American Dish Service ADS HUB-40-HIGH TEMP Manual

Undercounter dishwashers

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Installation/Operation Manual/Parts Manual

www.americandish.com

American Dish Service

900 Blake Street

Edwardsville, KS 66111-3820 U.S.A.

Toll Free 800-922-2178

Undercounter Dishwashers

ADS HUB-40-HIGH TEMP

High Temperature

with built-in booster

Fresh Water Final Rinse

THE MODELS CONTAINED IN THIS

MANUAL COMPLY WITH ANSI/ASSE

1001 & ANSI/ASSE 1004.

Issue Date: 8.17.22

Manual P/N

For machines beginning with S/N W2204106955 and above

A0513316 Rev.A

Printed in the USA

Table of Contents

Need help?

Do you have a question about the ADS HUB-40-HIGH TEMP and is the answer not in the manual?

Questions and answers

Summary of Contents for American Dish Service ADS HUB-40-HIGH TEMP

Page 1 Installation/Operation Manual/Parts Manual Installation/Operation Manual/Parts Manual Undercounter Dishwashers Undercounter Dishwashers ADS HUB-40-HIGH TEMP ADS HUB-40-HIGH TEMP High Temperature with built-in booster Fresh Water Final Rinse THE MODELS CONTAINED IN THIS THE MODELS CONTAINED IN THIS MANUAL COMPLY WITH ANSI/ASSE MANUAL COMPLY WITH ANSI/ASSE 1001 &...
Page 2 For future reference, record your dishwasher information in the box below. Model Number__________________________ Serial Number_______________________ Voltage________________Hertz_____________ Phase__________________ Service Agent __________________________________ Tel:______________________ Parts Distributor _________________________________ Tel:______________________ National Service Department In the USA: Toll-free: 800-922-2178 Tel: 913-422-3700 Fax: 913-422-6630 email: service@americandish.com ATTENTION: The model no., serial no., voltage, Hz and phase are needed to identify your machine and to answer questions.
Page 3 4:34 PM • Use the fax form on the next page.
Page 4 PRODUCT REGISTRATION BY FAX COMPLETE THIS FORM AND FAX TO: 913-422-6630 in the USA PRODUCT REGISTRATION CARD Model Serial # Date of Installation: Company Name: Address: (Street) Province Postal Code Telephone #: ( Contact: Installation Company: Address: Telephone #: Contact: FAILURE TO REGISTER YOUR PRODUCT MAY VOID YOUR WARRANTY IMPORTANT IMPORTANT...
Page 5 Revision History Revision History A revision might be a part number change, a new instruction, or other information that was not available at print time. We reserve the right to make changes to these instructions without notice and without incurring any liability by making the changes. Equipment owners may request a revised manual, at no charge, by calling 1 (800) 922-2178 in the USA.
Page 6: Limited Warranty
Limited Warranty LIMITED WARRANTY American Dish Service (herein referred to as ADS), 3 . warrants machines, and parts, as set out below. 00 Blake Street, Edwardsville, KS 66111-3820 U.S.A Warranty of Machines: ADS warrants all new machines of its manufacture bearing the name "ADS" and installed within the United States, Islands, Mexico and Canada to be free from defects in material and workmanship for a period of one (1) year after the date of installation or ﬁfteen (15) months after the date of shipment by ADS, whichever occurs ﬁrst.
Page 7 3 Phase Connection (in-field conversion) 1" Caster Kit *Not available with 17" Stand / 8" leg stand or casters American Dish Service 900 Blake Street | Edwardsville, Kansas, 66111 Phone: 913.422.3700 | Toll-Free: 800.922.2178 | Fax: 913.422.6630 orders@americandish.com | americandish.com...
Page 8 American Dish Service American Dish Service Manufacturers of Ware Washing Equipment 900 Blake Street | Edwardsville, Kansas, 66111 913.422.3700 | Toll-Free: 800.922.2178 | Fax: 913.422.6630 orders@americandish.com | americandish.com HUB40-V01-R1.0...
