hygena Valencia Assembly Instructions Manual

Hide thumbs Also See for Valencia:

Advertisement

Table of Contents

Valencia -
Assembly Instructions -
hygena
Dimensions
Width - 50cm
Depth - 59cm
Height - 87cm
Important -
Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline: 08456 400800
500mm Base Cabinet
Please keep for future reference
Cabinet
Black Door Pack
Cream Door Pack
Oak Door Pack
White Gloss Door Pack
White HN Door Pack
656/5776
633/2882
633/2710
205/4009
633/2806
192/3722
MADE IN
BRITAIN
Issue 2 - 31/07/14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Valencia and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for hygena Valencia

Summary of Contents for hygena Valencia

  • Page 1 Valencia - 500mm Base Cabinet Assembly Instructions - Please keep for future reference Cabinet 656/5776 hygena Black Door Pack 633/2882 Cream Door Pack 633/2710 Oak Door Pack 205/4009 White Gloss Door Pack 633/2806 White HN Door Pack 192/3722 Dimensions Width - 50cm...
  • Page 2 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 16.5kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 3 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Base (DPF074A) (469 x 494mm) Left Side Right Side (DPF068A) (DPF069A) (720 x 560mm) (720 x 560mm)
  • Page 4 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 5 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 If you would If you would Choose which way like your door like your door you would like the to open this to open this door to open...
  • Page 6 Assembly Instructions Step 3 Prepare the right side Refer to step 1 and, if required, fit 2 hinge plates onto the right side , making sure 150mm that the slot is facing towards the front edge. Screw 4 metal dowels into the holes shown on the right side Fit a bracket...
  • Page 7 Assembly Instructions Step 5 Fit the legs to the base Push the leg sockets into the holes in the base as shown. Secure each leg socket with 3 screws Tap in the centre plug on each leg socket Push the leg into the leg socket Step 6...
  • Page 8 Assembly Instructions Step 8 Fit the 2 cross rails Push each cross rail onto the right side Support this cross rail until the left side has been Use a screwdriver to fitted in the next step. tighten the large locking fitted to each cross rail Note: Turn the large...
  • Page 9 Assembly Instructions Step 10 Fit the back Slide the back along the grooves in the side panels Step 11 Secure the back The bottom edge of the back must be flush with the bottom edge of the base Secure the back the back edge of the base using 3 screws...
  • Page 10 Assembly Instructions Step 12 Warning: Take care when Secure the unit to the drilling the wall wall that you do not drill into any pipes, wires Using the brackets etc. If in doubt, consult fitted to the back edge of an expert.
  • Page 11 Assembly Instructions Step 14 Fit the loose shelf Insert 4 shelf studs the required height. Lower the loose shelf down onto the shelf studs Step 15 Fit the unit to worktop To fit the unit to the worktop use 2 screws to screw up through the holes in the cross rail as shown.
