- Page 1 PCBL 1610/ 1810 DE LUXE POWER WHEELCHAIR USER'S MANUAL Edition 08.2010 mdh sp. z o.o. 90-349 Łódź, ul tymienieckiego 22/24 tel. (+48) 42 212 32 08 fax: (+48) 42 674 04 99 www.mdh.pl export@mdh.pl...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Practice before operating......................3 2. User’s safety..........................3 3. Driving outdoor.........................4 4. Driving over the hills and on uneven terrain..................4 5. Technical parameters........................5 6. Battery and charging.......................10 7 Comfort adjustment.........................11 8. Maintenance and cleaning......................15 9. Specification..........................17 Please, read the instruction carefully before the first use of the wheelchair. If any part of the text is not clear or if you need any further information, please, contact your dealer. -
Page 3: Practice Before Operating
1. PRACTICE BEFORE OPERATING Before driving the vehicle on everyday basis, you should find an open area such as a park to practice maneuvers . We recommend that when you practice driving you should be accompanied by an assistant. ... -
Page 4: Driving Outdoor
3. DRIVING OUTDOOR The wheelchair is not designed to move in the street traffic Do not use the wheelchair during rain or snow, when the temperature is higher than 30°C or lower than 0°C Do not use the wheelchair on soft, uneven, unprotected surfaces such as grass, gravel, sand or decks, beside a river, lake ... -
Page 5: Technical Parameters
5. TECHNICAL PARAMETERS headrest backrest controller controller holder seat armrest rear lights front lights frame battery footrests rear wheels front wheels motor Wheelchair parts Frame - main frame, bottom frame, shock absorbers, rear and front lights; Armrests - parts which enable armrests’ assembly and adjustment, polyurethane foam padding Backrest - upholstery, actuator which allow to adjust backrest’s angle, safety belts, belts which allow to adjust backrest depth Seat –... - Page 6 Electronic control panel Electronic control panel allows to control power wheelchair, battery power status and general condition of the whole electronic system. Electronic control panel is usually placed on the armrest and joint to the battery and motor. The panel can be attached to the left /right armrest or behind the wheelchair (when it is used by a caregiver).
- Page 7 Battery status bar You can find the battery status bar at the top of controller. Using the color light indicator, the battery status bar provides information on supply, approximate power of the batteries, electric systems of the wheelchair using a color code. Constant red, yellow and green light indicate that batteries are fully charged, electric systems and electronic system of control panel are efficient.
- Page 8 Right turn button When you press the button, the corresponding light icon will activate. In order to switch off the winker, press the button again. Warning light button Activates the warning lights. Motor clutch Ball lock pin Clutch lever 1. If you want to push the power wheelchair, pull the clutch lever to release the ball lock pin (the ball lock pin will slope down).
- Page 9 Charger Charger plug connection 1. Plug the charger output cable to into the charging socket in the bottom part of the controller. 2. After connecting the charger output cable to the charging socket and to the power outlet, turn on the electronic control panel.
-
Page 10: Battery And Charging
6. BATTERY & CHARGING The charger is the key part of the wheelchair. In order to charge the batteries quickly and safely ,use only the original charger supplied with the wheelchair and follow the below rules. 1. Always plug the charger into the charging socket placed at the bottom part of the controller. Then, plug it to the power outlet. -
Page 11: Comfort Adjustment
7. COMFORT ADJUSTMENT First, choose the adjustment mode on your controller Push the mode button on the controller and choose the adjustment mode. Please, look at the wheelchair icon placed on the controller – it will indicate which wheelchair’s part (backrest, seat or footrest) is ready to be adjusted. - Page 12 Armrest adjustment In order to adjust the armrest height, loosen the handle, choose the required armrest height and screw in the screw. handle Controller adjustment Hand adjustable screw It is possible to adjust the controller position to individual needs. Loosen the hand adjustable screw placed under the armrest and choose required controller position as shown in picture A and B.
- Page 13 Battery removal In order to remove the batteries loosen the socket head cap screw and pull out the battery tray. Socket head cap screw Battery tray Battery The wheelchair is equipped with two 12 V maintenance-free batteries. In order to obtain maximum efficiency of your battery please, follow the instructions below: 1.
- Page 14 WARNING Never let the batteries unload completely. If you notice last yellow or first red light indicator on the controller- charge the batteries. Remember that the charging cycle should take about 9-10 hours, till the batteries are fully charged. Never stop or suspend the charging if batteries are not fully charged. Not following the above rules may lead to battery damage.
-
Page 15: Maintenance And Cleaning
8. MAINTENANCE AND CLEANING In order to ensure that your wheelchair will give you years of trouble-free operation, the user should regularly inspect and maintain the wheelchair and deliver it to the authorized distributor for annual comprehensive maintenance and inspection. If you find any problems or abnormalities while using the wheelchair, please, contact the nearest authorized service point. - Page 16 you fail to store the unit under the above conditions, the frame can rust, and the electronics can be damaged. Problem checklist 1. Problem: The controller lights blink quickly when the power is switched on. Action: Switch off the power, put the joystick in its neutral position. Then wait few seconds and reactivate the wheelchair 2.
-
Page 17: Specification
SPECIFICATION Cataloge number PCBL 1610/1810 Seat width 40,89 cm and 45,97 cm Length 104 cm Width 64 cm Wheelchair height 107 cm Front wheels 9’’ Rear wheels 14’’ Permissible tire 3,5 bar pressure Capacity 136 kg Max Speed 10 km/h... - Page 18 export@mdh.pl...
