CHAINTECH CT- 6AIA Manual page 22

WOL (Wake-on-LAN) Connector (J2)
1 1
+
+
1
1
P o w e r su p p ly c o n n .
Creative's SB-LINK Sound Connector (J3)
1
1
+
+
1
1 P o w e r su p p ly c o n n .
System Bus Setting Jumper (JP3)
1
1
+
+
1 1
P o w e r su p p ly c o n n .
Enable the Wake Up On LAN selection in BIOS's Power
Management Menu to use this function. The capability
to remotely manage PCs on a network is a significant
factor in reducing administrative and ownership costs.
Magic Packet technology is designed to give WOL (Wake-
on-LAN) capability to the LAN controller. When a PC
capable of receiving wake up command goes to sleep, the
F L O P P Y 1
Magic Packet mode in the LAN controller is enabled.
When the LAN controller receives a Magic Packet frame,
the LAN controller will wake up the PC. This header is
used to connect an add-in NIC (Network Interface Card)
which gives WOL capability to the mainboard.
To support this function, a switching power supply
with a minimum of 750mA 5VSB is required.
The SB-LINK serves as a bridge between the mainboard
and Creative's PCI sound card. This connector delivers
Sound Blaster 16 compatility for real-mode DOS games.
1
(P C /P C I)
GNT#
GND
F L O P P Y 1
1
CPU
This jumper allows the system bus frequency to be
determined either by the CPU or the user. If set to pins
1-2, the CPU automatic determines the system bus speed.
If set to pins 2-3, the system bus speed is always 100MHz.
F L O P P Y 1
GND
(P C /PC I)
REQ#
S ERIAL
IRQ
1
Hardware Setup
100MHz
17
