Bergen 5 drawer chest
Assembly Instructions
Dimensions
Width - 45.6cm
Depth - 38.1cm
Height - 101.5cm
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
Argos = 03456 400 800
- Please keep for future reference
557/2911
OAK
575/9576
WALNUT
549/4006
WHITE
571/3079
WHITE HG
576/9470
WHITE/MIRROR
Tip : To prevent damage,
we recommend that you
build your unit on the
carton(s) it was packed in.
557/2911
575/9576
549/4006
571/3079
576/9470
Issue: 3 - 19/12/16
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for hygena Bergen 557/2911
Summary of Contents for hygena Bergen 557/2911
- Page 1 Bergen 5 drawer chest Assembly Instructions 557/2911 - Please keep for future reference 575/9576 549/4006 571/3079 576/9470 Dimensions Tip : To prevent damage, Width - 45.6cm we recommend that you 557/2911 Depth - 38.1cm build your unit on the 575/9576 WALNUT 549/4006 WHITE...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • To reduce components and tools listed or put weight on the product, the likelihood of on the following pages.
- Page 3 Components - Panels If you have damaged or missing components, 03456 400 800 call the Customer Helpline: Please check you have all the panels listed below Right side Back Broad Left side (963x380x15) (974x435x2,5) (963x380x15) P2191 BO3443 P2192 Foot Bottom (410x340x22) (455x381x15) (456x381x15)
- Page 4 Components - Fittings Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required. FK1322 FK1400 FK1309 Screw x 4 Screw x 1 Pozi Screw x 85 (4x30mm)
- Page 5 Assembly Instructions Step 1 If Highgloss, Prepare the drawer Please remove the protective film! fronts Screw 2 locking screw E into the holes shown on the back of each drawer front 7 . Note: Insert locking screw E as far as shown. Do not over tighten.
- Page 6 Assembly Instructions Step 1 continued finishing the drawers Turn over drawer and slide drawerbase supports J in corner as shown and fix them, using the attached screws . Step 2 Attaching runners Fix runner right part A R on right side 3 as shown using euro screw drawer D and pozi screw C.
- Page 7 Assembly Instructions Step 3 Finished Attaching runners front edge Fix runner left part A P on left side 1 as shown using euro screw drawer D and pozi screw C. Insert 4 Large locking nuts G into left side 1 where shown.
- Page 8 Assembly Instructions Step - 5 Attaching top Position plinth 0 onto right side 1 . Use a screwdriver to turn locking nuts G clockwise to lock. Position right side 3 onto plinth 0 . Use a screwdriver to turn locking nuts G clockwise to lock.
- Page 9 Assembly Instructions Step - 7 A: Attaching bottom Position bottom 3 onto left & right side 1 , 3. Use a screwdriver to turn locking nuts G clockwise to lock. Finished front edge A: Attaching felt Stick the selfadhesive felt L strategically underneath the foot 5.
- Page 10 Assembly Instructions Step - 8 Insert back board Turn chest upright and slide back board 5 in the groove. Step 9 a: Prepare top Screw 4 locking screw E into the holes shown on top Note: Insert locking screw Eas far as shown.
- Page 11 Assembly Instructions Step - 9 continued Attaching top Position top 6 onto left & right side 1 , 3. Use a screwdriver to turn locking nuts G clockwise to lock. Finished front edge Step - 10 Fixate back board Slide drawerbase supports J in corner as shown and fix them, using the attached screws .
- Page 12 Assembly Instructions Step 11 Attaching runners Fix runner left and right side B Q and S on left & right drawer side @ and ! as shown using 12,5mm pozi screw C. Step 12 Attaching drawer handle Attacht drawer handle M on drawer front 7 as shown using 12,5mm pozi screw C.
- Page 13 Assembly Instructions Step - 1 Fixing to wall It is recommended that the chest is fixed to a wall. position L-bracket I onto top 6 as shown , fix by using 15mm screw Note: there are no pre- drilledholes for 15mm screw B With help, move chest into position.
-
Page 14: A Guide To - Wall Mounting & Fixings
A Guide to - Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are suitable for supporting your unit.
