Furn Mill CALIFORNIA HOCTA00079 Assembly Instruction

Coffee table

ASSEMBLY INSTRUCTION

PRODUCT CODE:-

CALIFORNIA COFFEE TABLE

HOCTA00079,HOCTA00014

Requirement for Assembly

ASSEMBLY RATING

The Assembly Rating is a 5-point

system that shows the degree of effort

needed in assembling a specific

product (with 1 being easy and 5 being

difficult).

For most products, two

persons are recommended.

EASY

DIFFICULT

2 PERSONS RECOMMENDED

1/5

Table of Contents

Do you have a question about the CALIFORNIA HOCTA00079 and is the answer not in the manual?

Page 1 ASSEMBLY INSTRUCTION PRODUCT CODE:- CALIFORNIA COFFEE TABLE HOCTA00079,HOCTA00014 Requirement for Assembly ASSEMBLY RATING The Assembly Rating is a 5-point system that shows the degree of effort needed in assembling a specific product (with 1 being easy and 5 being difficult). For most products, two persons are recommended.
Page 2 HARDWARE DETAIL ASSEMBLED PRODUCT HARDWARE QTY. Allen Bolt 8 pcs M8x35mm Allen Key 1 pcs No.5 8 pcs Dowel...
Page 3 STEP 01 Fix the PART-B and PART-C in the slot as shown in Fig. STEP 02 Flip the PART-A(Top) and last assembled part on carpet and fix with dowel & allen bolt of M8x35mm using allen key at position A1,A2,A3 and A4 as shown in Fig.
Page 4 STEP 03 Now place PART-D(Bottom) with last assemble part and fix with dowel & allen bolt M8X35mm using allen key at position B1,B2,B3 &B4 as shown In Fig. STEP 04 Flip the table and your table is ready to use.
Page 5 Thank you for your purchase! We hope you will enjoy your new product for many years to come. Our commitment to providing quality products does not simply end when a purchase is made. We stand behind our products and will provide any support needed in order for you to fully enjoy your purchase. Your satisfaction is the greatest recognition we could have.

California hocta00014
