- Page 1 Instructions for use Edition EJ 10.2022 REAR ASSIST DRIVE - WAY Catalogue number: DRVK0M_PP...
-
Page 2: Table Of Contents
Instructions for use TABLE OF CONTENT 1. Introduction 1.1 Product description 2. Usage 2.1 Assembly - cross frame wheelchair 2.2 Assembly - fixed frame wheelchair 2.3 Further assembly stages 3. Everyday use and maintenance 4. Drive module parameters and standards 5. Contact details Always follow precautions according to the safety information provided below when using the product. -
Page 3: Introduction
1. INTRODUCTION Thank you for choosing our product. We are deeply convinced that it will meet your expectations. Please read this document before using it for the first time. This manual is implemented to provide you with the necessary information on the safe use of the device. Correct compliance with the recommendations will significantly contribute to extending the durability and aesthetics of the product. We would like to point out that we are constantly trying to improve the quality of our products, which may result in minor changes that are not included in the manual. - Page 4 List of items inside the package Fig. 3. Two mounting brackets Fig. 2. Rear drive, main unit Fig. 5. Fig. 4. Charger Spreader bar Fig. 6. Control module 4 VITEACARE.COM...
-
Page 5: Usage
2. USAGE • After unpacking the packaging, check that it contains all the parts according to the list of components above. • Make sure that all elements have no visible mechanical damage. If in doubt, contact the manufacturer. • The module should not be used until all components are properly assembled on the wheelchair. -
Page 6: Assembly - Fixed Frame Wheelchair
2.2 ASSEMBLY - FIXED FRAME WHEELCHAIR 1. Select the appropriate mounting bracket depending on the thickness of the rear wheels axle and the spreader bar. 2. Install the handle in the center of the axle and tighten it (Fig. 9.). a) The cap of the handle should be above the axis/bar. b) Tighten the eccentric clamp 1, which is in the horizontal position when tightened. c) Lock it by slightly tilting it backwards. Handle cap Rear wheel axle holder, diameter... - Page 7 5. Dismantling the rear module • Release eccentric clamp 2 and pull the drive out of the mounting bracket (Fig. 11.). Fig. 11. Fig. 12. 6. Then connect the control module (Figure 13.) to the rear module. To do this, screw the end of the cable with a pin to the control module socket on the right side of the module (Figure 14.).
- Page 8 Fig. 15 Warning! The safety switch is not designed to shut down the drive during normal use. Use the rotary switch to safely reduce the speed and stop the drive. The manufacturer does not consider warranty claims caused by not using the control panel properly.
-
Page 9: Everyday Use And Maintenance
3. EVERYDAY USE AND MAINTENANCE Usage: • The maximum load capacity is 100 kg. • Connect the rear drive to the wheelchair and turn on the power switch, then turn the rotary switch. When the switch is turned a third of the wheel, the module starts working. Speed: 0-7.5 km / h •... -
Page 10: Drive Module Parameters And Standards
Do not use: • solvents, • toilet cleaners, • agents with chlorine content, • sharp brushes and hard objects, • caustic cleaning agents, • do not clean the device with pressure or steam generators! Repair: • In the event of repairs being necessary, please contact the manufacturer or the distributor. Customer service: •... -
Page 11: Contact Details
European Union. If you wish to decommission this appliance, please obtain the correct decommissioning information from your local authorities or from your retailer. Medical device 5. CONTACT DETAILS mdh Sp. z o. o. ul. Maratońska 104, 94-007, Łódź, Poland tel. +48 42 674 83 84, fax. +48 42 636 52 21 www.mdh.pl, www.viteacare.com VITEACARE.COM 11... - Page 12 MDH Sp. z o.o. ul. Maratońska 104, 94-007, Łódź, Polska www.mdh.pl www.viteacare.com...
