VESDA VLS-XXX Product Manual

Laserscanner
Hide thumbs
Table of Contents

Advertisement

Quick Links

Vision Fire & Security
LaserSCANNER
Product Guide
November 10, 2004
Part: 19147

Advertisement

Table of Contents
loading

Related Manuals for VESDA VLS-XXX

Summary of Contents for VESDA VLS-XXX

  • Page 1 Vision Fire & Security LaserSCANNER Product Guide November 10, 2004 Part: 19147...

  • Page 3: Fcc Compliance Statement

    System. ® To the extent by law that any limitation or exclusion can not apply, the total liability of VFS in relation to the VESDA System is limited to: (i) in the case of services, the cost of having the services supplied again; or (ii) in the case of goods, the lowest cost of replacing the goods, acquiring equivalent goods or having the goods repaired.
  • Page 4 VESDA Product Warranty Conditions VFS International Pty Ltd (VFS) warrants that new VESDA products (excluding consumable items) will conform to its published specifications and remain in good working order during the warranty period of 24 (twenty four) months from the date an invoice is issued by VFS to its distributor.
  • Page 5 Safety Label This VESDA product incorporates a laser device and is classified as a Class 1 laser product that complies with FDA regulations 21 CFR 1040.10. The laser is housed in a sealed detector chamber and contains no serviceable parts. This laser emits invisible light and can be hazardous if viewed with the naked eye.
  • Page 6 VESDA LaserSCANNER Product Manual ®...

  • Page 7: Table Of Contents

    Wiring Connections ........................25 The Termination Card ......................25 VESDAnet Terminals ......................26 Connections for GPI ......................27 Power Source ..........................28 Back Up Battery Power ......................... 28 Starting Up ............................. 30 Preliminary Systems Check ......................30 Maintaining the VESDA LaserSCANNER ..................31...
  • Page 8 VESDA LaserSCANNER Product Manual ® Replacing the chassis/Air Inlet Pipe Manifold ............... 32 Internal Wiring for LaserSCANNER ..................34 Spare Parts ........................... 36...

  • Page 9: Scope

    You will also find instructions on installing, cabling and powering up the detector. This manual is for anyone involved with the design, maintenance and purchasing of a VESDA system. It is assumed that anyone using this manual has knowledge and the appropriate certification from the local fire and electrical authorities.
  • Page 10 VESDA LaserSCANNER Product Manual ® Each pipe inlet in the manifold has a valve that can open or close the flow of air to the pipe. The scan function controls the opening and closing of the valves to detect the smoke carrying pipe.

  • Page 11: The Scanning Function

    VESDA ® LaserSCANNER Product Manual The Scanning Function The LaserSCANNER is designed to sample air from different sectors and to identify through a scanning process the sector reporting presence of smoke. Scanning During normal operation the scanner valves remain open and the LaserSCANNER draws air from all the pipes.

  • Page 12: The Scanner Valve Test

    ® The Scanner Valve Test The VESDA LaserSCANNER performs a scanner valve test when first powered up. Thereafter a valve test is performed every alternate Tuesday at 12:00 hours. During the valve test each valve is individually closed and opened to ensure its proper functioning. Any improper functioning is reported as a fault (refer to the VESDA Troubleshooting Guide for fault descriptions and troubleshooting).

  • Page 13: Laserscanner Configurations

    • Display Module • LCD Programmer Module • Fire and OK LEDs (FOK) Module Legend Blank Plate LCD Programmer LaserSCANNER Display Unit Figure 2 - VLS-214 VESDA LaserSCANNER with 7 relays, blank plate, LCD Programmer and Display Module...

  • Page 14: Display Module

    VESDA LaserSCANNER Product Manual ® Display Module The LaserSCANNER Display Module is mounted either on the detector front cover or at a remote location in a remote mounting box or a 19” subrack. It provides a visual representation of the smoke levels and the four alarm stages for the assigned detector.
  • Page 15 SYSTEM: A fault affecting the network to which the Display module is connected ZONE: A fault in the VESDA Zone monitored by the Display module POWER: A fault in the power supply if the GPI function is used NETWORK: A communications fault on VESDAnet...
  • Page 16 Sensitivity: Shows the level of smoke that must be measured to illuminate the entire bar graph and always corresponds with the Fire 1 alarm level. Smoke Level: Indicates the current level of smoke in the relevant VESDA Zone and is represented as % obs/m or % obs/ft.

  • Page 17: Display During The Scan Process

    A hand-held model is also available. The hand- held model is connected to the VESDAnet socket on the termination card of the detector. For a detailed description and use of the LCD Programmer please refer to the VESDA LCD Programmer Manual.

  • Page 18: Laserscanner Components

    VESDA LaserSCANNER Product Manual ® Legend Display Keys Figure 5 - LCD programmer LaserSCANNER Components Legend Front Cover Pipe Inlet Manifold Termination Card Air Filter Blank Card Protecting Processor Card Aspirator Chassis with Laser Detector Chamber Mounting Box/Enclosure Figure 6 - An exploded view of the detector...

