Lower Shelf — Slots 7-12) (Note)
*
1 DSX-1 A — Quad, 12 lines
DSX-1 B — Quad, 24 lines
†
2 DSX-1 A — Quad, 24 lines
DSX-1 B — Octet, 24 lines
DSX-1 D — Octet, 24 lines
‡
3 DSX-1 A — Octet, 24 lines
DSX-1 C — Octet, 24 lines
DSX-1 B — Quad, 24 lines
4 DSX-1 A — Octet, 24 lines
DSX-1 C — Octet, 24 lines
DSX-1 B — Octet, 24 lines
DSX-1 D — Octet, 24 lines
Note: For the octet mode of operation, DS1-A is paired with DS1-C and DS1-B is paired with DS1-D.
* DS1-C and DS1-D are not used in this configuration.
† DS1-C is not used in this configuration.
‡ DS1-D is not used in this configuration.
CIT Commands
ed-dt::dt-1-3:::nbs:lines =12,dtm= quad;
ed-dt::dt-1-5:::nbs:lines =24,dtm= quad;
ed-dt::dt-1-1:::nbs:lines =24,dtm= quad;
ed-dt::dt-1-5:::nbs:lines =24,dtm= octet;
ed-dt::dt-2-13:::nbs:lines= 24,dtm =octet;
ed-dt::dt-1-5:::nbs:lines =24,dtm= octet;
ed-dt::dt-2-13:::nbs:lines= 24,dtm =octet;
ed-dt::dt-1-1:::nbs:lines =24,dtm= quad;
ed-dt::dt-1-5:::nbs:lines =24,dtm= octet;
ed-dt::dt-2-13:::nbs:lines= 24,dtm =octet;
ed-dt::dt-3-7:::nbs:lines =24,dtm= octet;
ed-dt::dt-2-1:::nbs:lines =24,dtm= octet;
363-208-001
Issue 9, April 1998
