6] The Trigger Out socket can not be controlled with this software, and it is automatically
triggered when illuminants are switched. The duration of the output signal (short circuit) is 500
ms. A 3.5 mm mono jack can be plugged into the socket, and an additional iQ-Trigger USB
box can be connected here.
[7] Only available on LED lightHEADs built before December 2020:
Power and intensity control knob for fluorescent lamp F11.
Press the button to turn the lamp off.

5 SOFTWARE DOCUMENTATION

5.1 Introduction

The lightSTUDIO is a Windows software designed to control the lightSTUDIO and its components
(Moving target option, Standard or LED lightHEAD, HDR box, timecode display, and iQ-Trigger). Each
part can be accessed and controlled separately. Moreover, sequence lists can be created for
simultaneous processing, including test chart movements and illumination with the lightHEADs and
HDR box. The graphical user interface (from now on, referred to as GUI) offers a complete overview of
all components simultaneously and quick access to creating an intuitive workflow with the
lightSTUDIO. Each component functions as a plug-in for the software, which switches the
corresponding module in the GUI on or off when a device is connected or disconnected.
