HSP 4 Parma
HSP 4 Parma
Equipment sheet
GB
Pellet stove
0545508511400g

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HSP 4 Parma and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HAAS + SOHN HSP 4 Parma

Summary of Contents for HAAS + SOHN HSP 4 Parma

  • Page 1 Equipment sheet HSP 4 Parma HSP 4 Parma Equipment sheet Pellet stove 0545508511400g...
  • Page 2 Introduction We thank you very much for purchasing our product! The description of the heating device will inform you in detail about the design, technical specification and operation of the heating device. We recommend you to acquaint yourselves closely with these data. In this way, you will avoid possible faults during the proper assembly and operation.

  • Page 3: Table Of Contents

    Contents 1. Technical data..........................1 2. Dimensions........................... 2 3. Pellet Stove Installation and Connection to Chimney............3 4. Cleaning work ..........................7 4.1. Cleaning the surface ......................... 7 4.2. Cleaning the glass panel ......................7 4.3. Clean combustion chamber “function instruction” Error F040..........7 4.4.
  • Page 4 Important Information from Manufacturer! IMPORTANT Please, observe the following instructions: Quality of wood pellets: Depending on the manufacturer, there are light, dark, shorter or longer pellets. Even deliveries from one supplier may contain different qualities. Standards for wood pellets are constantly tightened, but: The wood remains wood and has its peculiarities in terms of ash and slag.

  • Page 5: Technical Data

    1. Technical data HSP 4 Parma Nominal Partial output Partial output output Heat output range: 8,5 kW 4,2 kW 2,5 kW Nominal heat output: 8,5 kW Test conditions defined by norm: EN 14785 Height: 1208 mm Width: 564 mm Depth:...

  • Page 6: Dimensions

    2. Dimensions Pos. 1: for external air input Pos. 2: convection air for 2nd room Pos. 3: flue pipe: inner diameter 80 mm...

  • Page 7: Pellet Stove Installation And Connection To Chimney

    3. Pellet Stove Installation and Connection to Chimney The pellet stoves must be connected to a separate chimney. It is not permissible to divert flue gas from other equipment to this chimney. Flue gases are fed through an 80 mm smoke duct connected to the stove smoke- flue being located on the rear side of the stoves.
  • Page 8 Figure 1.1: Chimney outside the building A) Chimney situated outside the building B) Effective chimney height. The chimney must be led above the roof level and fitted with thermal insulation C) External air inlet to the heater D) T-piece with stopper E) Condensate collector...
  • Page 9 Figure 1.2: Chimney as a part of building A) The smoke-flue inserted into the existing chimney. Here, the possibility of cleaning is required. B) Effective chimney height. C) External air inlet to the heater D) T-piece with stopper E) Condensate collector...
  • Page 10 Figure 1.3: Connection to the existing chimney A) Existing chimney B) Effective chimney height. C) External air inlet to the heater D) Condensate collector E) Smoke-flue...

  • Page 11: Cleaning Work

    4. Cleaning work WARNING Before starting any cleaning work, the stove must be cool down! Once the cleaning work is completed, the correct operating status of the device must be re- established: Put the combustion pot in correctly, close the combustion chamber door. 4.1.
  • Page 12 WARNING Cleaning the combustion pot may only be done with a cooled down stove in “OFF” operating mode. Otherwise there is a risk of burns! • Clean the burner with the supplied tool. (By scraping the burner wall, dirt falls down through the cleaning roller into the ash pan.) WARNING Do not dismantle the burner!
  • Page 13 Figure 2: Cleaning the combustion pot (using the supplied tool)

  • Page 14: Maintenance Work

    5. Maintenance work WARNING Before starting any cleaning work, the stove must be cool down! The mains plug must be pulled out of the power supply socket (always in advance)! The frequency of maintenance in turn depends to a large extent on the pellet quality (ash content). Quality pellets have a low ash content of about 0.2-0.3%.

  • Page 15: Cleaning The Flue Gas Passes

    5.2. Cleaning the flue gas passes CAUTION Check and clean the flue-gas ways, exhaust (flue-gas) fan and flue-gas ducts at the latest after 1000 kg of pellets have been consumed. Clean with a brush or an ash extractor. CAUTION After completion of the cleaning make sure that when putting back the covers, the seals are seated in the right positions.

  • Page 16: Cleaning The Flue Baffle

    5.2.1. Cleaning the flue baffle After consuming 1000 kg of pellets or after a year of operation, it is necessary to clean the deflector using the enclosed tool. CAUTION To remove the deflector, you must retract the flame temperature sensor - otherwise the deflector cannot be removed.

  • Page 17: Cleaning The Pellet Container - Annual Maintenance

    5.3. Cleaning the pellet container - annual maintenance • Heat the pellet stove until the storage tank is completely empty. • Then the protective grille (1) in the pellet tank may be removed. • Then clean the tank and the intake of the screw conveyor housing with a vacuum cleaner. •...

  • Page 18: Replacement Parts List

    6. Replacement parts list 6.1. Replacement parts list (without trim parts) Description Pos. Piece No. PR Replacement parts list (without trim parts) Complete combustion chamber door/ 1 piece 0545508005300 anthracite Ash-pan door/anthracite 1 piece 0545908005520 Ash pan 1 piece 0545908005604 Protection grate 1 piece 0545508005739...
  • Page 19 Combustion chamber cladding left 1 piece 0545508005211 Combustion chamber cladding back 1 piece 0545508005210 Combustion chamber cladding right 1 piece 0545508005212 Draught baffle plate 1 piece 0545508005700 1 piece Door contact switch 0089500040005 Cleaning roller 1 piece 0545508905130 Screw conveyor motor 1 piece 0545508007120 Complete control unit...

  • Page 20: Detail A1

    1 piece Cover 0545508025087 4 piece Stand 0551908506005 Flue way bend 1 piece 0545508006145 Flue way T-piece 1 piece 0545508006120 1 piece Condensate collector 0545508006130 6.2. Detail A1 Description Pos. Piece No. PR Detail A1 Screwing door — Set 1 piece A1.1.

  • Page 21: Replacement Parts List

    6.3. Replacement parts list Description Pos. Piece No. PR Replacement parts list Front plate/black-glossy 1 piece 0545508015280 Front plate/white 1 piece 0545508025280 Side wall right/black-glossy 1 piece 0545508015265 Side wall right/white 1 piece 0545508025265 Side wall left/black-glossy 1 piece 0545508015260 1 piece Side wall left/white 0545508025260...
  • Page 22 1 piece Back wall 1 0545508005117 1 piece Back wall 2 0545508005119...

  • Page 23: Circuit Diagram

    7. Circuit diagram 7.1. Circuit diagram IO 57.1...
  • Page 24 Description circuit diagram: Description cable harness No.: Mains plug / mains filter Electric ignition Screw conveyor motor — relay Screw conveyor motor — relay Induced draught Cleaning roller Conv. fan Screw conveyor motor — relay 12– Flue gas fan rotation speed 18–...

  • Page 25: Circuit Diagram Relay + Human Presence Detection

    7.2. Circuit diagram relay + human presence detection Steuer- Braun platine Steuer- Schwarz platine Description circuit diagram: Description cable harness No.: A1/A2 Control board Control board Screw conveyor motor Description circuit diagram human presence detection: Description cable harness No.: Control board Control board Control board...