  • Page 12 Assembly Instructions Step 17 PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY TO CHOOSE WHICH 2 HOLES YOU WILL NEED TO DRILL Drill the handle holes in the door Important: Please follow Drill these 2 holes if ONLY drill these instructions you have fitted the carefully.
  • Page 13 Assembly Instructions Step 18 Fit door and handle 2 people are needed Push and here click Note: The easiest way to attach the door is to fit the top hinge first, then align and fit the other hinge. Push Push the hooks on the hinge arm underneath the front of the hinge plate...
  • Page 14 Assembly Instructions Step 19 Adjust the door if needed Height adjustment. Loosen screws A on hinge plates and move door up or down as required. Retighten screw A. Forward and Back adjustment. Loosen screw B on hinge arm and move door in or out as required.
  • Page 15 Assembly Instructions Step 20 Fit the hinge covers Push the hinge covers onto the hinge arms Step 21 Fit the plinth After cutting the plinth to the required length, offer the plinth up to the unit Black Plinth Pack 608/2345 and using a pencil, mark the position of the unit’s Cream Plinth Pack...
  • Page 16 Assembly Instructions Step 22 Fit other products to the unit To fit other products to this unit e.g. worktops etc., please follow the instructions packed with them. We recommend that you consult a qualified joiner or kitchen fitter. Assembly is complete Warning: The unit is heavy.
  • Page 17 Valencia - 1000mm Base Cabinet Assembly Instructions - Please keep for future reference Cabinet 656/5790 hygena Black Door Pack 633/2882 Cream Door Pack 633/2710 Grey Door Pack 656/5295 Plum Door Pack 656/4540 White Door Pack 633/2806 Dimensions Width - 100cm...
  • Page 18 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 26kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 19 (DPF084A) (969 x 96mm) Loose Shelf Back (DPF083A) (DPF085A) (968 x 431mm) (979 x 680mm) The front surface of this door is protected with a Muntin Rail (DPF086A) peel-off film (36 x 688mm) 7 Valencia Door (DPF147B) (497 x 716mm)
  • Page 20 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 21 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Only screw ONE metal dowel into Prepare the left side one of these holes. Screw a metal dowel into one of the holes shown on the left side If you ARE NOT fitting a sink...
  • Page 22 Assembly Instructions Step 3 Prepare the right side Only screw ONE metal dowel into one of these holes (use Screw a metal dowel the same hole that you used into one of the holes for the left side in step 1). shown on the right side Use the same hole that you used for the left side...
  • Page 23 Assembly Instructions Step 5 Prepare the base Insert 4 large locking nuts into the base 10mm as shown. Note: Arrow on locking nut must point towards hole in edge of panel. Tap 6 wooden dowels into the base shown. Note: Wooden dowels must not stick out from the edge by more than 10mm or they may...