Page 9: Table Of Contents
Table of Contents Table of Contents Models ADS HUB-40-HIGH TEMP Revision History Limited Warranty Model Descriptions Installation Receiving Placement Electrical Connections Electrical Connections-Wiring Diagrams Connecting Incoming Power to the Main Terminal Block (1 and 3 PH) Booster Heater Conversion from 1 to 3 PH...
Page 10: Installation
Installation Receiving NOTE: The installation of your dishwasher must be performed by qualiﬁed service personnel familiar with food service equipment and must comply with all local health codes. Problems due to improper installation are not covered by the Limited Warranty. NOTE: The installation of the dishwasher must comply with all local electrical, plumbing, health and safety codes or in the absence of local codes, installed in accordance with the applicable...
Page 11 Installation 1PH and 3PH Wiring Diagrams ! ATTENTION ! ALL DISHWASHERS ARE SHIPPED FROM THE FACTORY WIRED FOR SINGLE PHASE OPERATION UNLESS SPECIFIED AT THE TIME OF ORDER. IF YOU ARE CONVERTING A SINGLE PHASE MACHINE TO THREE PHASE BE SURE TO FOLLOW THE BOOSTER WIRING INSTRUCTIONS ON PAGES 7-8.
Page 12: Connecting Incoming Power To The Main Terminal Block (1 And 3 Ph)
Installation Connecting Incoming Power to the Main Terminal Block WARNING: Electrocution or serious injury may result when working on an energized circuit. Disconnect power at the main breaker or service disconnect switch before working on the circuit. Lock-out and tag the breaker or service disconnect switch to indicate that work is being performed on the circuit.
Page 13 Installation Connecting Incoming Power to the Main Terminal Block Refer to the photo below: Remove the lower front dishwasher panel. Remove the retaining fasteners (A) from the swing-out brackets and swing the chemical pump bracket (B) and the chemical circuit board bracket (C) out of the way as shown. (continued on next page) Main Terminal Block Cover...
Page 14 Installation Connecting Incoming Power to the Main Terminal Block for 1PH and 3PH Machines with Boosters (continued from previous page) Refer to the photo below: Provide a 3 foot/1 meter service loop in the power supply cable to service the machine Route the power cable from the rear of the machine to the terminal block making sure the cable does not touch the booster tank.
Page 15 Installation Booster Heater Conversion from 1PH to 3 PH Operation ! VERY IMPORTANT ! THE BOOSTER HEATER IS WIRED FOR 1PH OPERATION WHEN SHIPPED. FOLLOW THE INSTRUCTIONS BELOW TO WIRE THE BOOSTER FOR 3PH. WARNING: Electrocution or serious injury may result when working on an energized circuit.
Page 16 Installation Booster Heater Conversion from 1PH to 3 PH Operation (continued) ! VERY IMPORTANT ! THE BOOSTER HEATER IS WIRED FOR 1PH OPERATION WHEN SHIPPED. FOLLOW THE INSTRUCTIONS BELOW TO WIRE THE BOOSTER FOR 3PH. Disconnect the existing booster heater wires and change the booster heater element jumpers as shown in the illustration below Connect wires 1H1, 1H2, and 1H3 as shown below Booster Heater...
Page 17 Installation Completing the 1PH to 3PH Electrical Conversion ! ATTENTION ! CHANGE THE DATA PLATE ON THE LOWER FRONT PANEL OF THE MACHINE AFTER THE MACHINE IS WIRED FOR 3PH AND THE BOOSTER HEATER IS CONNECTED FOR 3PH. The data plate on the dishwasher lower front panel must be changed after the machine is conver ted from single phase operation to three phase operation.
Page 18: Water Connections
Installation Water Connections ! VERY IMPORTANT ! Make sure the ﬂexible water supply and drain hoses are not kinked. Plumbing connections must allow the machine to be pulled out for service and cleaning. Plumbing connections must comply with national, provincial local plumbing and sanitary codes.
