Summary of Contents for Finish Thompson SF Series
- Page 1 SF SERIES PUMPS SFM, SFM-DEF, SFP, SFV, & SFVV OPERATION & PARTS MANUAL P/N 111214 R1...
- Page 2 EU Declaration of Conformity Finish Thompson Inc. hereby declares that the following machine(s) fully comply with the applicable health and safety requirements as specified by the EU Directives listed. The product may not be taken into service until it has been established that the drive motor for the Drum and Container Pump complies with the provisions of all relevant EU Directives.
-
Page 3: Table Of Contents
Introduction This manual pertains to the SF Series drum pumps and accessories. Finish Thompson Inc. thanks you for choosing our products. We believe the use of our products will be fully satisfactory. When properly installed and operated, your Finish Thompson motor and pump will provide long, trouble-free service; therefore, please read this manual carefully before carrying out any operations on the pump/motor unit. -
Page 4: Warranty, General Terms & Conditions
The warranty of the products shall be valid for a period of 12 months from the date of delivery, under the condition that notice of the alleged defect to the products or parts thereof be given to Finish Thompson, Inc. within the term of 8 days from the discovery. -
Page 5: Safety
The personnel in charge of the installation, the operation, and the maintenance of the pump must be qualified and able to per- form the operations described in this manual. Finish Thompson, Inc. shall not be held responsible for the training level of personnel and for the fact that they are not fully aware of the contents of this manual. -
Page 6: Important Safety Information For Pumping Flammable Or Hazardous Substances
IMPORTANT SAFETY INFORMATION FOR PUMPING FLAMMABLE OR HAZARDOUS SUBSTANCES Read these instructions before operating the pump and motor equipment. The manufacturer will not be responsible for any damage to property or to persons caused by improper use of the equipment. WARNING: It is the responsibility of the user to operate the pump in conformance with OSHA rules for dispensing liquids. -
Page 7: Specifications & Dimensions
PUMP SPECIFICATIONS MODEL SFM MODEL SFM-DEF MODEL SFP MODEL SFV MODEL SFVV Outer Tube Diameter 1-5/8" (41mm) 1-5/8" (41mm) 1-5/8" (41mm) 1-5/8" (41mm) 1-5/8" (41mm) Discharge Spout 1" (25mm) Barb 3/4" (19mm) Barb 1" (25mm) Barb 1" (25mm) Barb 1" (25mm) Barb Discharge Thread 1-1/4"... -
Page 8: Operation
Check drum pump accessories at www.finishthompson.com or contact your local Finish Thompson distributor for bung adapter info. 3. Make sure the pump’s discharge hose is properly secured before operating the motor, torque Finish Thompson hose clamps to 25 in-lbs(2.8 N·m). -
Page 9: Disassembly
DISASSEMBLY & REASSEMBLY INSTRUCTIONS Disassembly 1. Cover, Impeller, & Diffuser Removal - Unthread the diffuser cover (item 19 or 20). Turn it clockwise (left-hand thread). See Figure 1 A & B. Unthread the impeller (item 18) turning it counter clockwise (right hand thread) using your hand while holding the coupling insert and coupling (items 1 &... - Page 10 Disassembly Continued 3. Intake Tube Removal - Unthread the diffuser (item 16) turing it clockwise (left-hand thread). The shaft sleeve (item 14) will drop out of the inner tube by holding it in a vertical position. Remove the intake tube (item 15). Hold the head (item 7) in one hand and with the other hand, turn the intake tube clockwise (left-hand thread).
-
Page 11: Reassembly
Reassembly 1. Seal Installation - Take the head (item 7), and install a new seal (item 4). It is recommended to lubricate the seal with a compatible lubricant or water prior to pressing it in. Insert the open part of the seal into the lower bore of the head. - Page 12 Reassembly Continued 5. Shaft Installation - Slide the shaft down through the seal until the bearing engages the bearing bore in the head. Set the half coupling on the floor and push the pump down using the intake tube (item 15) for leveridge.
-
Page 13: Exploded View - Sf Pump Tube
SF SERIES PUMP EXPLODED VIEW UNLESS OTHERWISE SPECIFIED DISTRIBUTION BLOCK DIMENSIONS ARE IN INCHES DEPT DEPT 921 GREENGARDEN ROAD PHONE: (814) 455-4 REC'D REC'D TOLERANCES ARE: ERIE, PENNSYLVANIA 16501 FAX: (814) 455-8518 .XXX .005 PUMP ASSM INJ MOLD PRODUCT: .010 FRAC. -
Page 14: Pump Tube Spare Parts List
PUMP SPARE PARTS LIST PART NUMBER ITEM DESCRIPTION MODEL MODEL MODEL MODEL MODEL SFM-DEF SFVV COUPLING INSERT J100014 J100014 J100014 J100014 J100014 COUPLING HALF 111058 111058 111058 111058 111058 SPACER BUSHING 111201 111201 111201 111201 111201 BEARING 111057 111057 111057 111057 111057 SHAFT (SFM/SFM-DEF = 316SS) (SFP/SFV/SFVV = ALLOY 625) - Page 15 PUMP SPARE PARTS LIST PART NUMBER ITEM DESCRIPTION MODEL MODEL MODEL MODEL MODEL SFM-DEF SFVV INNER TUBE (SFM/SFM-DEF/SFP/SFV = POLYPROPYLENE) (SFVV = PVDF) 27” 108373-2 108373-2 108373-2 108373-2 108373-7 40” 108373-3 108373-3 108373-3 108373-3 108373-8 48” 108373-4 108373-4 108373-4 108373-4 108373-9 54”...
- Page 16 PUMP SPARE PARTS LIST PART NUMBER ITEM DESCRIPTION MODEL MODEL MODEL MODEL MODEL SFM-DEF SFVV DIFFUSER COVER - HIGH FLOW POLYPROPYLENE 111212-1 111212-1 111212-1 PVDF 111212-2 111212-2 DIFFUSER COVER - HIGH HEAD POLYPROPYLENE 111213-1 111213-1 111213-1 PVDF 111213-2 111213-2 *Recommended spare parts Service 1-800-888-3743 P/N 111214 R1...
