Perma PRO LINE Quick Start Manual

perma PRO LINE
Quick Start Guide
Assembly
1 INSERT BATTERY
Battery PRO B
(Back-up battery)
Catch
Insert the battery PRO B into the drive unit (according to
the direction of the arrow on the label).
3 DISCHARGE OPENING
Push the PRO LC into the protection cover until
lubricant comes out of the opening
The Expert in Lubrication Solutions
No function!
Setting of PRO LC size
is done via menu on
the display.
Gear theeth
2 COVER FOR PRO LC & PLUG
Protection cover for PRO LC
Place the PRO LC inside the protection cover and remove
the plug of the PRO LC.
4 DRIVE
1
2
Place the PRO LC with its protection cover on the drive unit.
Turn the cover clockwise until the bayonet catch locks.
Scan the QR code
for a video tutorial.
PRO LC
Plug
