Berkeley - Bookcase
Assembly Instructions -
hygena
Dimensions
Width - 49.5cm
Depth - 33cm
Height - 165cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800
Please keep for future reference
411/9681
MADE IN
BRITAIN
Issue 1 - 11/05/15
Advertisement
Related Manuals for hygena Berkeley 411/9681
Summary of Contents for hygena Berkeley 411/9681
- Page 1 Berkeley - Bookcase Assembly Instructions - 411/9681 Please keep for future reference hygena Dimensions Width - 49.5cm Depth - 33cm MADE IN Height - 165cm BRITAIN Important - Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 03456 400800...
-
Page 2: Care And Maintenance
Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 24kgs. space to layout the parts before recommend the Please lift with care. starting. - Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the panels listed below These 2 holes are through-holes Middle Shelf (DF3746) (461 x 323mm) These 2 holes are through-holes Left End...
- Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 03456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
- Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 03456 400800 quoting the reference numbers below Step 1 Prepare the left end Screw 6 metal dowels into the left end Note: Tighten the metal Finished front edge dowels up fully against the panels.
- Page 6 Assembly Instructions Step 4 Fit the middle shelf to the right end Push the middle shelf onto the right end Use a screwdriver to tighten the 2 large locking nuts fitted to the middle shelf Through-holes Note: Turn the large Finished Finished locking nuts...
- Page 7 Assembly Instructions Step 7 Fit a divider Push a divider onto the middle shelf Finished front edge Step 8 Fit the bottom shelf Push the bottom shelf onto the right end and the divider Use a screwdriver to tighten the 2 large locking nuts fitted to the bottom shelf...
- Page 8 Assembly Instructions Step 10 Fit the top shelf Push the top shelf onto the right end and the divider Through-holes Use a screwdriver to tighten the 2 large locking nuts fitted to Finished the top shelf front edge Step 11 Fit the left end Push the left end onto the assembly.
- Page 9 Assembly Instructions Step 13 Fit the base Fit the base onto the left end and the right using 4 screws Step 14 Prepare the top Screw 4 metal dowels into the top Finished front edge Step 15 Fit a divider Push a divider onto the top shelf...
- Page 10 Assembly Instructions Step 16 Fit the top Push the top onto the left end and the right end Use a screwdriver to tighten the 4 large locking nuts fitted to the left end and the right end Finished front edge Step 17 Note: The raised part of the leg bracket must...
- Page 11 Assembly Instructions Step 18 The measurement from top corner X to bottom corner X must be Fit the back equal to the measurement from top corner Y to bottom corner Y Square up the unit by making sure that measurement x to x equals y to y.
- Page 12 Assembly Instructions Step 20 Example Attach the Attach the Fit the overbalance Screw strap to the wall strap to the unit protector kit Washer Wall fixing Strap To prevent possible Strap (not supplied) overbalancing we Washer recommend that this unit is secured to a suitable Screw wall by fitting of the...
