American Dish Service
INSTALLATION INSTRUCTIONS
Model ET-AF-M/ET-AF-3 (Gravity-Drain)
Available in 90, 120, 150-second Time Cycles
Undercounter, Single-Rack, Chemical Sanitizer, Dump & Fill Dishmachine
Listed by UL #E68594, NSF/ANSI 3, ASSE 1004 #933, LA Test Labs File M-840044, Mass. License P3-0111-306
If you have questions, call 800-922-2178 or visit our website at
www.AmericanDish.com
The electrical power supplied to this machine is an imminent hazard that could result in severe
bodily injury or death if not properly installed or hooked up correctly. When working in the control
box or on electrical parts, always disconnect power and tag-out before servicing. Replace cover
to control box and other protective covers when fi nished servicing this equipment.
READ Manufacturer's Manual before Using this Product. For your safety read and observe all
cautions shown throughout these instructions. While performing installations described in this
booklet, wear approved Personal Protective Equipment, including Safety Eye-Wear.
Copyright ADS Installation Manual Model ET-AF Gravity, Revision 3.0 , 6/7/2013
Advertisement
Related Manuals for American Dish Service ET-AF-M
Summary of Contents for American Dish Service ET-AF-M
- Page 1 American Dish Service INSTALLATION INSTRUCTIONS Model ET-AF-M/ET-AF-3 (Gravity-Drain) Available in 90, 120, 150-second Time Cycles Undercounter, Single-Rack, Chemical Sanitizer, Dump & Fill Dishmachine Listed by UL #E68594, NSF/ANSI 3, ASSE 1004 #933, LA Test Labs File M-840044, Mass. License P3-0111-306 If you have questions, call 800-922-2178 or visit our website at www.AmericanDish.com...
- Page 2 See chemical manufacturer’s safe practices and MSDS sheets for handling and installing chemicals and supply containers. #1 BEFORE YOU BEGIN— American Dish Service provides this information as a service to our customers. Keep all instructions for future reference. ADS reserves the right to alter or update this information at any time.
-
Page 3: Electrical Section
The electrical power supplied to this machine is an imminent hazard that could result in severe bodily injury or death if not properly installed or hooked up correctly. Electrical—ET-AF-M/ET-AF-3 Gravity- Drain (120 volt, 20 amp) A time cycle of 90-seconds is the shortest time available for this model and is compliant with NSF listing. - Page 4 Optional buzzer for low level chemical alarm Optional chemical alarm pressure switch Power junction box for incoming 120v power Wash motor contactor to the left of the cam timer motor 1.5 HP Motor, arrow 1 arrow 2 point to L1 and Neutral connect points IT IS RECOMMENDED THAT THIS EQUIPMENT BE INSTALLED USING A NEW CIRCUIT BREAKER.
- Page 5 120°F required for this model of dishmachine, which demands a minimum of 60 GPH for ET-AF-M or ET-AF-3. Temperatures above 150°F exceed the operational design limits for these models. These models cannot be converted to high temp sanitizing by adding a booster.
- Page 6 INLET FLEX HOSE—Domestic style 1/2” fl exible braded hose should not be used to connect the dishmachine to plumbing. The ID of the plastic liner for this type hose restricts fl ow. However, ADS provides a 48” stainless fl ex hose that has large enough ID for adequate fl ow with P/N 088-1068 (see photo below, page 7).
- Page 7 Showing drain solenoid Drain outlet, 1.5” pipe ET (gravity) drain ball, note rubber washer on OPTIONAL 48” hot water inlet fl ex hose and push rod adapter (088-1068) CHEMICAL FEEDERS SECTION You must wear approved safety eye-wear before connecting chemicals. Read the chemical manufacturer’s MSDS sheets.
-
Page 8: Chemical Feeder Pumps
CHEMICAL FEEDER PUMPS Showing deter, rinse, sanitizer internal chemical pumps ADS provides three (3) peristaltic pumps to dispense liquid chemicals Chemical feed lines are color coded “Red” Detergent, “Green” Sanitizer, “Blue” Rinse-aid Pick-up tubes are provided for chemical product containers Sanitizer (chlorine) concentrations should be set at 50 parts per million Inspect the transfer tubing for any cuts or holes, keep them protected and secured out of the way Showing chemical lines above sump... - Page 9 TYPE OF CHEMICALS—Use only commercial grade low-energy chemicals. For proper operation, use non-foaming detergents and buffered sanitizer. Do not wash gold, pewter, silver, or silver-plate with chlorine based sanitizers. High concentrations of chlorine sanitizers and caustic detergents will cause damage to metals and welds. Do not exceed 50 parts-per-million (PPM) “free” or available chlorine. Any setting higher than 50 ppm will be dependent on local health requirements, however, the increased chlorine will result in higher corrosion of metal parts.
- Page 10 Cam timer adjustment tool Chlorine test strips Spray arm pressure tester #088-1048 To widen the notch (length = time energized) or close the notch use the timer adjustment tool, which is provided and taped to the control box shelf. This tool has two raised buttons that fi t into the holes on the side of each wheel.
- Page 11 Looking at the front of the cams with the cam timer assembly sitting on its mounting base #1 Cam: The white cam on the left is the master cam. It controls the total time of the cycle and is not adjustable.
-
Page 12: Final Installation Checklist
If this vapor lock occurs, check incoming water temperature and reduce the temperature if it is above 140- 150°F. Operating temperature of 120°F is the minimum, 130-140°F is recommended. If the problem is caused by low water pressure to the machine, then see the Plumbing Section above to correct that condition. - Page 13 Drain ball assembly and pump fi lter Optional ET (Gravity) secondary fi lter #085-6616 8 PUMP FILTER—Inspect the sump area and verify pump fi lter is in place. It should be removed and emptied only after the machine is completely drained. Verify that chemical feed lines are in their proper container and that lines are primed.
- Page 14 Copyright ADS Installation Manual Model ET-AF Gravity, Revision 3.0 , 6/7/2013...