  • Page 19: Laserscanner Product Information

    Sampled Air: -20° to 60° C (-4° to 140° F) outside these parameters please contact your nearest Humidity: 10-95% RH, non-condensing VESDA Technical Office) Up to 2 years (battery life). 0° to 85°C Dry (<95% humidity) Storage Temperatures 0° to 85° C...
  • Page 20 VESDA LaserSCANNER Product Manual ® 7 relays: Alert, Action, Fire 1, Fire 2, Minor Fault, Urgent Fault and Isolate. (7 x NO/NC contacts) Relays Default 12 relays: Configuration Alert, Action, Fire 1, Fire 2, Minor Fault, Urgent Fault and Isolate, First Alarm sector 1 to 4 and Scan. (10 x...

  • Page 21: Laserscanner Dimensions

    VESDA ® LaserSCANNER Product Manual Filter and flow monitoring Maintenance Aids: Event reporting via VESDAnet or event log Auto Scan and Threshold Detector selects the appropriate scan threshold Settings: automatically LaserSCANNER Dimensions Mounting Bracket Figure 7 - LaserSCANNER dimensions - rear view...

  • Page 22: Ratings And Approvals

    VESDA LaserSCANNER Product Manual ® Figure 8 - LaserSCANNER dimensions Ratings and Approvals Figure 9 - Example of an approvals label...

  • Page 23: Default Settings

    VESDA ® LaserSCANNER Product Manual Default Settings Range Access Parameter Default Value Level Minimum Maximum Airflow Delay 0 seconds 60 seconds • High Urgent 130% 105% 200% • High Minor 120% 105% 200% • Low Minor • Low Urgent Aspirator Speed...

  • Page 24: Relays

    VESDA LaserSCANNER Product Manual ® Range Access Parameter Default Value Level Minimum Maximum Fire 1 Threshold 0.2% obs/m 0.015% obs/m 2% obs/m 0.0625% obs/ft. 0.0046% obs/ft. .6250% obs/ft. Fire 2 Threshold 2% obs/m 0.625% 0.02% obs/m 20% obs/m obs/ft. 0.0062% obs/ft.

  • Page 25: Relay Settings And Conditions To Change States

    VESDA ® LaserSCANNER Product Manual Relay Settings and Conditions to Change States Relay # Default State change Latch Isolate Energizes when an operator isolates the detector by Unlatched pressing the Isolate key on the Display Module or by activating the command via a PC or a LCD Programmer or GPI option.

  • Page 26: Relay Default Settings

    VESDA LaserSCANNER Product Manual ® Relay default settings Relay Isolate Minor Fault Urgent Fault Alert Sector 1 Alert Sector 2 Alert Sector 3 Alert Sector 4 Action Sector 1 Action Sector 2 Action Sector 3 Action Sector 4 Fire 1 Sector 1...

  • Page 27: First Alarm Sector Relays

    VESDA ® LaserSCANNER Product Manual First alarm sector relays: The first alarm sector relays are Factory set at Default to relays 8, 9, 10 and 11 (See “Relay settings and conditions to change state for 7 and 12 relays head termination card” on page 17.

  • Page 28: General Purpose Input (Gpi) Functions

    VESDA LaserSCANNER Product Manual ® General Purpose Input (GPI) Functions The input terminal requires a voltage supply between 5V and 30 VDC to operate. The input is isolated from the system by an opto-coupler device. Connect the GPI + terminal to the positive output and the GPI - terminal to the ground output of the external device.

  • Page 29: Mounting The Laserscanner

    VESDA ® LaserSCANNER Product Manual Function State change Inverted This is the reverse of the normal Reset reset function. ≤ 2 VDC detector reset ≥ 5 VDC normal operating mode Reset Table 4 - GPI Functions Note: The signal voltage into the GPI terminals must be between 5 to 30 VDC. The logic input states are not defined for any voltages >2 to <...

  • Page 30: Mounting The Laserscanner Detector In Normal Orientation

    VESDA LaserSCANNER Product Manual ® Mounting the LaserSCANNER detector in Normal Orientation Place the three bridges located at the rear of the detector onto the lances of the mounting bracket. Push downwards until it locks onto the lances and engages the fitting dimples. To prevent unwanted removal of the detector, secure the detector to the mounting surface by placing two screws through the keyhole slots situated near the termination card.

  • Page 31: Recess Mounting Kit

    VESDA ® LaserSCANNER Product Manual Note: The detection chamber, head processor card and flow sensors are factory calibrated as a matched set. Separating the set and replacing it with components from another set may cause the detector to malfunction, requiring re-calibration at the factory.

  • Page 32: Connecting To The Pipe Network

    VESDA LaserSCANNER Product Manual ® 1.6 Connecting to the Pipe Network Inlet Pipes The inlets in the pipe inlet manifold are designed to receive a standard pipe of 25 mm (1 in) OD. A 25 mm to 1.050 inches adaptor to fit the pipe inlet manifold is included for all shipments to USA.