  • Page 24: Table Of Contents

    Assembly Instructions Step 7 Join the right side and base Push the base onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to the base Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.

  • Page 25: Tighten The 2 Large

    Assembly Instructions Step 10 Prepare the muntin rail Tap 2 wooden dowels into the muntin rail shown. Step 11 Fit the muntin rail Attach the muntin rail to the base cross rail and secure with 2 screws If you are fitting a sink unit you will need to fit this support rail here Step 12...
  • Page 26 Assembly Instructions Step 13 Fit the left side Push the left side onto the assembly. Use a screwdriver to tighten the large locking fitted to the 2 cross rails and the 2 fitted to the base Note: Turn the large locking nuts as far as they will go - more than...

  • Page 27: The Base

    Assembly Instructions Step 15 Secure the back The bottom edge of the back must be flush with the bottom edge of the base Secure the back the back edge of the base using 4 screws Stand the unit up for the next stage.
  • Page 28 Assembly Instructions Step 17 Joining units together Fittings have been supplied so you are able to join units together. Make sure that your first unit is level. Push the other unit up against first unit and ensure both units are level.
  • Page 29 Assembly Instructions Step 19 Fit the unit to worktop To fit the unit to the worktop use 2 screws to screw up through the holes in the cross rail as shown. Then use 2 screws screw up through the brackets as shown.
  • Page 30 Assembly Instructions Step 21 PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY TO CHOOSE WHICH 2 HOLES YOU WILL NEED TO DRILL Drill the handle holes in the doors Important: Please follow these instructions This will be ONLY drill carefully. the left door these 2 holes Lay the doors down...
  • Page 31 Assembly Instructions Step 22 Fit doors and handles 2 people are needed Push and here click Note: The easiest way to attach the door is to fit the top hinge first, then align and fit the other hinge. Push Push the hooks on the hinge arm underneath the front of the hinge plate...
  • Page 32 Assembly Instructions Step 23 Adjust the door if needed Height adjustment. Loosen screws A on hinge plates and move door up or down as required. Retighten screw A. Forward and Back adjustment. Loosen screw B on hinge arm and move door in or out as required.
  • Page 33 Assembly Instructions Step 24 Fit the hinge covers Push the hinge covers onto the hinge arms Step 25 Fit the plinth After cutting the plinth to the required length, offer the plinth up to the unit Black Plinth Pack 608/2345 and using a pencil, mark the position of the unit’s Cream Plinth Pack...
  • Page 34 Assembly Instructions Step 26 Fit other products to the unit To fit other products to this unit e.g. worktops etc., please follow the instructions packed with them. We recommend that you consult a qualified joiner or kitchen fitter. Assembly is complete Warning: The unit is heavy.
  • Page 36 ALR2653...
  • Page 37 Valencia - 4 Drawer Cabinet Assembly Instructions - Please keep for future reference Cabinet 656/5848 hygena Black Drawer Pack 633/2909 Cream Drawer Pack 633/2734 Oak Drawer Pack 205/4528 White Gloss Drawer Pack 633/2820 White HN Drawer Pack 204/6718 Dimensions Width - 50cm...
  • Page 38 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 16.5kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 39 If you have damaged or missing components, call the Components - Panels Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the panels listed below Base (DPF074A) (469 x 494mm) Left Side Right Side (DPF087A) (DPF088A) (720 x 560mm) (720 x 560mm)
  • Page 40 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 41 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Fit the left runners to the left side Fit the 4 left runners marked ‘L’ to the left side The 1st screw uses...
  • Page 42 Assembly Instructions Step 3 Prepare the left side Screw 4 metal dowels into the holes shown on the left side Note: Tighten metal dowels up fully against the panels. Fit a bracket flush to 150mm the top edge of the left side , about 150mm in from the groove, see...
  • Page 43 Assembly Instructions Step 5 Fit soft close units to the right side Fit the 4 right soft close units marked ‘R’ to the right side using 3 screws Step 6 Prepare the right side Screw 4 metal dowels into the holes shown on the right side Fit a bracket flush to...
  • Page 44 Assembly Instructions Step 7 Prepare the base Insert 4 large locking nuts into the base as shown. Note: Arrow on locking nut must point towards hole in edge of panel. Tap 6 wooden dowels into the base shown. Note: Wooden dowels must not stick out from the edge by more than 10mm or they may...

