- Page 1 CHAPTER 6 Setting Up the System CHAPTER 7 Customizing Screen Displays CHAPTER 8 Creating Calibration Curves CHAPTER 9 Troubleshooting Index KOBE, JAPAN Code No. BL022510 SMN: 11209614 Date of Last Revision: October 2014 Software Version: 01-13 onwards © SYSMEX CORPORATION 2012-2014...
-
Page 3: Table Of Contents
Creating a calibration curve before analyzing a sample on the tracks ..8-1 Creating a calibration curve while analyzing a sample on the tracks ..8-1 CS-5100 LAS Instructions for Use Revised October 2014... - Page 4 Other information ..........9-3 Index CS-5100 LAS Instructions for Use Revised October 2014...
-
Page 5: Chapter 1 Introduction
Chapter 1 Introduction Thank you for purchasing the CS-5100 LAS. The CS-5100 LAS enables the CS-5100 to automatically analyze the samples coming from the tracks of the facility. When the CS-5100 detects the sample that was transported by the LAS (Laboratory Automation System) to the sample aspiration position, the sample arm A of the CS-5100 automatically aspirates and analyzes the sample. -
Page 6: Hazards In This Manual
Background information and practical tips. 1.2 Protected names • Sysmex is a registered trademark of SYSMEX CORPORATION. • Other registered trademarks or trademarks referenced are property of their respective owners. The fact that a trademark is not explicitly mentioned in this manual does not authorize its use. -
Page 7: Design And Function
Risk of infection Never touch the tip of the probe. The probe tip is sharp and very dangerous. Handle it with care. Accidentally touching the probe tip could cause injury and infection by pathogens. CS-5100 LAS Instructions for Use Revised October 2014... -
Page 8: Specifications
Pneumatic Unit: approx. 280 (W) × approx. 355 (D) × approx. 400 (H) mm, approx. 17 kg * The above includes the Sampler Unit except the projections. The IPU and other options are not included. CS-5100 LAS Instructions for Use Revised October 2014... -
Page 9: Chapter 2 Basic Operations
Instrument control status Communication Displays the communication status between the CS-5100 and the LAS by status color. Color Communication status Green Connecting Communication error Gray The power of CS-5100 or LAS is turned OFF. CS-5100 LAS Instructions for Use Revised October 2014... -
Page 10: Disconnecting The Las
[OK]. 2.4 Shutting down To shut down the instrument properly, refer to the procedures described in the CS-5100 Instructions for Use. (➤ CS-5100 Instructions for Use “Chapter 3: 3.4.6 Shutdown”) CS-5100 LAS Instructions for Use Revised October 2014... -
Page 11: Chapter 3 Performing Analysis
Check that the communication status is green on the LAS connection status display of the status bar. (➤ P.2-1 “Chapter 2: 2.2 Checking the LAS connection status”) (➤ P.2-2 “Chapter 2: 2.3 Disconnecting the LAS”) CS-5100 LAS Instructions for Use Revised October 2014... -
Page 12: Analyzing A Sample While Analyzing Another Sample On The Tracks
Set the sample rack containing a sample to the right rack pool of the CS-5100 sampler. This halts the analysis on the tracks and starts the analysis on the sampler’s sample. After aspiration of the sampler's sample is completed, the analysis on the tracks resumes automatically. CS-5100 LAS Instructions for Use Revised October 2014... - Page 13 Or press the [Start] button on the IPU toolbar. This halts the analysis on the tracks and proceeds the analysis on the STAT sample. After aspiration of the STAT sample is completed, the analysis on the tracks resumes automatically. CS-5100 LAS Instructions for Use Revised October 2014...
- Page 14 Chapter 3 Performing Analysis CS-5100 LAS Instructions for Use Revised October 2014...
-
Page 15: Chapter 4 Checking Analysis Results
(7) Tick the [Use Filter] checkbox. (8) Select both [Specify Sample Distinction Code.] and [LAS Sample]. Remove all other checkboxes. (9) Press [Save]. The [Filter / Sort / View] dialog box closes and the conditions are saved. CS-5100 LAS Instructions for Use Revised October 2014... - Page 16 Select the item that you specified at step 1 for the display conditions of the [Joblist] screen. (➤ CS-5100 Instructions for Use “Chapter 3: 3.9.2.2 Changing the conditions of analysis results to be displayed”) The analysis results only of track sample appear on the [Joblist] screen. CS-5100 LAS Instructions for Use Revised October 2014...