Page 19 Installation Drain Connections ! VERY IMPORTANT ! Do not connect the drain hose to a disposer. The dishwasher will not drain correctly. Refer to the photo below. All models are equipped with a 6 ft.. 5/8" I.D. drain hose. The maximum drain height connection must not exceed 3 ft.[1 m] and must be vented to prevent the wash tank from siphoning.
Page 20: Drain Connection
Installation Drain Connection (continued) NOTE Plumbing connections must comply with national, provincial local plumbing and sanitary codes. DO NOT REMOVE THE CLAMPS HOLDING THE DRAIN HOSE TO THE BACK OF THE DISHWASHER. DO NOT CONNECT THE DRAIN HOSE TO A DISPOSER. DO NOT REDUCE THE SIZE OF THE DRAIN HOSE CONNECTION NOR USE A DOMESTIC DRAIN FITTING.
Page 21 Installation Drain Connection For an Indirect Drain Connection: A 1" [25.4mm] minimum air gap must be provided between the outlet of the dishwasher drain hose and the ﬂood-level rim of the ﬂoor drain, ﬂoor sink or any other locally approved drain receptacle. (See illustration below.) Dishwasher Drain Hose Minimum...
Page 22: Booster Fill Switch - (Filling The Booster For The First Time)
Installation Booster Fill Switch - (Filling the booster tank for the ﬁrst time) ! CAUTION ! AVOID PERMANENT DAMAGE TO THE BOOSTER HEATER DO NOT TURN THE DISHWASHER POWER SWITCH ON WHEN FILLING THE BOOSTER FOR THE FIRST TIME. THE BUILT-IN BOOSTER TANK WAS DRAINED BEFORE SHIPMENT AND MUST BE REFILLED BEFORE OPERATING THE DISHWASHER.
Page 23 Installation Booster Fill Switch - (Filling the booster tank for the ﬁrst time) inside the wash compartment. Release the FILL switch. Replace the lower front panel on the machine.
Page 24: Chemical Connections
Installation Chemical Connections ! VERY IMPORTANT ! ALWAYS USE A COMMERCIAL-GRADE NON-CHLORINATED DETERGENT. PLACE THE CHEMICAL SUPPLY CONTAINERS AS CLOSE TO THE MACHINE AS POSSIBLE. DO NOT ELEVATE THE CHEMICAL CONTAINERS ABOVE THE FINISHED FLOOR. ! VERY IMPORTANT ! Contact a chemical supplier for detergent and rinse-aid chemicals. The chemical supplier must adjust the chemical dispensing pumps for water hardness and food soil types.
Page 25: Pumps And Injection Points - Detergent And Rinse-Aid Dispensing Pumps
Installation Pumps and Injection Points - Detergent and Rinse-aid Dispensing Pumps 2. For the detergent enters the wash tank compartment through a ﬁtting on the back right corner of the wash compartment. Rinse-aid enters the ﬁnal rinse piping through a ﬁtting near the vacuum breaker. DETERGENT INJECTION POINT...
Page 26 Installation Pumps and Injection Points - Detergent and Rinse-aid Dispensing Pumps Priming the Dispensing Pumps ! VERY IMPORTANT ! The chemical dispensing pumps must be primed before operating the dishwasher and whenever the chemical container is changed. Control Panel Extended Wash ON-OFF/DRAIN Cycle Light Power Switch...
Page 27 Installation Detergent and Rinse-aid Dispensing Pumps - Pump and Fill Adjustments ! ATTENTION ! The amount of dispensed chemical is determined by the run time of the dispensing pump. Refer to the photo below: 1. The chemical dispensing pump run and the tank ﬁll adjustment screws are located on the end of the chemical circuit board swing-out bracket.
Page 28: Operation
Operation Loading Dish Racks ! VERY IMPORTANT ! DO NOT OVERLOAD THE DISH RACK. LOAD ONE DISH RACK INTO THE MACHINE AT A TIME. Prescrap and rinse the wares before loading to remove large food particles. Load soiled wares into the dish rack. Place plates and glasses in a peg rack. Place cups and bowls in a ﬂat bottom rack.
Page 29 Operation Loading Dish Racks (continued) Load pots and pans in a ﬂat-bottom rack. Load utensils in a single layer in a ﬂat-bottom rack. Load cups and bowls in a ﬂat-bottom rack. NEVER stack dish racks. Wash one dish rack at a time.
Page 30: Normal Wash Mode