  • Page 45: Prepare The 2 Cross Rails

    Assembly Instructions Step 9 Join the right side and base Push the base onto the right side Use a screwdriver to tighten the 2 large locking nuts fitted to the base Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
  • Page 46 Assembly Instructions Step 11 Fit the 2 cross rails Push each cross rail onto the right side Use a screwdriver to tighten the large locking fitted to each cross rail Support this cross rail until the left side has been Note: Turn the large fitted in the next step.
  • Page 47 Assembly Instructions Step 13 Fit the back Slide the back along the grooves in the side panels Step 14 Secure the back The bottom edge of the back must be flush with the bottom edge of the base Secure the back the back edge of the base using 3 screws...
  • Page 48 Assembly Instructions Step 15 Warning: Take care when Secure the unit to the drilling the wall wall that you do not drill into any pipes, wires Using the brackets etc. If in doubt, consult fitted to the back edge of an expert.
  • Page 49 Assembly Instructions Step 17 Fit the unit to worktop To fit the unit to the worktop use 2 screws to screw up through the holes in the cross rail as shown. Then use 2 screws screw up through the brackets as shown.
  • Page 50 Assembly Instructions Wheel on Step 19 outside surface Prepare the drawers Fit the left drawer side and right side drawer side onto the drawer Wheel on front using 4 screws outside into the slotted holes. surface Top of Important: Make sure drawer that the drawer sides front...
  • Page 51 Assembly Instructions Step 22 Fit the soft close catches Position the location hole of the right soft close catch marked ‘R’ into the 3rd hole up from the front of the right drawer side then secure Location using 3 screws hole Position the location hole of the left soft close...
  • Page 52 Assembly Instructions Step 24 Prepare the soft close units Before fitting the drawers you will need to push the movable part of the 8 soft close units forward until it clicks into place. Step 25 Fit the drawers Slide the wheels on the drawer sides over the wheels on the runners...
  • Page 53 Assembly Instructions Step 26 Black Plinth Pack 608/2345 Cream Plinth Pack 608/2369 Fit the plinth Oak Plinth Pack 205/5668 After cutting the plinth to White Gloss Plinth Pack 608/2352 the required length, offer the plinth up to the unit White HN Plinth Pack 198/9917 and using a pencil, mark the position of the unit’s...
  • Page 56 ALR2654...
  • Page 57 Valencia - 600mm Larder Cabinet Assembly Instructions - Please keep for future reference Cabinet 633/7777 hygena Black Door Pack 633/2923 Cream Door Pack 633/2758 Oak Door Pack 198/9405 White Gloss Door Pack 633/2844 White HN Door Pack 194/7605 If you are fitting a...
  • Page 58 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 47kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 59 Loose Shelf (DPF079A) Top/Base (DPF078B) (568 x 431mm) x 3 (569 x 494mm) x 2 Small Back (D1148) (164.5 x 570mm) Fixed Shelf (DPF108B) (569 x 494mm) Valencia Door 8 Valencia Larder Door (DPF148B) (DPF156B) (597 x 716mm) (597 x 1258mm)
  • Page 60 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 61 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Choose which way If you would If you would you would like the like your doors like your doors doors to open to open this to open this...
  • Page 62 Assembly Instructions Step 3 IMPORTANT Only carry out this step if you are building a housing for a Prepare the left side fridge/freezer. If you are building a Larder Cupboard you have already prepared this panel in Step 2. Refer to step 1 and, if required, fit 5 hinge plates onto the left...
  • Page 63 Assembly Instructions Step 5 IMPORTANT Only carry out this step if you are building a housing for a Prepare the right side fridge/freezer. If you are building a Larder Cupboard you have already prepared this panel in Step 4. Refer to step 1 and, if required, fit 5 hinge plates onto the right...
  • Page 64 Assembly Instructions Step 7 Fit the legs to the base Push the leg sockets into the holes in the base as shown. Secure each leg socket with 3 screws Tap in the centre plug on each leg socket Push the leg into the leg socket Step 8...
  • Page 65 Assembly Instructions Step 9 Prepare the fixed shelf Insert 4 large locking nuts into the fixed shelf as shown. Note: Arrow on locking nut must point towards hole in edge of panel. Tap 6 wooden dowels into the fixed shelf Note: Wooden dowels must not stick out from the edge by more than...
  • Page 66 Assembly Instructions Step 11 IMPORTANT Fit the small back Only carry out this step if you are building a housing for a fridge/freezer. If you are building a Larder Cupboard please Position the small back ignore this step. between the top and fixed shelf , as shown and secure it into...
  • Page 67 Assembly Instructions Step 13 IMPORTANT Fit the back Only carry out this step if you are building a Larder Cupboard. If you are building a housing for a fridge/freezer please ignore this step. Slide the back along the grooves in the side panels Note: These 3 holes must be...
  • Page 68 Assembly Instructions Step 14 Secure the unit to the Warning: Take wall care when drilling the wall Using the brackets that you do not fitted to the back edge of drill into any pipes, wires the sides etc. If in doubt, consult screw the unit to the an expert.
  • Page 69 Assembly Instructions Step 16 IMPORTANT Fit the loose shelves Only carry out this step if you are building a Larder Cupboard. If you are building a housing for a fridge/freezer please ignore Insert 4 shelf studs this step. the required height for each of the shelves Lower the loose shelves down onto the shelf...

