- Page 1 Ivy Small Sideboard 453/6563 hygena Width - 90cm Depth - 40cm Height - 80cm Issue 1-28-10-15...
- Page 2 Do not stand or put excessive weight on the product, this could cause damage.
- Page 3 0345 6400 800 Underside Underside Top panel Base panel (90x39.7x1.5cm) (90x39.7x1.5cm) Inside Inside Side panel (right) Side panel (left) (32x39.7x1.5cm) (32x39.7x1.5cm) Divider Drawer front x 2 (32x39.7x1.5cm) (53x15.5x1.5cm) Drawer side panel (left) x 2 Drawer side panel (right) x 2 (35x8.5x1.2cm) (35x8.5x1.2cm) Drawer back x 2...
- Page 4 0345 6400 800 Back panel Door (31.5x31.5x1.5cm) (89.8x34.8x0.3cm) Shelf Legs x 4 (38x31.8x1.5cm)
-
Page 5: Tools Required
Components - Fittings 0345 6400 800 Large locking nut x 12 Small locking nut x 8 Metal dowel x 20 4 x 30mm Screw x 8 Drawer runner x 2 sets Wooden dowel x 12 3.5 x 12mm Screw x 24 M4 x 16mm Screw x 6 Handle x 3 M6 x 12mm Screw x 20... - Page 6 Assembly lnstructions Preparing panels Place top panel , base panel and drawer front flat on the floor with the fixing holes facing up. Screw metal dowels into each panel as shown. Note: Screw metal dowels as far as shown. Do not overtighten. Insert wood dowels into top panel base panel...
- Page 7 Assembly lnstructions Assembling base panel With help, carefully locate base panel into position as shown. Insert large locking nuts into side panels and divider Turn locking nuts clockwise to secure. Shown upside down Assembling legs Assemble legs to base panel using screws...
- Page 8 Assembly lnstructions Assembling back panel With help, carefully turn the unit onto it's front. Note: Ensure the unit is straight and square. Place back panel into the recess around the back of the unit. Secure using screws Base Note: As shown, ensure you leave two holes clear at the top of the back panels for later assembly...
- Page 9 Assembly lnstructions Assembling door and shelf a: Insert shelf support pins into left side panel and divider at the desired height. Carefully locate shelf onto the support pins. b: Assemble hinges door using screws Fit handle to door using screws c: Assemble door left side panel using...
- Page 10 Assembly lnstructions Hinge adjustment To move doors up or down, loosen screws as shown and move doors to suit. Once doors are aligned, insert 2 more screws into the hinge plates and fully tighten all screws. To move doors in or out, loosen screw shown and move doors to suit.
- Page 11 Assembly lnstructions Assembling drawers a: Locate drawer back in between drawer side panels . Secure using screws shown upside down b: Place drawer base into the groove in back panel c: Locate drawer front onto the drawer body. Insert small locking nuts into drawer sides Turn locking nuts clockwise to secure.
- Page 12 Assembly lnstructions Locating drawers Carefully slide drawers into position as shown. Fixing to wall It is recommended that the unit is fixed to the wall to ensure stability. Assemble wall straps the back edge of the top panel using screws plain washer With help, move the unit to the desired location.
