American Dish Service
INSTALLATION INSTRUCTIONS
Model ASQ Glasswasher
Available in 75-second cycle
Undercounter, Carousel, Chemical Sanitizer, Batch-type Glasswasher
Listed by UL #E68594, NSF/ANSI 3, LA Test Labs File M-810115, Mass. License P3-0111-306
If you have questions, call 800-922-2178 or visit our website at
www.AmericanDish.com
The electrical power supplied to this machine is an imminent hazard that could result in severe
bodily injury or death if not properly installed or hooked up correctly. When working in the control
box or on electrical parts, always disconnect power and tag-out before servicing. Replace cover
to control box and other protective covers when fi nished servicing this equipment.
Copyright ADS Installation Manual Model ASQ, Revision 2.0, 6/7/2013
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for American Dish Service ASQ
Summary of Contents for American Dish Service ASQ
- Page 1 When working in the control box or on electrical parts, always disconnect power and tag-out before servicing. Replace cover to control box and other protective covers when fi nished servicing this equipment. Copyright ADS Installation Manual Model ASQ, Revision 2.0, 6/7/2013...
- Page 2 See chemical manufacturer’s safe practices and MSDS sheets for handling and installing chemicals and supply containers. #1 BEFORE YOU BEGIN — American Dish Service provides this information as a service to our customers. Keep all instructions for future reference. ADS reserves the right to alter or update this information at any time.
-
Page 3: Electrical Section
110-120 volts. Attach a building ground wire to the green ground screw located in the junction box and tighten all wires. Replace the junction box cover. Copyright ADS Installation Manual Model ASQ, Revision 2.0, 6/7/2013... - Page 4 The sustainer snap action thermostat receives power any time the machine is switched on. IT IS RECOMMENDED THAT THIS EQUIPMENT BE INSTALLED USING A NEW CIRCUIT BREAKER. This machine does not use a booster heater. Copyright ADS Installation Manual Model ASQ, Revision 2.0, 6/7/2013...
- Page 5 #1 TANKLESS water heaters can be problematic for commercial dishmachines and glasswashers. The ADS model ASQ glasswasher requires the full cycle amount of water (1.2 gallon) supplied within 7 seconds. It has been the experience of ADS that tankless supply systems require multiple units plumbed in sequence with a recirculation loop to achieve proper pressure and temperature.
- Page 6 Water heaters or boilers must provide the minimum temperature of 120°F required for this model of machine, which has a minimum hourly demand of 57.6 GPH for ASQ. Temperatures above 150°F exceed the operational design limits for this model. This model cannot be converted to high temp sanitizing by adding a booster.
- Page 7 In the event of chemical contact to skin or eyes; wash immediately with fresh water and seek medical attention. Showing deter, rinse, sanitizer internal chemical Chlorine test strips for measuring sanitizer pumps Copyright ADS Installation Manual Model ASQ, Revision 2.0, 6/7/2013...
- Page 8 Remove the tube from the barb; turn the screw to the right for less sensitivity. Chemical must be placed on the fl oor of the cabinet for the pressure switch to work Copyright ADS Installation Manual Model ASQ, Revision 2.0, 6/7/2013...
- Page 9 CAM TIMER ADJUSTMENT SECTION Timer for the ASQ is a 7-cam. The cycle times are not adjustable. The cams of the timer are wheels whose positions are either fi xed or adjustable on its hub. Each cam controls a specifi c machine function, as noted on the timer decal.
- Page 10 Again, when this sound is heard, that would be the point to turn the water OFF. Seven seconds of full spray arm rinse pressure is required by health code. Operating temperature of 120°F is the minimum, 130-140°F is recommended. Copyright ADS Installation Manual Model ASQ, Revision 2.0, 6/7/2013...
-
Page 11: Final Installation Checklist
9) Verify incoming water temperatures 120°F minimum (130-140°F recommended). 10) Verify that chemical feed lines are in their proper container and that lines are primed. Prime switches are located on side of the control box and labeled. Copyright ADS Installation Manual Model ASQ, Revision 2.0, 6/7/2013... - Page 12 START THE CYCLE — by pushing the red start switch on the front of the glasswasher. The switch stays illuminated during operation. Wash, Rinse, and Sanitization occurs in 75 seconds. Copyright ADS Installation Manual Model ASQ, Revision 2.0, 6/7/2013...
- Page 13 Caution: Do not hit the scrap tray against a trash can. After cleaning, reassemble in reverse order. PUMP SEAL and IMPELLERS For Reversing pump Showing pump screen Diffuser w/spray arm pivot Diffuser removed, centrifugal Impeller Copyright ADS Installation Manual Model ASQ, Revision 2.0, 6/7/2013...
- Page 14 2 Spacer washers under propeller Small o-ring on top of propeller Large o-ring in top of impeller APPENDIX 089-9391---ASQ Parts Manual 089-9348---ASQ Service Manual 089-9303---Brochure 089-9441---Wall Chart 089-9444---Wire Diagram 089-9359---Spec Sheet 089-9381---ASQ Installation Manual Copyright ADS Installation Manual Model ASQ, Revision 2.0, 6/7/2013...
- Page 15 Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454 2940 Hwy 14 W, Rochester, MN 55901 Copyright ADS Installation Manual Model ASQ, Revision 2.0, 6/7/2013...
- Page 16 Total Restaurant Supply - https://totalsupply1.com - Toll Free 1-800-944-9304 - Local 507-288-9454 2940 Hwy 14 W, Rochester, MN 55901 Copyright ADS Installation Manual Model ASQ, Revision 2.0, 6/7/2013...
