- Page 1 HVDP SERIES PUMPS OPERATION, INSTALLATION & PARTS MANUAL...
- Page 2 EU Declaration of Conformity Finish Thompson Inc. hereby declares that the following machine(s) fully comply with the applicable health and safety requirements as specified by the EU Directives listed. The product may not be taken into service until it has been established that the drive motor for the Drum and Container Pump complies with the provisions of all relevant EU Directives.
-
Page 3: Table Of Contents
Introduction This manual pertains to the HVDP Series drum pumps. Finish Thompson Inc. thanks you for choosing our products. We believe the use of our products will be fully satisfactory. When properly installed and operated, your Finish Thompson motor and pump will provide long, trouble-free service; therefore, please read this manual carefully before carrying out any operations on the pump/motor unit. -
Page 4: Warranty, General Terms & Conditions
The warranty of the products shall be valid for a period of 12 months from the date of delivery, under the condition that notice of the alleged defect to the products or parts thereof be given to Finish Thompson, Inc. within the term of 8 days from the discovery. -
Page 5: Safety
The personnel in charge of the installation, the operation, and the maintenance of the pump must be qualified and able to per- form the operations described in this manual. Finish Thompson, Inc. shall not be held responsible for the training level of personnel and for the fact that they are not fully aware of the contents of this manual. -
Page 6: Important Safety Information For Pumping Flammable Or Hazardous Substances
IMPORTANT SAFETY INFORMATION FOR PUMPING FLAMMABLE OR HAZARDOUS SUBSTANCES Read these instructions before operating the pump and motor equipment. The manufacturer will not be responsible for any damage to property or to persons caused by improper use of the equipment. WARNING: It is the responsibility of the user to operate the pump in conformance with OSHA rules for dispensing liquids. -
Page 7: Hvdp Terminology
HVDP TERMINOLOGY... -
Page 8: Hvdp Series Assembly, Removal, And Operation
Check drum pump accessories at www.finishthompson.com or contact your local Finish Thompson distributor for bung adapter info. 3. Make sure the pump’s discharge hose is properly secured before operating the motor. -
Page 9: Hvdp Series Stator Removal, Inspection, And Installation
NEVER operate the pump against a closed discharge. If the pump is operated against a closed discharge, a bypass (pressure relief valve) must be used. NEVER pump liquids containing solids that can damage internal pump parts (i.e. metal chips). Pumping solids can lead to increased wear on the stator and rotor. -
Page 10: Hvdp Series Rotor Removal, Inspection And Installation
SECTION 5: ROTOR REMOVAL, INSPECTION & INSTALLATION REMOVAL: 1. Remove the motor (see section 1 and follow the instructions for your model). 2. Remove the drive assembly (see section 3). 3. The rotor is located at the bottom of the drive assembly (see Figure 4). Figure 4 4. -
Page 11: Hvdp-Hr Series Parts Schematic
HVDP SERIES - HVDP-HR ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. Coupling Insert J100014 Adapter 1 1/2” 105176 HVDP-HR Gear Box Assembly 16:1 105150 HVDP Barbed Hose Adpater 2” 105287 Tube O-ring FKM 105080 HVDP Tri-Clamp Discharge Fitting 107395... -
Page 12: Hvdp-Lr Series Parts Schematic
HVDP SERIES - HVDP-LR ITEM DESCRIPTION PART NO. ITEM DESCRIPTION PART NO. HVDP LR Gearbox Assembly 5:1 105154 HVDP Barbed Hose Adapter 1 1/2” 105176 HVDP LR Gearbox Assembly 4:1 105155 HVDP Barbed Hose Adapter 2” 105287 Tube O-ring FKM...
