Nady Systems WS-16U Owner's Manual

Nady Systems WS-16U Owner's Manual

16-channel uhf pll synthesized wireless system

Advertisement

Quick Links

SERVICE
(U.S.) Should your Nady Wireless Microphone System require service, please contact
the Nady Service Department via telephone at (510) 652-2411 or e-mail to
service@nady.com for a Return Authorization (R/A) Number and a service quote (if
out of warranty). Make sure the R/A Number is clearly marked on the outside of the
package and enclose a cashier's check or money order (if not prepaid with a credit card).
Ship the unit prepaid to: Nady Systems, Inc., Service Department, 6701 Shellmound
Street, Emeryville, CA 94608. Include a brief description of the problems you are experi-
encing.
The warranty card enclosed with this system contains additional valuable war-
ranty and service information. Keep it in a safe place for future possible refer-
ence. Do not attempt to service this unit yourself as it will void the warranty.
(International) For service, please contact the Nady distributor in your country through
the dealer from whom you purchased this product.
Nady Wireless Systems are type accepted under FCC rules parts 90, 74
and 15. The device complies with RSS-210 of Industry & Science Canada.
Operation is subject to the following two conditions: (1) this device may not
cause harmful interference and (2) this device must accept any interference
received, including interference that may cause undesired operation.
NADY SYSTEMS, INC.
6701 Shellmound Street • Emeryville, CA 94608 USA
Tel: 510.652.2411 • Fax: 510.652.5075 • www.nady.com
WS-16U
16-Channel UHF PLL Synthesized
Wireless System
OWNER'S MANUAL
