Page 2
Notes in the text Of utmost importance there are the notes entitled WARNING. The notes entitled WARNING advise you on serious danger of damage to the heating device or of an injury. The note entitled Notice advises you on possible damage to your heating device. The note entitled Important calls your attention to the information important for the operation of your heating device.
2. Dimensions 2.1. Flue-pipe conn on the top Pos. 1: for external air input Pos. 2: convection air for 2nd room Pos. 3: flue pipe: inner diameter 80 mm...
3. Cleaning work WARNING Before starting any cleaning work, the stove must be cool down! Once the cleaning work is completed, the correct operating status of the device must be re- established: Put the combustion pot in correctly, close the combustion chamber door. 3.1.
Page 10
WARNING Cleaning the combustion pot may only be done with a cooled down stove in “OFF” operating mode. Otherwise there is a risk of burns! • Clean the burner with the supplied tool. (By scraping the burner wall, dirt falls down through the cleaning roller into the ash pan.) WARNING Do not dismantle the burner!
Page 11
Figure 1: Cleaning the combustion pot (using the supplied tool)
4. Maintenance work WARNING Before starting any cleaning work, the stove must be cool down! The mains plug must be pulled out of the power supply socket (always in advance)! The frequency of maintenance in turn depends to a large extent on the pellet quality (ash content). Quality pellets have a low ash content of about 0.2-0.3%.
4.2. Cleaning the flue gas passes CAUTION Check and clean the flue-gas ways, exhaust (flue-gas) fan and flue-gas ducts at the latest after 1000 kg of pellets have been consumed. Clean with a brush or an ash extractor. CAUTION After completion of the cleaning make sure that when putting back the covers, the seals are seated in the right positions.
4.2.1. Cleaning the flue baffle After consuming 1000 kg of pellets or after a year of operation, it is necessary to clean the deflector using the enclosed tool. CAUTION To remove the deflector, you must retract the flame temperature sensor - otherwise the deflector cannot be removed.
4.3. Cleaning the pellet container - annual maintenance • Heat the pellet stove until the storage tank is completely empty. • Then clean the tank and the intake of the screw conveyor housing with a vacuum cleaner. Figure 3: Pellet tank...
5. Replacement parts list 5.1. Replacement parts list (without trim parts) Description Pos. Piece No. PR Replacement parts list (without trim parts) Complete combustion chamber door/ 1 piece 0545508005300 anthracite Ash-pan door/anthracite 1 piece 0545908005520 Ash pan 1 piece 0545908005604 Protection grate 1 piece 0545508005739...
Page 18
Draught baffle plate 1 piece 0545908005700 1 piece Door contact switch 0089500040005 Cleaning roller 1 piece 0545508905130 Screw conveyor motor 1 piece 0089500880005 Complete control unit 1 piece 0545508005576 Backup battery CR 2032 1 piece Relay 1 piece 0545508005583 Flame temperature sensor 1 piece 0553808005541 Seal, tank cover (600 mm)
5.3. Replacement parts list Description Pos. Piece No. PR Replacement parts list Side wall right/black-glossy 1 piece 0545908005260 Side wall right/white 1 piece 0545908015260 Side wall right/grey 1 piece 0545908025260 Side wall rear right/black-glossy 1 piece 0545908005263...
Page 21
Side wall rear right/white 1 piece 0545908015263 Side wall rear right/grey 1 piece 0545908025263 Front plate/black-glossy 1 piece 0545908005310 Front plate/white 1 piece 0545908015310 Front plate/grey 1 piece 0545908025310 Side wall left/black-glossy 1 piece 0545908016260 1 piece Side wall left/white 0545908026260 Side wall left/grey 1 piece...
