Chapton 4',4'6" and 5' Ottoman Beds
Assembly Instructions
hygena
Dimensions (4')
Length - 203cm
Width - 130cm
Height - 85cm
Important
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 0345 6400 800
Please keep for future reference
Dimensions
(4'6)
Length - 203cm
Width - 145cm
Height - 85cm
Dimensions
(5')
Length - 213cm
Width - 160cm
Height - 85cm
572/6114
545/9223
557/1565
544/1633
578/8822
531/7901
Issue 1 - 09/05/16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for hygena Chapton 545/9223
Summary of Contents for hygena Chapton 545/9223
- Page 1 Chapton 4',4'6" and 5' Ottoman Beds Assembly Instructions Please keep for future reference 572/6114 545/9223 hygena 557/1565 544/1633 578/8822 531/7901 Dimensions (4') Dimensions Dimensions (4'6) (5') Length - 203cm Length - 213cm Length - 203cm Width - 130cm Width - 145cm...
- Page 2 Safety and Care Advice Check you have all the Assemble the item as close We do not to its final position (in the same recommend the components and tools listed on pages 2, 3 and 4. room) as possible. use of power drill/drivers for Remove all fittings from the Assemble on a soft level...
- Page 3 0345 6400 800 INSIDE INSIDE FRONT INSIDE Hinges x 2 Piston x 2 (750 x 115mm) (420mm) Base panel x2 Feet x 4 Base panel x1 Ottoman end frame (Headboard) x 1 Ottoman end frame (Footboard) x 1...
- Page 4 0345 6400 800 Ottoman frame (Sides) x 2 Bentwood slats x28(4'-600*9*53mm) (4'/4'6-1822*30mm)(5'-1925*30mm) Bentwood slats x28(4'6-675*9*53mm) Bentwood slats x30(5'-750*9*53mm) Ottoman frame centre rail x 1 Base support x 4 (4'/4'6-1822*30mm)(5'-1925*30mm) (120 x 20mm) Central support x 1 Short support leg x 2 (4'/4'6-1930*80mm) (5'-2030*80mm) Wooden support rail x 2 Double slat caps x 14 (4'-5.5mm)
-
Page 5: Tools Required
Components - Fittings 0345 6400 800 45mm M8 Bolt x 2 25mm M8 Bolt x 20 15mm M6 Bolt x 32 35mm M4 Wood screw x 28 Nut x 4 19mm Flat washer x 14 5mm Allen key x 1 14mm Flat washer x 4 Plastic cap x 2 4mm Allen key x 1... - Page 6 Assembly Instructions Attaching feet a: Attach 2 x Feet the underside of the headboard using screws as shown. Repeat on the underside of the footboard Note: The position is outlined.
- Page 7 Assembly Instructions Preparing footboard Attach the ottoman frame support to the footboard using fixings shown. Attach base supports to the footboard headboard shown using screws Note: The positions should be outlined.
- Page 8 Assembly Instructions Attaching side rails Loosely fit bolts into headboard footboard as shown. With help, raise the headboard into the standing position. Hang the metal brackets on the end of the side rails , over the bolts in the headboard Note: Ensure the 4 holes on the inside of...
- Page 9 Assembly Instructions Preparing base Attach the short support legs to the underside of the central support using bolts Fit plastic caps into support legs Assemble central support in between headboard footboard using fixings at both ends. Assemble wooden support rails between side rails using screws Finally, fully tighten all...
- Page 10 Assembly Instructions Completing base With help, carefully slide base panels inside the bed frame as shown. Attaching folding hinges Secure the hinges to the side rails & using bolts as shown. Note: Ensure the hinges are fitted the correct way around as shown.
- Page 11 Assembly Instructions Assembling ottoman frame Assemble long support legs to the underside of centre rail and end frame using screws b: Assemble ottoman frame components together as shown. Note: Secure the assembly using fixings as shown. Important Do not fully tighten screws at this stage.
- Page 12 Assembly Instructions Locating ottoman frame With help, lift the ottoman frame into position onto hinges Note: The frame is heavy, lift with care. Secure on both sides using screws Once assembly is complete, fully tighten all screws around the ottoman frame.
- Page 13 Assembly Instructions Attaching single slat caps Assemble single slat caps onto one end of bentwood slats Attaching slats Fit bentwood slats into the ottoman frame (sides) by locating single slat caps into the holes. Fit bentwood slats into both sides of double slat caps , before pushing caps...