Operation Normal Wash Mode Control Panel Extended Wash ON-OFF/DRAIN Cycle Light Power Switch Extended Wash/ Prime Cycle Light Delime Push button Start Push button Push button Wash Temperature Final Rinse Temperature Digital Display Digital Display Close the door . Push the dishwasher Power Switch UP to turn the power ON. The power switch will illuminate and the machine will ﬁll with water.
Page 31: Rinse Sentry Mode
Operation - ! ATTENTION ! DOOR LEFT OPEN DURING WASH CYCLE If the dishwasher door is left open for more than 5 seconds during the normal wash mode, then the dishwasher cycle will reset to the beginning of the normal wash cycle. ! ATTENTION ! RINSE SENTRY MODE WILL EXTEND WASH CYCLE TIME In the event that the ﬁnal rinse temperature has not reached 180-195ºF/82-91ºC after the...
Page 32 Operation Drain Mode pushed down to the OFF/DRAIN position. POWER OFF/DRAIN START Push the illuminated power switch down to the OFF/DRAIN position. The power switch light will go out. The cycle light will illuminate and the machine will drain. The machine, will ﬂush, perform 3 short drain cycles and then drain completely. The cycle light will go out indicating that the drain cycle is complete.
Page 33: Cleaning
Cleaning Cleaning VERY IMPORTANT DRAIN AND CLEAN THE DISHWASHER EVERY 2 HOURS OF CONTINUOUS OPERATION, AFTER EACH MEAL PERIOD, AND AT THE END OF THE DAY. All Models Cleaning the wash tank: Remove the upper and lower spray arms and ﬂush clean in a sink. wash tank or sump.
Page 34 Cleaning Spindle Rinse Arms Assembly There are two rinse ar ms in the They are interchangeable. Remove the spindle assembly and end plugs in each pipe and ﬂush the rinse pipes. Inspect the rinse arm bearings for wear and replace as necessary. Clean the rinse arm nozzles with a small paper clip.
Page 35 Cleaning All Models - Cleaning All Models Scrap Screen and Sump Strainer Scrap Lift the scrap screen straight up and out of Screen the machine to prevent food par ticles from falling into the tank sump. Flush the scrap screen in a remote sink making sure to back-ﬂush both side of the screen.
Page 36: Deliming
Deliming Deliming Cautions and Warnings A deliming agent must be used in accordance with your chemical supplier's instructions. DANGER: Death or serious injury may result when deliming solution is mixed with sodium hypochlorite sanitizing agent. Mixing may cause hazardous gases to form. Deliming solution and other acids must never be mixed with chlorine, iodine, bromine, or ﬂuorine.
Page 37 Deliming Read and Follow the Deliming Cautions and Warnings on page 32 before deliming the machine.. Deliming Procedure Follow the procedures below to de-lime Open the dishwasher door and remove any dish racks. Turn the power switch on the dishwasher to the ON position. Remove the detergent and rinse-aid chemical supply tubing from their chemical supply containers.
Page 38: Maintenance
Maintenance Follow the maintenance schedules below to keep the dishwasher operating most efﬁciently. Daily Maintenance Make sure the water supply is on and that the drain is not clogged. Check the temperature gauges and/or displays to ensure they are operating. Make sure the dish racks are in good condition.
Page 39 Troubleshooting Troubleshooting Illustrations Page Troubleshooting Chart Wash Codes Temperature Display Board Rinse Codes Temperature Display Board Booster Codes Temperature Display Board Timer Board Connection Diagram - All Models Timer Board Diagnostic Testing Temperature Display Board Power Terminal Connections Temperature Display Board M3-M4 Selector Slide Switch Temperature Display Board Diagnostics Booster/Wash Tank Heater Interlock Circuit Operation...
