- Page 1 PCBL 1600/1800 POWER WHEELCHAIR MODERN INSTRUCTIONS FOR USE Edition 01.2022...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Practice before operating......................3 2. User’s safety..........................3 3. Driving outdoor.........................4 4. Driving over the hills on uneven terrain..................4 5. Technical parameters........................5 6. Battery and charging.......................12 7. Maintenance and cleaning......................13 8. Specification..........................15 Please, read the instruction carefully before the first use of the wheelchair. If any part of the text is not clear or if you need any further information, please, contact your dealer. -
Page 3: Practice Before Operating
1. PRACTICE BEFORE OPERATING Before driving the vehicle on everyday basis, you should find an open area such as a park to practice maneuvers . We recommend that when you practice driving you should be accompanied by an assistant. ... -
Page 4: Driving Outdoor
3. DRIVING OUTDOOR The wheelchair is not designed to move in the street traffic Do not use the wheelchair during rain or snow, when the temperature is higher than 30° or lower than 0° Do not use the wheelchair on soft, uneven, unprotected surfaces such as grass, gravel, sand or decks, beside a river, lake ... -
Page 5: Technical Parameters
5. TECHNICAL PARAMETERS armrest controller backrest seat footrests front light anti-tip wheel motor front wheel rear wheel 1. controller 2. armrests 3. backrest 4. seat 5. footrests 6. anti-tip wheels 7. rear wheels 8. front wheels 9. motor 10. front light... - Page 6 Assembly 1. Install the battery by putting it into the rails placed on the wheelchair frame under the seat. 2. Assemble the armrests – choose the desired height and screw in the butterfly screw. 3. Assemble the swing away footrest, block them in a chosen position. 4.
- Page 7 Adjusting the control panel position Unscrew the butterfly screw, adjust the control panel and screw in the butterfly screw. Moving the control panel to left/right armrest Disconnect the supply from the control panel. Remove both armrests. Unscrew and remove the control panel holder.
- Page 8 Electronic control panel Electronic control panel allows to control power wheelchair, battery power status and general condition of the whole electronic system. Electronic control panel is usually placed on the armrest and joint to the battery and motor. The panel can be attached to the left /right armrest or behind the wheelchair (when it is used by a caregiver).
- Page 9 Switch on button NEVER, even in case of danger or other unpredictable situations, turn off the wheelchair by pressing the switch on button – the wheelchair will abruptly stop which may cause falling down. Always turn off the power if you do not intend to drive it – in this way you will avoid unpredictable wheelchair ‘s movements.
- Page 10 Driving lights button When you switch on the driving lights, the corresponding light icon will activate. Left turn button When you press the button, the corresponding light icon will activate. In order to switch off the winker, press the button again. Right turn button When you press the button, the corresponding light icon will activate.
- Page 11 Battery The wheelchair is equipped with two 12 V maintenance-free batteries. In order to obtain maximum efficiency of your battery please, follow the instructions below: 1. Charge each battery before the first use. The batteries will reach 90 % of their capacity. 2.
-
Page 12: Battery And Charging
6. BATTERY & CHARGING The charger is the key part of the wheelchair. In order to charge the batteries quickly and safely ,use only the original charger supplied with the wheelchair and follow the below rules. 1. Always plug the charger into the charging socket placed at the bottom part of the controller. Then, plug it to the power outlet. -
Page 13: Maintenance And Cleaning
Changing the tyres 1. Unscrew the wheel blocking screw. 2. Remove the wheels, remove the tyre and change it with a new one. 3. Install the wheel and screw in the blocking screw. 7. MAINTENANCE AND CLEANING In order to ensure that your wheelchair will give you years of trouble-free operation, the user should regularly inspect and maintain the wheelchair and deliver it to the authorized distributor for annual comprehensive maintenance and inspection. - Page 14 central position. Check the rubber boot around the base of the joystick for damage. Visually inspect the boot. Do not handle or try to repair it. See authorized dealer if there is any problem. 10. Carefully check all the wires – if you notice any damage contact the authorized service point. Make sure that all wiring connections are correct and proper;...
-
Page 15: Specification
8. SPECIFICATION Model no PCBL 1600 1800 Seat width 40,7 cm 45,7 cm Length 115 cm Width 59,5 cm 64,5 cm Caster wheel 9’’ Drive wheel 14’’ Weight capacity 136 kg Max speed 12 km/h Range 36 km Turning radius... - Page 16 Medical device Contact details mdh Sp. z o.o. ul. Maratońska 104, 94-007, Łódź, Polska tel. +48 42 674 83 84 fax. +48 42 636 52 21...
