  • Page 1 Vision Fire & Security LaserPLUS Product Guide October 13, 2005 Part:19145...
  • Page 3 2004 VFS International Pty Ltd ACN 100 259 381 Disclaimer The manufacturer reserves the right to change designs or specifications without obligation and without further notice. VESDA, LaserTEKNIC, LaserPLUS, LaserSCANNER, LaserCOMPACT, LaserFOCUS, VESDAnet, VESDAlink, ASPIRE, ASPIRE2, AutoLearn, VSM, VConfig, InfoWORKS, PROACTIV, PRECISION, VSC, ADPRO, FastTrace, FastVu, FastScan, Axiom, PRO, Amux, Video Central, Millbank and VxLAN are brands and trade marks used under license by the distributor.
  • Page 4 This VESDA product incorporates a laser device and is classified as a Class 1 laser product that complies with FDA regulations 21 CFR 1040.10.
  • Page 5 You must check that ASPIRE2 approves alterations before making any changes. ASPIRE2 is available from your VESDA ASD distributor. AS1603.13 AS1603.13: VESDA detectors are not compliant with the pressure testing in this standard. FM Approved Applications The product must be powered from VPS-100US-120, VPS-100US-220 or VPS-220 only.
  • Page 6 VESDA LaserPLUS Product Guide ®...

  • Page 7: Table Of Contents

    LaserPLUS Dimensions ......................10 LaserPLUS Ratings and Approvals ..................11 Default Settings ........................12 Relays ...........................13 LaserPLUS relay Assignments and Conditions to Change States ........14 Relays default settings ......................14 General Purpose Input (GPI) Functions ................15 Mounting the LaserPLUS ......................16 Securing the mounting bracket .....................16 Mounting the LaserPLUS in Normal Orientation ...............17...
  • Page 8 VESDA LaserPLUS Product Guide ® Spare Parts ........................... 32...

  • Page 9: Scope

    1.2 Introduction to the LaserPLUS The LaserPLUS is an aspirating smoke detector providing very early warning of fire conditions by drawing air samples through an air sampling pipe network. The detector chamber can detect presence of smoke at very low concentrations.
  • Page 10 Some air is filtered and: flows into the chamber for testing is filtered a second time, then used to flush the chamber with ultra clean air All air is then vented Figure 1 - Operation and internal air flow of a LaserPLUS...

  • Page 11: Laserplus Configurations

    LaserPLUS Product Guide ® LaserPLUS Configurations The modular options available with a LaserPLUS are: • Fire and OK LEDs (FOK) • LCD Programmer • LaserPLUS Display Module Figure 2 - VLP-012 VESDA LaserPLUS installed with LCD Programmer and Display Module...

  • Page 12: Display Module

    ® Display module The LaserPLUS Display Module is mounted either on the detector front cover or at a remote location in a remote mounting box or a 19” subrack. It provides a visual representation of the smoke levels and the four alarm stages for the assigned detector. An array of fault LEDs illuminate in different configurations to report Urgent, Minor, Zone and System faults.
  • Page 13 SYSTEM: A fault affecting the network to which the Display Module is connected ZONE: A fault in the VESDA Zone monitored by the Display Module POWER: A fault in the power supply if the GPI function is used NETWORK: A communications fault on VESDAnet...

  • Page 14: Vesda Lcd Programmer

    A hand-held model is also available. The hand- held model is connected to the VESDAnet socket on the termination card of the detector. For a detailed description and use of the LCD Programmer please refer to the VESDA LCD Programmer Manual.

  • Page 15: Laserplus Components

    VESDA LaserPLUS Product Guide ® LaserPLUS Components Legend Front cover Pipe inlet manifold Termination card Air filter Blank card protecting processor card Aspirator Chassis with laser detector chamber Mounting box/enclosure Figure 6 - An exploded view of the detector...

  • Page 16: Laserplus Product Information

    VESDA LaserPLUS Product Guide ® 1.4 LaserPLUS Product Information Product Specifications Supply Voltage 18 to 30 VDC Power Consumption @24 VDC • LaserPLUS with Blank Normal: 5.8 W Plates 3,000rpm Alarm On: 6.24 W • LaserPLUS with Blank Normal: 6.72 W Plates @ 4,200rpm Alarm On: 7.2 W...
  • Page 17 Event reporting via VESDAnet or event log Table 1 - LaserPLUS Detectors Specifications Note: For operating the LaserPLUS Detector outside the parameters mentioned above please contact VESDA Technical Support Note: UL Mode: Factory Default = ON (Fire 2 set to 12% obs/m 4% obs/ft. to comply with...