Page 40 Troubleshooting Condition Cause Solution Dishwasher will not run. Door not closed. Close door completely. Main power OFF. Check breaker on panel. Dishwasher OFF. Turn dishwasher power switch ON. Low or no water. Main water supply off. Open supply valve. Fill hose kinked. Straighten fill hose.
Page 41 Digital Temperature Display Codes Digital Temperature Display Codes Display codes that appear in the display windows indicate the operating condition of the machine. Refer to the illustrations below for the meaning of the codes. Wash Display Codes CAUSE WASH DISPLAY CODE Wash temperature is below 100˚F RINSE TEMP...
Page 42 Digital Temperature Display Codes Rinse Display Codes CAUSE RINSE DISPLAY CODE 1 5 9 Rinse temperature is below 100˚F RINSE TEMP WASH TEMP 1 5 6 Rinse temperature is above 200˚F WASH TEMP RINSE TEMP 1 4 9 Booster tank is empty &...
Page 43 Digital Temperature Display Codes Booster Display Codes Error Codes for Booster and Final Rinse Thermistors Only. CAUSE DISPLAY CODES 1 5 0 Booster overtemp lockout because booster temperature is greater than 210˚F. RINSE TEMP WASH TEMP NOTE: Booster is locked out for 10 minutes before being re-energized.
Page 45 All Models - Timer Board Diagnostic Testing Diagnostic Testing for the Solid State Timer Board, P/N 0712105 Beginning with S/N W081217467 and above Before testing, Press the dishwasher power switch to OFF/DRAIN and allow the machine to complete the drain cycle. Check the incoming voltages.
Page 46 Digital Temperature Display Board - All Models Power Neutral...
Page 47 All Models - Digital Temperature Display Board UNIVERSAL TEMPERATURE CONTROL BOARD MODELS...
Page 48 Booster Heater/Wash Tank Heater Interlock Circuit Operation Booster Heater/Wash Tank Heater Interlock Circuit Operation The booster heater/wash tank heater interlock circuit removes power from the wash tank heater whenever the booster heater contactor energizes. The illustration below shows how the booster heater contactor is wired. The booster heater contactor is located on the center of the base behind the lower front access panel.
Page 49 Electrical Schematic SINGLE PHASE THREE PHASE...
Page 50 Timing Charts...
Page 51 Service Replacement Parts Service Replacement Parts Illustrations Page Wash Pump/Motor Assembly - All Models Base Assembly - All Models Fill Piping Assembly Fill Rinse Piping Assembly Final Rinse Piping Fill Chute Assembly Chemical Dispensing Pumps Booster Assembly Power Input Block and Cord Assemblies Timer Control Board Assembly Wash and Rinse Spray Arms and Drain Valve Control Panel...
Page 52 Wash Pump/Motor Assembly - All Models...
Page 53 Wash Pump/Motor Assembly Item Part Description Qty. A0512347 CAPACITOR 40 µF A0512101 PUMP/MOTOR ASSEMBLY COMPLETE 115VAC/60/1 A0313394 BRACKET, WASH PUMP A0512185 BOLT, HEX FLANGE 1/4-20 X 3/8" SST A110285 GASKET A114139 SEAL A0512345 IMPELLER A0501478 WASHER, PLAIN, 17/64" A106482 WASHER, LOCK, 1/4" A114144 NUT, M6 A0512340...
Page 54 Base Assembly - All Models To upper wash hub To rinse 16 17 Detail on pgs. 106-107 Detail on pgs. 102-105 35 36...
Page 55 All Models - Base Assembly Item Part Description Qty. A0512136 SCREEN, SCRAP ASSY. A0513324 FLANGE, PUMP SUCTION A0513677 O-RING A0512169 HEATER, 120VAC 750W) A0512426 HEATER, 240VAC 2000W A0512099 O-RING A0508872 ADAPTOR, THERMOMETER A0512107 THERMOMETER, WASH TANK A108954 NUT, GRIP 6-32 WITH NYLON INSERT SST A113604 THERMOSTAT, HI-LIMIT BI-METAL SNAP, 212°F A0512299...
Page 56 All Models - Base Assembly Item Part Description Qty. A0512227 PUMP, DRAIN 115VAC A0512322 CLAMP, HOSE A0513339 HOSE, OVERFLOW A0712236 TUBE, OVERFLOW GUARD ---- A0712236-1 TUBE, OVERFLOW GUARD A109835 SCREW #8 X 1/2" SELF-TAPPING SST A0512185 BOLT, HEX FLANGE 1/4-20 X 3/8" SST A0509526 HOSE, 1/2"...
Page 57 Fill Piping Assembly From Hot Water Supply Note: This is a 3/4” Garden Hose FItting...