-
Page 17: Chapter 5 Performing Qc Analysis
Disconnect the CS-5100 from the LAS. (➤ P.2-2 “Chapter 2: 2.3 Disconnecting the LAS”) Set the control on the CS-5100 to perform QC analysis. (➤ CS-5100 Instructions for Use “Chapter 3: 3.10 Performing QC analysis”) CS-5100 LAS Instructions for Use Revised October 2014... -
Page 18: Performing The Qc Analysis With The Control Set On The Cs-5100 While Analyzing A Sample On The Tracks
Register the order. This halts the analysis on the track sample and starts the QC analysis. When aspiration of the control is completed, the analysis on the track sample will resume automatically. CS-5100 LAS Instructions for Use Revised October 2014... -
Page 19: Performing The Qc Analysis For The Tracks
According to the sample ID that was identified by the LAS, the instrument acquires the order information from the host computer. The track control is carried to the sample aspiration position for the analysis. CS-5100 LAS Instructions for Use Revised October 2014... - Page 20 Chapter 5 Performing QC Analysis CS-5100 LAS Instructions for Use Revised October 2014...
-
Page 21: Chapter 6 Setting Up The System
(➤ CS-5100 Instructions for Use “Chapter 4: 4.1.7.6 [Sample Volume Check] screen”) [Sample Volume Check] screen [LAS] When checking the sample volume with respect to the sample on the tracks, tick this checkbox to set the range of sample volume (liquid level). CS-5100 LAS Instructions for Use Revised October 2014... -
Page 22: Order Inquiry] Screen
Select the assay group you want to specify as fixed parameters from [Test List] and press [OK]. Multiple assay groups can be selected. The selected assay groups are set as fixed parameters. CS-5100 LAS Instructions for Use Revised October 2014... -
Page 23: Chapter 7 Customizing Screen Displays
[Filter / Sort / View] dialog box (when the [Filter] tab is selected) [LAS] Tick this check box to display the data of the sample that was analyzed on the tracks. CS-5100 LAS Instructions for Use Revised October 2014... - Page 24 Chapter 7 Customizing Screen Displays CS-5100 LAS Instructions for Use Revised October 2014...
-
Page 25: Chapter 8 Creating Calibration Curves
Register the order. This halts the analysis on the track sample and creates the calibration curve. When aspiration of the calibrator is completed, the analysis on the track sample will resume automatically. CS-5100 LAS Instructions for Use Revised October 2014... - Page 26 Chapter 8 Creating Calibration Curves CS-5100 LAS Instructions for Use Revised October 2014...
- Page 27 Check the LAS status. action 24007 Sample with no order arrived at aspiration position(LAS) Probable LAS sent Sample Aspiration Start Request command without sending Sample ID Notification cause command. Corrective Check the LAS status. action CS-5100 LAS Instructions for Use Revised October 2014...
- Page 28 LAS. Corrective Check the LAS status. action Contact your local service representative for more information on any error messages that are not explained in this manual or the CS-5100 Instructions for Use. CS-5100 LAS Instructions for Use Revised October 2014...
- Page 29 Analysis was not completed and Abort command. must be repeated. 24025 LAS communication is 1) The instrument or LAS Analysis was not completed and disconnected. become power-off. must be repeated. 2) Communication error CS-5100 LAS Instructions for Use Revised October 2014...
- Page 30 Chapter 9 Troubleshooting CS-5100 LAS Instructions for Use Revised October 2014...
- Page 31 Customizing screen displays ......7-1 Design and function ...........1-3 [Detail] dialog box ..........9-3 Disconnecting the LAS ........2-2 [Filter / Sort / View] dialog box ......7-1 Hazards ..............1-2 [Joblist] screen ...........4-1 [Order Inquiry] screen ........6-2 CS-5100 LAS Instructions for Use Revised October 2014...
- Page 32 Index CS-5100 LAS Instructions for Use Revised October 2014...