  • Page 70: Right Side

    Assembly Instructions Step 18 PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY TO CHOOSE WHICH 2 HOLES YOU WILL NEED TO DRILL Drill the handle holes in the door Important Important: Please follow If you have these instructions ONLY drill the carefully. fitted the 2 holes in each hinges on the Lay the doors...
  • Page 71 Assembly Instructions Step 19 PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY TO CHOOSE WHICH 2 HOLES YOU WILL NEED TO DRILL Drill the handle holes in the door Important: Please follow Important If you have these instructions carefully. fitted the ONLY drill the hinges on the 2 holes in each Lay the doors...
  • Page 72 Assembly Instructions Step 20 Fit doors and handles 2 people are needed Push and here click Note: The easiest way to attach each door is to fit the top hinge first, then align and fit the other hinge(s). Push Push the hooks on the hinge arm underneath the front of the hinge plate...
  • Page 73 Assembly Instructions Step 21 Adjust the doors if needed Height adjustment. Loosen screws A on hinge plates and move door up or down as required. Retighten screw A. Forward and Back adjustment. Loosen screw B on hinge arm and move door in or out as required.
  • Page 74 Assembly Instructions Step 22 Fit the hinge covers Push the hinge covers onto the hinge arms Step 23 Fit the plinth After cutting the plinth to the required length, offer the plinth up to the unit and using a pencil, mark Black Plinth Pack 608/2345 the position of the unit’s...
  • Page 75 Assembly Instructions Step 24 Fit other products to the unit To fit other products to this unit e.g. worktops etc., please follow the instructions packed with them. We recommend that you consult a qualified joiner or kitchen fitter. Assembly is complete Warning: The unit is heavy.
  • Page 76 ALR2657...
  • Page 77 Valencia - 500mm Wall Cabinet Assembly Instructions - Please keep for future reference Cabinet 656/5721 hygena Black Door Pack 633/2882 Cream Door Pack 633/2710 Grey Door Pack 656/5295 Plum Door Pack 656/4540 White Door Pack 633/2806 Dimensions Width - 50cm...
  • Page 78 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 10kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 79 (469 x 319 mm) End Panel Loose Shelf Back Panel (DPF141A) (DPF092A) (DPF093A) (468 x 236mm) (479 x 694 mm) (320 x 716 mm) The front surface of this door is protected with a peel-off film Valencia Door (DPF147B) (497 x 716mm)
  • Page 80 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 81 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 If you would like If you would like Choose which way your door to your door to you would like the open this way, open this way, door to open...
  • Page 82 Assembly Instructions Step 3 Prepare the right end panel This will be the Refer to step 1 and, if right end panel required, fit 2 hinge plates onto the right end panel , orientated as shown. Screw 4 metal dowels into the holes shown on the right end panel Note: Tighten metal...
  • Page 83 Assembly Instructions Step 5 Join the right side and base Push the base onto the right end panel Use a screwdriver to tighten the 2 large locking nuts fitted to the base Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
  • Page 84 Assembly Instructions Step 7 Cut-outs at the top Fit the back Slide the back along the grooves in the top and base and into the groove of the right end panel Important: Make sure that the cut-outs on the back are at the top of the assembly.
  • Page 85 Assembly Instructions Step 9 18mm 18mm Fit the unit to the wall 464mm 37mm If you are joining this unit Outline of the unit to another one, also refer to step 10. To fix the unit to the wall, place the unit in the required position and lightly mark the outline of Warning: The...
  • Page 86 Assembly Instructions Step 10 Joining units together Fittings have been supplied so you are able to join units together. Make sure that your first unit is level. Push the other unit up against first unit and ensure both units are level.
  • Page 87 Assembly Instructions Step 11 Fit the loose shelf Insert 4 shelf studs the required height. Lower the loose shelf down onto the shelf studs Step 12 Prepare the door Push fit the 2 hinges into the door Secure each hinge with 2 screws Note: Before securing with the screws, make...
  • Page 88 Assembly Instructions Step 13 PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY TO CHOOSE WHICH 2 HOLES YOU WILL NEED TO DRILL Drill the handle holes in the door Drill these 2 holes if Important: Please follow you have fitted the these instructions hinges to the left side.
  • Page 89 Assembly Instructions Step 14 Fit door and handle 2 people are needed Push and here click Note: The easiest way to attach the door is to fit the top hinge first, then align and fit the other hinge. Push Push the hooks on the hinge arm underneath the front of the hinge plate...