  • Page 33: Managing The Exhaust Air

    VESDA ® LaserSCANNER Product Manual Managing the Exhaust Air To exhaust air from the detector, use the exhaust ports at the rear or at the bottom of the head mounting box. Remove the appropriate exhaust port plugs and if required, connect an outlet pipe to the exhaust manifold.

  • Page 34: Vesdanet Terminals

    VESDAnet cables are terminated at the VESDAnet A and B Terminals on the termination card. Communication wires from another VESDA device are brought into the detector at one terminal and looped out to another device on VESDAnet from the other terminal. It is necessary to maintain the polarity throughout the network.

  • Page 35: Connections For Gpi

    VESDA ® LaserSCANNER Product Manual Figure 18 - Stand -Alone VESDAnet Connection Figure 19 - An example of the wire connection for VESDAnet (closed loop for illustrative purposes only) Connections for GPI GPI - - 0V + 24 VDC GPI+...

  • Page 36: Power Source

    VESDA LaserSCANNER Product Manual ® 1.8 Power Source There are two sets of power terminals on the termination card. Use one of the power terminals on the termination card to connect to a 24 VDC power supply and if necessary loop out to another device via the second set.
  • Page 37 VESDA ® LaserSCANNER Product Manual To facilitate the calculation of the backup battery size a Battery Calculation Sheet is presented on the next page. NORMAL LOADS @ 24 V DC FULL ALARM LOADS @ 24 V DC EQUIPMENT LOAD mA...

  • Page 38: Starting Up

    ® Note: If intelligent VESDA power supply is fitted it will report power failures (F15) on VESDAnet. VLP & VLS with GPI terminals connected will maintain their aspirator speed for an hour after the loss of mains power. After which, the aspirator speed will be limited to 3000 rpm to conserve power.

  • Page 39: Maintaining The Vesda Laserscanner

    Table 7 - Suggested maintenance schedule for LaserSCANNER detector Caution: While a VESDA Zone is isolated for maintenance, no fire warnings will be issued by the detector and any fire will go undetected. Prior to any maintenance or testing: Inform appropriate supervising authority about the risk associated with isolating a VESDA Zone.

  • Page 40: Replacing The Chassis/Air Inlet Pipe Manifold

    VESDA LaserSCANNER Product Manual ® Replacing the chassis/Air Inlet Pipe Manifold Isolate the LaserSCANNER by pressing the Isolate button or by selecting Isolate Zone from the Zone menu in VConfig Pro or VSM3. This isolates the outputs from the unit to a fire alarm panel and other third party devices such as building management systems.
  • Page 41 VESDA ® LaserSCANNER Product Manual Unscrew the two manifold retaining screws (G). Legend 2 Manifold retaining screws 4 Retaining tabs Figure 24 - Remove the chassis The manifold is held in place by four tabs (H). Use a flat head screw driver to lever out the tabs near the head termination card, and lift up that end of the manifold.

  • Page 42: Internal Wiring For Laserscanner

    VESDA LaserSCANNER Product Manual ® Internal Wiring for LaserSCANNER The table below provides the cable loom interconnecting details inside the detector. Use the look up table in conjunction with the attached circuit diagram to assist with maintenance. Connector card and...
  • Page 43 VESDA ® LaserSCANNER Product Manual Note: Do not attempt to force the connector into its socket. If there is any difficulty, reverse the orientation of the connector before inserting again. Legend Detector chamber Programmer module Display module Detector terminal card...

  • Page 44: Spare Parts

    Number of detectors Installed to warrant ONE spare part Part No. Description Normal Mission Service Critical VSP-000 Blank Plate, non-EMC painted, with VESDA logo VSP-001 LCD Programmer VSP-004 Display Module VSP-005 Filter Cartridge VSP-009 VLS Detector chassis assembly complete with...
  • Page 45 VESDA ® LaserSCANNER Product Manual Index ........... 7 ......3 Action Excessive scan cycles ......3 ......... 25 Adapting Scan Threshold Exhaust Air ......3 ........10 Adaptive Scan Threshold Exploded view ......30 ........20 Air flow normalizing External Reset ...........
  • Page 46 VESDA ® LaserSCANNER Product Manual ........20 Reset+Isolate ..........20 Mains OK ......... 31 Maintaining ...... 32 Save Node Configuration .......... 8 Mode button ........3 Scan Threshold ........8 Mode/Test button ..........3 Scanning ..........21 Mounting ........ 2 Second Stage Filter ........
  • Page 47 VESDA LaserSCANNER Product Manual ® ......27 VESDAnet closed Loop ......26 VESDAnet Terminals ......25 Wiring Connections ..........7 Zone fault ......... 8 Zone number...
  • Page 48 VESDA ® LaserSCANNER Product Manual...