  • Page 18: Laserplus Dimensions

    VESDA LaserPLUS Product Guide ® LaserPLUS Dimensions Figure 7 - LaserPLUS dimensions - rear view...

  • Page 19: Laserplus Ratings And Approvals

    VESDA LaserPLUS Product Guide ® Figure 8 - LaserPLUS dimensions LaserPLUS Ratings and Approvals Figure 9 - Example of an approvals label...

  • Page 20: Default Settings

    VESDA LaserPLUS Product Guide ® Default Settings Range Access Parameter Default Value Level Minimum Maximum Event Log - Events • Smoke Level Enabled • Alarms Enabled • Faults Enabled • User Action Enabled Fire 2 Threshold 2% obs/m 0.625% 0.02% obs/m 20.% obs/m...

  • Page 21: Relays

    VESDA LaserPLUS Product Guide ® Range Access Parameter Default Value Level Minimum Maximum Air flow Thresholds: • High Urgent 130% 105% 200% • High Minor 120% 105% 200% • Low Minor • Low Urgent • Delay 0 seconds 0 seconds...

  • Page 22: Laserplus Relay Assignments And Conditions To Change States

    VESDA LaserPLUS Product Guide ® LaserPLUS relay Assignments and Conditions to Change States Relays 1, 2, 4, 5 and 7 are fully configured. (For example, relay 5 could be configured to de- energize on Alert) Note: Assignments to relays 3 and 6 are fixed to Urgent Fault and Fire 1 respectively.

  • Page 23: General Purpose Input (Gpi) Functions

    VESDA LaserPLUS Product Guide ® General Purpose Input (GPI) Functions The input terminal requires a voltage supply between 5V and 30 VDC to operate. The input is isolated from the system by an opto-coupler device. Connect the GPI + terminal to the positive output and the GPI - terminal to the ground output of the external device.

  • Page 24: Mounting The Laserplus

    LCD Programmer choose Isolate Disabled from the Button Lockout menu. 1.5 Mounting the LaserPLUS The LaserPLUS detector can be mounted onto the wall or on any suitable secure surface using the mounting bracket. It is strongly recommended that the detector is mounted on to the mounting bracket included with the packaging.

  • Page 25: Mounting The Laserplus In Normal Orientation

    Use the four keyhole slots to secure the mounting box to a flat surface, ensuring that it is horizontally straight. Re-install the chassis into the mounting box. Carefully re-connect the looms and complete the cabling prior to closing the front cover. See Internal Wiring for LaserPLUS on page 30...

  • Page 26: Recess Mounting Kit

    VESDA LaserPLUS Product Guide ® Note: The laser detector chamber, head processor card and flow sensors are factory calibrated as a matched set. Separating the set and replacing it with components from another set may cause the detector to malfunction, requiring re-calibration at the factory.

  • Page 27: Connecting The Laserplus To The Pipe Network

    VESDA LaserPLUS Product Guide ® 1.6 Connecting the LaserPLUS to the Pipe Network Inlet Pipes The inlets in the pipe inlet manifold are designed to receive a standard pipe of 25 mm (1 in) OD. A 25 mm to 1.050 inches adaptor to fit the pipe inlet manifold is included for all shipments to USA.

  • Page 28: Managing The Exhaust Air

    VESDAnet cables are terminated at the VESDAnet A and B Terminals on the termination card. Communication wires from another VESDA device are brought into the detector at one terminal and looped out to another device on VESDAnet from the other terminal. It is necessary to maintain the polarity throughout the network.

  • Page 29: Connections For Gpi

    LaserPLUS Product Guide ® The LaserPLUS detector is shipped with the VESDAnet A and B terminals looped. If the detector is not to be networked with other devices, then do not disturb this loop. Remove this loop to connect the detector to the VESDAnet.