  • Page 90 Assembly Instructions Step 15 Adjust the door if needed Height adjustment. Loosen screws A on hinge plates and move door up or down as required. Retighten screw A. Forward and Back adjustment. Loosen screw B on hinge arm and move door in or out as required.
  • Page 91 Assembly Instructions Step 16 Fit the hinge covers Push the hinge covers onto the hinge arms...
  • Page 92 Assembly Instructions Step 17 Fit other products to the unit To fit other products to this unit, please follow the instructions packed with them. We recommend that you consult a qualified joiner or kitchen fitter. Assembly is complete Warning: The unit is heavy.
  • Page 93 Valencia - 1000mm Wall Cabinet Assembly Instructions - Please keep for future reference Cabinet 656/5745 hygena Black Door Pack 633/2882 Cream Door Pack 633/2710 Grey Door Pack 656/5295 Plum Door Pack 656/4540 White Door Pack 633/2806 Dimensions Width - 100cm...
  • Page 94 Safety and Care Advice Important - Please read these instructions fully before starting assembly • Warning: This unit weighs • Make sure you have enough • We do not approximately 16.5kgs. space to layout the parts before recommend the Please lift with care. starting.
  • Page 95 Loose Shelf Muntin Rail (DPF141A) (DPF098A) (DPF100A) (968 x 236mm) (36 x 688mm) (320 x 716mm) The front surface of this door is protected with a peel-off film Back Panel 6 Valencia Door (DPF099A) (DPF147A) (979 x 694mm) (497 x 716mm)
  • Page 96 If you have damaged or missing components, call the Components - Fittings Customer Helpline: 08456 400800 quoting the reference numbers below Please check you have all the fittings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fittings may be supplied than are required.
  • Page 97 If you have damaged or missing components, call the Assembly Instructions Customer Helpline: 08456 400800 quoting the reference numbers below Step 1 Prepare the left end panel Fit 2 hinge plates onto the left end panel orientated as shown. Screw 4 metal dowels into the holes shown on the left end panel Note: Tighten metal...
  • Page 98 Assembly Instructions Step 3 Prepare the base and Insert 4 large locking nuts into the base and top as shown. Note: Arrow on locking nut must point towards hole in edge of panel. Tap 4 wooden dowels into the base and top as shown.
  • Page 99 Assembly Instructions Step 4 Join the right side and base Push the base onto the right end panel Use a screwdriver to tighten the 2 large locking nuts fitted to the base Note: Turn the large locking nuts as far as they will go - more than 1/2 a turn.
  • Page 100 Assembly Instructions Step 6 Prepare the muntin rail Tap 2 wooden dowels into the muntin rail shown. Step 7 Fit the muntin rail Attach the muntin rail to the top and base and secure with 2 screws...
  • Page 101 Assembly Instructions Step 8 Fit the back Cut-outs at the top Slide the back along the grooves in the top and bottom and into the groove of the right end panel Important: Make sure that the cut-outs on the back are at the top of the assembly.
  • Page 102 Assembly Instructions Step 10 18mm 18mm Fit the unit to the wall 964mm 37mm If you are joining this unit Outline of the unit to another one, also refer to step 11. To fix the unit to the wall, place the unit in the required position and lightly mark the outline of the top corners of the...
  • Page 103 Assembly Instructions Step 11 Joining units together Fittings have been supplied so you are able to join units together. Make sure that your first unit is level. Push the other unit up against first unit and ensure both units are level.
  • Page 104 Assembly Instructions Step 13 Fit the loose shelf Insert the loose shelf at an angle then lower it down onto the shelf studs Step 14 Prepare the doors Push fit 2 hinges into each door Secure each hinge with 2 screws Note: Before securing with the screws, make sure that the hinges are...
  • Page 105 Assembly Instructions Step 15 PLEASE FOLLOW THESE INSTRUCTIONS CAREFULLY TO CHOOSE WHICH 2 HOLES YOU WILL NEED TO DRILL Drill the handle holes in the doors This will be Important: Please follow the left door these instructions carefully. Lay the doors down ONLY drill onto a smooth surface.
  • Page 106 Assembly Instructions Step 16 Fit door and handle 2 people are needed Push and here click Note: The easiest way to attach the doors is to fit the top hinge first, then align and fit the other hinge. Push Push the hooks on the hinge arm underneath the front of the hinge plate...
  • Page 107 Assembly Instructions Step 17 Adjust the doors if needed Height adjustment. Loosen screws A on hinge plates and move door up or down as required. Retighten screw A. Forward and Back adjustment. Loosen screw B on hinge arm and move door in or out as required.
  • Page 108 Assembly Instructions Step 18 Fit the hinge covers Push the hinge covers onto the hinge arms Step 19 Fit other products to the unit To fit other products to this unit, please follow the instructions packed with them. We recommend that you consult a qualified joiner or kitchen fitter.