Page 58 Fill Piping Assembly Item Part Description Qty. A0512985 CLAMP, HOSE A0508782 ELBOW, 90° 1/2" MPT X 1/2" HOSE A0312146 BRACKET, 1/2" SOLENOID VALVE (UH230, UH230B) A0512185 BOLT, HEX FLANGE 1/4-20 X 3/8" SS A0502618 BARB, HOSE 1/2" X 3/8" MPT A0509526 HOSE, 1/2"...
Page 59 Upper Final Rinse Piping...
Page 60 Upper Final Rinse Piping Item Part Description Qty. A0502571 CLAMP, HOSE A0512120 HOSE, UPPER WASH A0512985 CLAMP, HOSE A107417 HOSE, RUBBER 1/2" ID X .84" OD A0512757 CONDUIT, 1/2" A0512758 CONDUIT, 3/8" A0512369 CLAMP, CONDUIT A112728 ELBOW, 1/8" MPT X 1/4" COMP PP A112883-1 TUBING, 1/8"...
Page 61 Chemical Dispensing Pumps RINSE-AID DETERGENT IMPORTANT: Check Items #9 and #10 every 6 months and replace if stretched or worn.
Page 62 Chemical Dispensing Pumps Item Part Description Qty. A0501869 STRAINER A0306363 TUBE, 3/8" ID X 12" LG. STIFFENER A0505483 LABEL, RINSE-AID HOSE A112883-1 TUBING, 1/8" OD X 1/16" ID A0503695 LABEL, DETERGENT HOSE A0502667 HOSE, 1/4" ID X 3/8" OD PVC A0501519 TIE, NYLON 4"...
Page 63 Booster Assembly 11 12...
Page 64 Booster Assembly Item Part Description Qty. A0512985 CLAMP, SS GEAR-MIN. 1/2" A107417 HOSE, RUBBER 1/2" ID X .84" OD A0513314 TEE, RINSE THERMISTOR 10 k , 2-WIRE A0513310 A110562 THERMOSTAT, HIGH LIMIT 240°F A108954 NUT, GRIP 6-32 W/NYLON INSERT SST A0512185 BOLT, HEX FLANGE, 1/4-20 X 3/8"...
Page 65 Power Input Block and Cord Assemblies...
Page 66 Power Input Block and Cord Assemblies Item Part Description Qty. A0313396 COVER, BOX WIRING A0501411 SCREW, 10-32 X 1/4", TRUSS HD. A0512432 CONTACTOR, 3-POLE 120VAC COIL A0509527 BLOCK, TERMINAL, 4-POLE (All except UL130) A103310 LUG, GROUND A0313395 BOX, WIRING A107964 BUSHING, STRAIN RELIEF, SMALL A0503592 LABEL, GROUND...
Page 67 Timer Control Board Assembly Front View Rear View...
Page 68 Timer Control Board Assembly Item Part Description Qty. A0313397 BOX, CONTROL BOARD A0712105 TIMER CKT. BD. A0501464 SCREW, 10-24 X 3/8; TRUSS HD. SST A0512373 FUSE, 4A 250V A0513698 FUSE, 6A 250V A0313398 COVER, BOX A0501411 SCREW, 10-32 X 1/4" SST A0501373 SWITCH, BOOSTER FILL A0512973...
Page 69 Wash and Rinse Spray Arms and Drain Valve...
Page 70 Wash and Rinse Spray Arms and Drain Valve Item Part Description Qty. A0501478 WASHER, 17/64 id X 9/16" OD SST A107967 NUT, HEX 1/40-20 NYLON INSERT SST A0514251-1 HUB, UPPER SPRAY ARMS A107873 WASHER, PACKING A110215 SCREW, RETAINING A0502571 CLAMP, HOSE GEAR 1-1/2" SST A0512120 HOSE, UPPER WASH ARM (UH230, UH230B) A0513699...
Page 71 Control Panel...
Page 72 Control Panel Item Part Description Qty. A0512221 SWITCH, ROCKER DPST 250V NEON A0512213 SWITCH, PIEZIO A0512232 LIGHT, INDICATOR, GREEN A0512226 SWITCH, ROCKER RND SPDT MOMENTARY A0501408 SCREW, TRUSS PHIL. SST 8-32 X 1/4" A0513313 LABEL, FACIA ADS HUB-40 HIGH TEMP A0313415 PANEL, FACIA A0512357...
Page 73 Panels...
Page 74 Panels Item Part Description Qty. A0313406 PANEL, FRONT WITHOUT GAUGE HOLE A0313407 PANEL, FRONT WITH GAUGE HOLE A0512319 GASKET, 1/8" x 5/8" x 21-1/2" A109812 GAUGE, PRESSURE 0-60 PSI A100779 SCREW 1/4-20 X 5/8" TRUSS SS PHIL A0513659 FITTING, 1/4" TUBE X 1/8" FNPT PP A107928 TUBING, 1/4"...
Page 75 Door Assembly...
Page 76 Door Assembly Item Part Description Qty. A0713136 DOOR ASSEMBLY A0513558 GASKET, DOOR TOP A0713428 HINGE, RH ASSY A0501476 WASHER, 9/32" X 5/8" OD SS A0501422 BOLT, HEX SS 1/4-20 X 1-1/2" A0513332 SPRING, DOOR A0713429 HINGE, LH ASSY A0313430 ARM, DOOR SPRING A0512320 GASKET, STEAM...
Page 77 Dish Racks, Line Strainer, PRV...
Page 78 Dish Racks, Line Strainer, PRV Item Part Description Qty. A101273 DISH RACK, FLAT-BOTTOM A101285 DISH RACK, PEG A104421 STRAINER, LINE 1/2" BRONZE A108265 VALVE, PRESSURE REGULATING (PRV)
Page 79 Blank Page This Page Intentionally Left Blank...