  • Page 30: Typical Wiring To Fire Panel (Facp)

    Figure 20 - Typical wiring to a fire panel with EOL Wiring To an Address Loop Module. This wiring example is for wiring VESDA detectors to a typical Address Loop module 3 output 1 input. These are example drawings. Refer to the appropriate product manual for the exact wiring details of the third party equipment.

  • Page 31: Power Source

    1.9 Back Up Battery The power supply for the LaserPLUS detector is switched to a back up battery in the event of a mains power supply disruption. The size of the back up battery is determined by local standards and codes, the total power required by the system, back up time required, allowance for reduction in capacity with age and expected temperature variations.
  • Page 32 VESDA LaserPLUS Product Guide ® Normal loads @ 24 V DC Full alarm load @ 24 V DC Equipment Load mA Qty. Total Load mA Qty. Total Detector @ 3000rpm Detector @ 3500rpm Detector @ 4000rpm Detector @ 4200rpm Integral Display...

  • Page 33: Powering Up

    ® Note: If intelligent VESDA power supply is fitted it will report power failures (F15) on VESDAnet. VLP & VLS with GPI terminals connected will maintain their aspirator speed for an hour after the loss of mains power. After which, the aspirator speed will be limited to 3000 rpm to conserve power.

  • Page 34: Installation Checklist

    VESDA LaserPLUS Product Guide ® Installation Checklist Site Name Address Detector Serial Number(s) Name of Installer Signature Date Perform the following checks listed below to ensure that all the necessary items are completed before handing over to a commissioning engineer.

  • Page 35: Preliminary Systems Check

    Caution: While a VESDA Zone is isolated, no fire warnings will be issued by the LaserPLUS detector and any fire will go undetected. Prior to any maintenance or testing: Inform appropriate supervising authority about the risk associated with isolating a VESDA Zone.

  • Page 36: Replacing The Chassis/Air Inlet Pipe Manifold

    VESDA LaserPLUS Product Guide ® Replacing the chassis/Air Inlet Pipe Manifold Isolate unit by pressing the Isolate button on the zone configured display or by selecting Isolate Zone from the Zone menu in VConfig Pro or VSM3. This isolates the outputs from the unit to a Fire Alarm Control Panel.
  • Page 37 VESDA LaserPLUS Product Guide ® Figure 25 - Remove the chassis Caution: Care must be taken not to damage the cable running to the manifold. Note: The chassis consists of the Detection Chamber, head processor card and flow sensors. These are factory calibrated as a matched set and must not be separated.

  • Page 38: Internal Wiring For Laserplus

    VESDA LaserPLUS Product Guide ® Internal Wiring for LaserPLUS The table below provides the cable loom interconnecting details inside the detector. Use the look up table in conjunction with the attached circuit diagram to assist with maintenance. Connector Name From...
  • Page 39 VESDA LaserPLUS Product Guide ® Note: Do not attempt to force the connector into its socket. If there is any difficulty, reverse the orientation of the connector before inserting again. Legend Detector chamber Programmer module Display module Detector terminal card...
  • Page 40 VSP-011 Recess Mounting Kit for VLP VSP-013 Detector Cover Assembly complete with EMC shields VSP-014 7-relay termination card VSP-015 LaserPLUS detector Aspirator Assembly VSP-019 Filter Cover VSP-100 Blank Plate with FOK LEDs and Logo If Applicable If Applicable VSP-200 Blank Plate, EMC Painted, without Logo...
  • Page 41 ......27 Clean Sampling Point ..........5 Action ......... 13 Communications ........14 Action relay . 19 Connecting LaserPLUS to Pipe Network ......... 12 Action Threshold .......... ii Conventions ......27 Air flow normalizing ......13 Air flow Thresholds .......... 5...
  • Page 42 VESDA LaserPLUS Product Guide ® ..........5 Filter fault ........27 Filter Inspection ......13 Filter Service Interval ......2 Laser detection chamber ........... 5 Fire 1 LaserPLUS .......... 14 Fire 1 relay ........7 Components ........ 12 Default settings ........
  • Page 43 Relay Set ..... 15 Use Night-time Threshold ..........8, 13 Relays ....... 14 Relays - default settings remote location Display Module - Introduction to LaserPLUS ..........6 ........... 4 VESDAnet Detector ......21 ........25 VESDAnet closed Loop Reset Button ......
  • Page 44 VESDA LaserPLUS Product Guide ®...
